4 4 Y -axis 1 Moving-axis KKD/KKJ-1203 39 40 34 30 36 33 39 38 32 39 31 30 15 36 33 39 23 28 37 37 37 37 37 37 23 28 35 1 1 24 13 24 42 7 26 41 24 1 1 24 13 7 26 41 14 21 18 21 20 19 20 18 23 19 16 16 17 OLD 16 24 28 12 …
3
4
X-axis-Sub Assy
Moving-axis
KKD/KKJ-1203
19
1
6
21
3
13
26
22
15
15
14
14
25
18
16
7
10
9
5
24
9
11
11
17
12
8
27
21
26
2
20
4
13
25
23
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KHY-M2211-00 FRAME R, X AXIS 1
2 KHY-M2240-00 SLEEVE,BRG. 1
3 KHN-M2241-00 HOLDER,MOTOR X 1
4 KHY-M2242-00 HOLDER,BRG. 1
5 KHY-M2271-00 BALL SCREW 1
6 KHY-M2276-S0 X-AXIS GUIDE SET 1
7 KHN-M2221-00 SUPPORT UNIT 1
8 KHN-M2261-A0 HOLDER,HEAD R ASSY. 1
9 KHY-M224H-00 DAMPER 2
10 KHN-M224D-00 SPACER 1
11 KHN-M2248-00 SPACER 2
12 KHN-M22F4-00 WASHER,SWR04 16
13 KHN-M22F6-00 WASHER,SWR06 8
14 KHN-M224J-00 COLLAR A 4
15 KHN-M224K-00 COLLAR B 4
16 KGS-M2628-00 LOCK NUT 1
17 KG2-M9173-00 LOCK NUT 1
18 KM0-M2220-00 COUPLING,X-AXIS 1
19 KHY-M220D-00 TAPE, X-AXIS 2
20 90990-26J008 BEARING 1
21 91312-04014 BOLT HEX.SOCKET HEAD 44 M4X14
22 92012-04025 BOLT BUTTON HEAD 4 M4X25
23 91312-05014 BOLT HEX.SOCKET HEAD 4 M5X14
24 91312-05018 BOLT HEX.SOCKET HEAD 8 M5X18
25 91312-06025 BOLT HEX.SOCKET HEAD 8 M6X25
26 92A08-04304 SET SCREW M4X4 2
27 99480-06018 PIN,PARALLEL 2
4
4
Y-axis 1
Moving-axis
KKD/KKJ-1203
39
40
34
30
36
33
39
38
32
39
31
30
15
36
33
39
23
28
37
37
37
37
37
37
23
28
35
11
24
13
24
42
7
26
41
24
11
24
13
7
26
41
14
21
18
21
20
19
20
18
23
19
16
16
17
OLD
16
24
28
12
5
29
26
6
2
5
26
29
4
29
22
3
24
1
8
9
25
12
27
22
1
8
9
25
27
10
OLD
15
36
34
36
14
35
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KHY-M2648-00 DAMPER 2
2 KHY-M652A-00 SENSOR,Y ORG ASSY 1
3 KHY-M652F-00 SENSOR,Y OT ASSY 1
4 KHY-M2682-00 DOG,ORIGIN 1
5 KHY-M2683-00 DOG,SECOND LIMIT 2
6 KHY-M2691-00 BRACKET,SENSOR 1
7
KHW-M2654-00 PLATE , DAMPER
2
8 KHN-M224J-00 COLLAR A 4
9 KHN-M224K-00 COLLAR B 4
10 KGS-M2256-00 GRIP 1
11 KV7-M2651-00 DAMPER,STOPPER 2
12 90K63-611F04 AC SERVO MOTOR 2
13 KHW-M2656-00 SPACER 4
14
KHY-M26C1-01 COVER TOP,BALL SCREW 1 NG MH40007-2011/4/19
KHY-M26C1-00 COVER TOP,BALL SCREW 1
15
KHY-M26C8-01 COVER TOP L,BS 1 NG MH40007-2011/4/19
KHY-M26C8-00 COVER TOP L,BS 1
16
KHY-M266A-01 PLATE,PIPE 2 OK MG30119-2010/3/26
KHY-M266A-00 PLATE,PIPE R 1
17
Delete MG30119-2010/3/26
KHY-M266B-00 PLATE,PIPE L 1
18 KHY-M266C-00 BLOCK,JOINT 2
19 KHY-M266D-00 JOINT 2
20 KHY-M266E-00 JOINT 2
21 KHN-M22AD-00 GREASE NIPPLE 2
22 91312-03006 BOLT HEX.SOCKET HEAD 4 M3X6
23
Delete MH40007-2011/4/19
91312-04006 BOLT HEX.SOCKET HEAD 20 M4X6
24 91312-04008 BOLT HEX.SOCKET HEAD 21 M4X8
25 91312-04025 BOLT HEX.SOCKET HEAD 4 M4X25
26 91312-05010 BOLT HEX.SOCKET HEAD 14 M5X10
27 91312-06018 BOLT HEX.SOCKET HEAD 8 M6X18
28
Delete MH40007-2011/4/19
92902-04200 WASHER PLAIN 31
29 92902-05600 WASHER PLAIN 10
30 KHY-M26C2-01 COVER1,BALL SCREW 2
31 KHY-M26C3-00 COVER2,BALL SCREW 1
32 KHY-M26C4-00 COVER3,BALL SCREW 1
33 KHY-M26C5-00 HEX. POST 6
34
KHY-M26C6-01 BRKT. 2R,COVER Y 1 NG MH40007-2011/4/19
KHY-M26C6-00 BRKT. 2R,COVER Y 1
35
KHY-M26C7-01 BRKT. 2L,COVER Y 1 NG MH40007-2011/4/19
KHY-M26C7-00 BRKT. 2L,COVER Y 1
36
KHY-M2655-01 BRKT. COVER Y AXIS 2 NG MH40007-2011/4/19
KHY-M2655-00 BRKT. COVER Y AXIS 2
37
91312-05008 BOLT HEX.SOCKET HEAD 30 M5X8 MH40007-2011/4/19
91312-05008 BOLT HEX.SOCKET HEAD 26 M5X8
38 91312-06010 BOLT HEX.SOCKET HEAD 20 M6X10
39
92902-05200 WASHER PLAIN 24 MH40007-2011/4/19
92902-05200 WASHER PLAIN 14
40 90172-00J050 WASHER,EXTL.TOOTHED 8
41 92902-05200 WASHER PLAIN 4
42 KHY-M2658-01 PLATE FIX Y AXIS 1
5
4
Y-axis 2
Moving-axis
KKD/KKJ-1203
36
34
43
40
40
38
37
43
38
39
41
42
39
42
35
12
26
9
9
10
10
8
8
17
25
17
25
26
12
31
32
33
11
29
18
14
28
23
1
2
2
1
22
15
21
5
21
15
21
15
3
21
21
15
21
15
21
13
19
1
1
27
27
27
16
20
27
16
20
24
29
18
14
28
23
22
15
21
5
3
4
13
19
24
4
7
6
30
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KHY-M264A-00 HOLDER SET,Y AXIS 2
2 KHY-M264L-00 SPACER,BRG.SET 2
3 KHY-M2671-00 BALL SCREW 2
4 KHY-M2676-S0 GUIDE SET,Y AXIS 1
5 KHY-M2666-00 HOLDER,NUT Y AXIS 2
6 KHY-M2678-00 GUIDE,CABLE Y AXIS 1
7 KHY-M260A-00 TAPE, Y AXIS 1
8 KHY-M260B-00 TAPE,Y DUCT 1
9 KHY-M260C-00 TAPE 2, Y DUCT 1
10 KHY-M260D-00 TAPE 3, Y DUCT 1
11 KHY-M2695-00 BRACKET GUIDE,Y AXIS 1
12 KHY-M2669-00 BRACKET,HARNESS 2
13
KHY-M224A-A0 SUPPORT UNIT 2 OK MG50155-2010/7/14
KHW-M224A-A0 SUPPORT UNIT 2
14 90990-26J008 BEARING 2
15 KHN-M22F5-00 WASHER,SWR05 16
16 KHN-M2651-00 NYLOCK BOLT (M12X45) 22
17 KV7-M2266-00 PLATE,NUT 2
18 KG2-M9173-00 LOCK NUT 2
19 KM0-M2220-00 COUPLING,X-AXIS 2
20 90201-124G9 WASHER,PLAIN 22
21 91312-05016 BOLT HEX.SOCKET HEAD 60 M5X16
22 91312-06018 BOLT HEX.SOCKET HEAD 8 M6X18
23 91312-06020 BOLT HEX.SOCKET HEAD 8 M6X20
24 91312-06035 BOLT HEX,SOCKET HEAD 8 M6X35
25 98502-03004 SCREW,PAN HEAD 4
26 90990-01J032 BOLT HEX.SOCKET HEAD 8
27 90990-21J001 PIN 6
28 99480-05010 PIN,PARALLEL 2
29 92A08-04305 SET SCREW M4X5 2
30 KHY-M2657-00 BRACKET 1,HARNESS 1
31 91312-04008 BOLT HEX.SOCKET HEAD 8 M4X8
32 91312-05010 BOLT HEX.SOCKET HEAD 14 M5X10
33 92902-05600 WASHER PLAIN 10
34 KHY-M26F1-01 FRAME 1 1
35 KHY-M26F2-01 FRAME 2 1
36 KHY-M26F4-01 DUCT,HARNESS 1
37 KHY-M2694-01 BRACKET 1,GUIDE 1
38 91312-04008 BOLT HEX.SOCKET HEAD 13 M4X8
39 92902-06200 WASHER PLAIN 16
40 90172-00J040 WASHER,EXTL.TOOTHED 11
41 90172-00J060 WASHER,EXTL.TOOTHED 16
42 91312-06010 BOLT HEX.SOCKET HEAD 20 M6X10
43 92902-04200 WASHER PLAIN 31
