KKD_KKJ_YS12P(F)_PL - 第5页
2 1 Sub Assy Base KKD/KKJ-1203 7 8 38 40 37 14 15 9 4 1 1 10 39 6 5 12 13 3 2 7 1 33 34 35 7 8 10 39 14 15 9 4 1 1 20 18 19 17 7 18 19 17 7 16 21 24 25 30 32 28 27 29 26 24 23 22 25 31 36 OLD OLD 27 41 42 43 No. Part No.…
1
1
Base
Base
KKD/KKJ-1203
UPS
32
33
33
33
32
37
11
32
13
12
37
37
31
10
12
3
29
30
37
7
6
6
9
5
8
18
37
37
33
34
16
4
33
34
16
34
16
33
20
36>38
14
37
2
34
16
33
34
16
33
16
34
33
34
16
33
33
15
22
25
24
36
35
28
35
26
35
27
23
36>38
36
21
17
1
19
OLD
13
11
10
24
26
OLD
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1
KHY-M1123-00 PLATE 23
1
2 KHY-M1118-00 PLATE 18 1
3 KHY-M1121-00 PLATE 21 1
4 KHY-M1122-00 PLATE 22 1
5 KHY-M1115-00 PLATE 15 1
6 97602-03306 SCREW,PAN HEAD W/W 2
7
90990-11J003
SCREW,PAN HEAD W/W 18
8
KHY-M1114-00 PLATE 14(I/O) 1
9 98902-03006 SCREW BINDING HEAD 11
10
KKS-M1338-01 BRKT.MAIN SWITCH 1 NG MH90028-2011/11/9
KHY-M1338-00 BRKT.MAIN SWITCH 1
11
KKS-M1336-01 BRKT.REAR LEFT 1 NG MH90028-2011/11/9
KHY-M1336-01
BRKT.REAR LEFT 1
12
90990-23J008 GROMMET 1 OK MG60109-2010/6/22
90990-23J004 GROMMET 1
13
KKS-M1337-01 BRKT. REAR RIGHT 1 NG MH90028-2011/11/9
KHY-M1337-00 BRKT. REAR RIGHT 1
14 KHW-M8597-00 BRACKET,GAUGE 1
15 KV7-M1125-00 PLATE,CLAMP 1
16
KGS-M1371-00 BRACKET,FIX 8
17 KHY-M1163-00 BRACKET 2,FAN 1
18 KHY-M1162-01 BRACKET,FAN 1
19 KHY-M1127-00 COVER,VALVE 1
20 KHY-M1152-01 PLATE SIDE 1 1
21 KHY-M1151-01 PLATE SIDE 2 1
22 KHY-M1151-10 PLATE SIDE 2 1 for UPS
23 KJJ-M1155-00 BRACKET,UPS 1 for UPS
24
KHW-M1157-01 BRACKET 2,UPS 1 for UPS Hole position change NG MHY0088-2012/3/5
KHW-M1157-00 BRACKET 2,UPS 1 for UPS
25 KHW-M1158-00 PLATE,UPS 1 for UPS
26
KHW-M1160-01 COVER,HARNESS 1 for UPS Notch large size NG MHY0088-2012/3/5
KHW-M1160-00 COVER,HARNESS 1 for UPS
27 KHW-M1161-00 BRACKET 3,UPS 1 for UPS
28 KV7-M1515-00 PLATE,RUBBER 1 for UPS
29 KHY-M11F1-00 STAY C/R,R 1
30 KHY-M11F2-00 STAY C/R,L 1
31 KHW-M1124-00 COVER,PU MOTOR UNDER 1
32 KHY-M11E1-A0 BASE MARK ASSY. 3
33 91312-05010 BOLT HEX.SOCKET HEAD 16 M5x10
34 92990-05200 WASHER PLAIN 12
35 90990-12J001 SCREW BIN.HEAD W/W 2 M4x8
36 90990-12J004 SCREW BIN.HEAD W/W 37 M5x10
37 97602-05310 SCREW,PAN HEAD W/W 12
38 90990-12J007 SCREW BIN.HEAD W/W 12 M5x8 OK MG60052-2010/6/17
2
1
Sub Assy
Base
KKD/KKJ-1203
7
8
38
40
37
14
15
9
4
11
10
39
6
5
12
13
3
2
7
1
33
34
35
7
8
10
39
14
15
9
4
11
20
18
19
17
7
18
19
17
7
16
21
24
25
30
32
28
27
29
26
24
23
22
25
31
36
OLD
OLD
27
41
42
43
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1
KG7-M8501-01 AIR FILTER 1 OK MKY0030-2014/1/20
KG7-M8501-00 AIR FILTER 1
2
KG7-M8502-01 MIST FILTER 1 OK MKY0030-2014/1/20
KG7-M8502-00 MIST FILTER 1
3 KG7-M8503-00 MODULE ADAPTER 1
4
KKE-M1125-01 PLATE 25 1 NG MG30043-2010/8/16
KHY-M1125-01 PLATE 25 1
5
90990-42J006 JOINT 1 OK ME30112-2008/6/17
KG7-M8512-00 JOINT 1
6
90990-42J008 JOINT 1 OK ME30112-2008/6/17
KG7-M8513-00 JOINT 1
7 $SL12-03 JOINT 4
8
KHY-M8501-00
EXHAUST VALVE 1 NG MG30043-2010/8/16
KH5-M8501-00 EXHAUST VALVE 1
9 $KM-22 MUFFLER 1
10 KHM-M1397-00 BRACKET,FDD 3 1
11 90K41-000540 LABEL,ALERT 1
12
91312-06012 BOLT HEX.SOCKET HEAD 1 M6X12 MG30043-2010/8/16
91312-06012 BOLT HEX.SOCKET HEAD 2 M6X12
13
92902-06200 WASHER PLAIN 1 MG30043-2010/8/16
92902-06200 WASHER PLAIN 2
14 91312-05010 BOLT HEX.SOCKET HEAD 6 M5X10
15 91312-04008 BOLT HEX.SOCKET HEAD 4 M4X8
16 KHY-M1111-00 PLATE 11 1
17 KHY-M8504-00 REGULATOR 1
18 $SLY10-03 JOINT 1
19 $TL4-02 JOINT 1
20 $KM-31 MUFFLER 1
21 90990-12J004 SCREW BIN.HEAD W/W 5
22 KGA-M1180-00 LEVELING BOLT ASSY 4
23 KHY-M8582-00 VALVE 1
24
$TL8-01 JOINT 1 OK MF60237-2009/7/28
$SL8-01 JOINT 2
25 $KM-11 MUFFLER 2
26 91312-03030 BOLT HEX.SOCKET HEAD 4 M3X30
27
KKS-M1339-01 BRKT.FL 1 NG MH90028-2011/11/9
KHY-M1339-00 BRKT.FL 1
28 KHY-M8596-00 PRESSURE GAUGE 1
29 KG2-M669R-11 HNS,BUZZER 1
30 KV7-M8583-00 OPTION MANIFOLD ASSY 1
31 KM7-M8584-00 MANIFOLD 1
32 91317-03025 BOLT HEX.SOCKET HEAD 2 M3X25
33 KG7-M8501-40 FILTER ELEMENT 1
34 KG7-M8502-40 MIST FILTER ELEMENT 1
35 KHY-M11B0-00 AIR TAG 1
36 KHW-M8582-40 VALVE 1 (Spare)
37 KHY-M1129-00 PLATE 25-1 1 NG MG30043-2010/8/16
38 91312-04005 BOLT HEX.SOCKET HEAD 4 MG30043-2010/8/16
39 98902-04006 SCREW BINDING HEAD 4 MG30043-2010/8/16
40 KHY-M8850-00 PADLOCK ASSY 1
41 97602-05310 SCREW,PAN HEAD W/W 12
42
KG7-M8501-60X BOWL SET 1 Nylon OK MKY0030-2014/1/20
KG7-M8501-50X BOWL SET (AD300) 1 Polycarbonate MHY0008-2011/12/7
43
KG7-M8501-60X BOWL SET 1 Nylon OK MKY0030-2014/1/20
KG7-M8501-50X BOWL SET (AD300) 1 Polycarbonate MHY0008-2011/12/7
1
2
Top Cover
Cover
KKD/KKJ-1203
Cover Rear (Fixed)
26
11
24
9
38
36
37
19
2
27
12
22
23
15
23
22
10
25
18
25
13
1
14
26
11
24
9
8
5
21
21
21
6
13
4
7
17
16
12
3
27
10
25
22
23
23
22
20
30
29
31
40
32
38>46
38
38
38
38
35
46
38
38
38
38
35
38
38
34
34
37
37
34
37
36
37
35
38
36
37
34
37
37
34
34
37
37
37
34
34
38
28
38
28
38
38
38
38
38
43
36
37
43
43
39
39
43
35
38
38
38
39
39
42
30
24
24
29
31
OLD
38
38
39
39
33
41
45
44
18
48
25
38
47
OLD
38>46
48
OLD
19
49
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KHY-M1301-02 COVER 1 1
2 KHY-M1302-02 COVER 2 1
3 KHY-M1303-02 COVER 3 1
4 KHY-M1304-02 COVER 4 1
5 KHY-M1306-00 COVER 6 1
6 KJJ-M130B-00 COVER 6-1 1
7 KHY-M13A5-02 COVER A5 1
8 KHY-M13A6-02 COVER A6 1
9 KHY-M13A7-02 COVER A7 2
10 KGA-M1318-00 COVER 18 1
11 KHY-M1331-03 BRKT.31,SIDE COVER 2
12 KHY-M1334-01 BRKT.1,GATE COVER 2
13 KHY-M1335-01 BRKT.2,GATE COVER 2
14 KHY-M1356-00 PLATE 1,JOINT 1
15 KHY-M1357-00 PLATE 2,JOINT 1
16 KHY-M1358-00 PLATE 3,JOINT 1
17 KHY-M1359-00 PLATE 4,JOINT 1
18
KHY-M13M1-01 PLATE M1 1 Hole diameter change NG MG20109-2010/2/23
KHY-M13M1-00 PLATE M1 1
19
KHY-M13M2-01 PLATE M2 1 Hole diameter change NG MG20109-2010/2/23
KHY-M13M2-00 PLATE M2 1
20
KKJ-M13M3-01 PLATE,KEYBOARD 1 Hole diameter change NG MG20087-2010/3/18
KKJ-M13M3-00 PLATE,KEYBOARD 1 FR Operation OK MF70162-2009/7/23
KHY-M13M3-00 PLATE,KEYBOARD 1 FR Operation
21
K46-M1374-12 HINGE 2 4 OK MK20039-2013/2/13
K46-M1374-11 HINGE 2 4 OK M70096-2009/7/13
K46-M1374-10 HINGE 2 4
22 KM0-M1332-01 BRACKET MAGNET 4
23 KV5-M1130-00 CATCH MG. 4
24 90990-23J024 GROMMET 8
25 90990-23J023 GROMMET 1
26 90K41-000380 LABEL,ALERT 2
27 90K41-000350 LABEL,ALERT 2
28 KHY-M1391-00 PLATE PROTECTOR 2
29
KJV-M1316-01 COVER 16 1 Cover Rear NG MF60283-2009/7/3
KJV-M1316-00 COVER 16 1 Cover Rear
30
KJV-M1317-01 BRACKET,COVER 16 2 Cover Rear NG MF60283-2009/7/3
KJV-M1317-00 BRACKET,COVER 16 2 Cover Rear
31
KJV-M1376-00 COVER TOP,R 1 Cover Rear NG MF60283-2009/7/3
KJV-M1318-00 COVER 18 1 Cover Rear
32 KHY-M1319-00 BRACKET L,COVER18 1
33
Delete MF60283-2009/7/3
91312-04006 BOLT HEX.SOCKET HEAD 8 M4x6
34 91312-04008 BOLT HEX.SOCKET HEAD 10 M4x8
35 98902-03005 SCREW BINDING HEAD 8 M3x5
36 91312-05010 BOLT HEX.SOCKET HEAD 36 M5x10
37 92902-04200 WASHER PLAIN 34
38 90990-12J001 SCREW BIN.HEAD W/W 75
39
90990-12J005 SCREW BIN.HEAD W/W 10 NG MF60283-2009/7/3
90990-46J001 BOLT,THIN HEAD 10 M4x6
40 KHY-M1318-00 BRACKET R,COVER18 1
41 KJV-M1378-00 COVER CENTER,R 1 MF60283-2009/7/3
42 KHU-M1117-00 PULL 1 MF60283-2009/7/3
43 90990-12J006 SCREW BIN.HEAD W/W 10 MF60283-2009/7/3
44 KKE-M1329-00 COVER 29 2 H014662-2010/7/19
45 98902-03008 SCREW BINDING HEAD 6
46 98902-04010 SCREW BINDING HEAD 12
47 KH1-M1396-00 WASHER 12
48
Delete MG20087-2010/3/18
90990-23J008 GROMMET 12 19x6t
49 90990-41J134 COLLAR 4 MK30113-2013/6/10
