11 Placement heads SIPLACE TwinStar (TH) SIPLACE T winStar with component c amera type 33 (fine pitch came ra) with component camer a type 25 (flip chip c amera) Component range a a) Please note that the placeable compon…
10
Placement heads
SIPLACE MultiStar (CPP)
SIPLACE MultiStar (CPP)
with component camera
type 30
With component camera
type 45
with component camera
type 33
(stationary camera)
Component range
a
a) Please note that the placeable component range is also affected by the pad geometry, the customer-specific stan-
dards, the component packaging tolerances and the component tolerances.
01005 to 27 mm x 27 mm 01005 to 15 mm x 15 mm 0402 to 50 mm x 40 mm
b
b) A diagonal of 69 mm is possible during multiple measurements (e.g. 64 mm x 10 mm).
Component spec.
Max height
c
Max. height
d
Min. lead pitch
Min. lead width
Min. ball pitch
Min. ball diameter
Min. dimensions
Max. dimensions
Max. weight
c) CPP head: in low installation position (stationary component camera not possible).
d) CPP head: in high installation position
4.0 mm
e
/ 6.0 mm
8.5 mm
250 µm
100 µm
f
/ 200 µm
g
250 µm
e
/ 350 µm
140 µm
e
/ 200 µm
f
0.4 mm x 0.2 mm
27 mm x 27 mm
4 g
e) Only 4 mm possible for SIPLACE TX2i.
f) For components < 18 mm x 18 mm
g) For components ≥ 18 mm x18 mm
6.0 mm
8.5 mm
250 µm / 120 µm
h
50 µm
140 µm
70 µm
0.11 mm x 0.11 mm
15 mm x 15 mm
4 g
h) Only possible for components which are within the camera focal area of ± 1.3 mm.
11.5 mm
300 µm
150 µm
350 µm
200 µm
1.0 mm x 0.5 mm
50 mm x 40 mm
8 g
Programmable set-down
force
1.0 - 10 N
Nozzle types 20xx, 28xx 20xx, 28xx 20xx, 28xx
X/Y accuracy
i
i) The accuracy values fulfill the conditions in the SIPLACE scope of supply and services.
± 40 µm/3 ± 40 µm/3 ± 34 µm/3
Angular accuracy ± 0.20° / 3
j
, ± 0.38° / 3
k
± 0.25° / 4
h
, ± 0.50° / 4
i
j) Component dimensions between 6 mm x 6 mm and 27 mm x 27 mm.
k) Component dimensions smaller than 6 mm x 6 mm.
± 0.38° / 3 ± 0.14° / 3
± 0.18° / 4
Illumination level 5 5 6
11
Placement heads
SIPLACE TwinStar (TH)
SIPLACE TwinStar
with component camera type 33
(fine pitch camera)
with component camera type 25
(flip chip camera)
Component range
a
a) Please note that the placeable component range is also affected by the pad geometry, the customer-specific standards, the
component packaging tolerances and the component tolerances.
0402 to SO, PLCC, QFP, BGA, special
components, bare dies, flip-chips
0201 to SO, PLCC, QFP, sockets, plugs, BGA,
special components, bare dies, flip-chips,
shields
Component specs
Max. height
Min. lead pitch
Min. lead width
Min. ball pitch
Min. ball diameter
Min. dimensions
Max. dimensions
Max. weight
b
b) Component plus nozzle or gripper.
25 mm
300 µm
150 µm
350 µm
200 µm
1.0 mm x 0.5 mm
55 mm x 45 mm (single measurement)
75 mm x 10 mm (multiple measure-
ment)
100 g
25 mm
250 µm
100 µm
140 µm
80 µm
0.6 mm x 0.3 mm
16 mm x 16 mm (single measurement)
100 g
Programmable set-down
force
1.0 N - 15 N 1.0 N - 15 N
Nozzle types 5xx (standard)
20xx / 28xx (with nozzle adapter 20xx/28xx on 5xx)
Special nozzles, gripper
Nozzle spacing for P&P
heads
70.8 mm 70.8 mm
X/Y accuracy
c
c) The accuracy values fulfill the conditions in the SIPLACE scope of supply and services.
± 28 µm/3 ± 22 µm/3
Angular accuracy ± 0.05° / 3 ± 0.05° / 3
Illumination level 6 6
Possible illumination level
settings
256
6
256
6
12
Placement heads
Nozzle changer
Nozzle changer for the SIPLACE SpeedStar (C&P20 P2)
Nozzle changer for the SIPLACE MultiStar CPP
Nozzle changer for the SIPLACE TwinStar
4 magazines for 20 nozzles of
type 40xx/60xx
3 magazines for 20 nozzles of
type 40xx/60xx
1 magazine for 9 nozzles of
type 28xx
3 magazines for 20 nozzles of
type 20xx
2 magazines for 20 nozzles of
type 20xx
1 magazine for 9 nozzles of
type 28xx
Magazine for two standard nozzles
Magazine for one special nozzle, gripper
Description
Nozzle changers increase the flexibility of the placement heads when it comes to processing
different components. The nozzle configuration can be rapidly adjusted to changing place-
ment jobs. Precisely defined positions and perfect nozzle seat in the garage ensure minimum
radial eccentricity on the placement head.
The nozzle changers feature a monitoring circuit. This checks whether the nozzle magazines
are seated correctly on the mount. In addition, the nozzle changer recognizes whether the
magazines are for 40xx, 20xx or 28xx nozzles by the code.
