12 Placement heads Nozzle changer Nozzle changer for the SI PLACE SpeedSt ar (C&P20 P2) Nozzle changer for the SIPLACE MultiStar CPP Nozzle changer for t h e SIPLACE T winSt ar 4 magazines for 20 nozzles of type 40xx…
11
Placement heads
SIPLACE TwinStar (TH)
SIPLACE TwinStar
with component camera type 33
(fine pitch camera)
with component camera type 25
(flip chip camera)
Component range
a
a) Please note that the placeable component range is also affected by the pad geometry, the customer-specific standards, the
component packaging tolerances and the component tolerances.
0402 to SO, PLCC, QFP, BGA, special
components, bare dies, flip-chips
0201 to SO, PLCC, QFP, sockets, plugs, BGA,
special components, bare dies, flip-chips,
shields
Component specs
Max. height
Min. lead pitch
Min. lead width
Min. ball pitch
Min. ball diameter
Min. dimensions
Max. dimensions
Max. weight
b
b) Component plus nozzle or gripper.
25 mm
300 µm
150 µm
350 µm
200 µm
1.0 mm x 0.5 mm
55 mm x 45 mm (single measurement)
75 mm x 10 mm (multiple measure-
ment)
100 g
25 mm
250 µm
100 µm
140 µm
80 µm
0.6 mm x 0.3 mm
16 mm x 16 mm (single measurement)
100 g
Programmable set-down
force
1.0 N - 15 N 1.0 N - 15 N
Nozzle types 5xx (standard)
20xx / 28xx (with nozzle adapter 20xx/28xx on 5xx)
Special nozzles, gripper
Nozzle spacing for P&P
heads
70.8 mm 70.8 mm
X/Y accuracy
c
c) The accuracy values fulfill the conditions in the SIPLACE scope of supply and services.
± 28 µm/3 ± 22 µm/3
Angular accuracy ± 0.05° / 3 ± 0.05° / 3
Illumination level 6 6
Possible illumination level
settings
256
6
256
6
12
Placement heads
Nozzle changer
Nozzle changer for the SIPLACE SpeedStar (C&P20 P2)
Nozzle changer for the SIPLACE MultiStar CPP
Nozzle changer for the SIPLACE TwinStar
4 magazines for 20 nozzles of
type 40xx/60xx
3 magazines for 20 nozzles of
type 40xx/60xx
1 magazine for 9 nozzles of
type 28xx
3 magazines for 20 nozzles of
type 20xx
2 magazines for 20 nozzles of
type 20xx
1 magazine for 9 nozzles of
type 28xx
Magazine for two standard nozzles
Magazine for one special nozzle, gripper
Description
Nozzle changers increase the flexibility of the placement heads when it comes to processing
different components. The nozzle configuration can be rapidly adjusted to changing place-
ment jobs. Precisely defined positions and perfect nozzle seat in the garage ensure minimum
radial eccentricity on the placement head.
The nozzle changers feature a monitoring circuit. This checks whether the nozzle magazines
are seated correctly on the mount. In addition, the nozzle changer recognizes whether the
magazines are for 40xx, 20xx or 28xx nozzles by the code.
13
Placement heads
Nozzle changer
Technical data
Nozzle changer for the SIPLACE SpeedStar
Number of magazines per location
a
SIPLACE TX1 / TX2
SIPLACE TX2i
a) All magazines in the nozzle changer must be configured.
4
3
Number of nozzle garages per location
SIPLACE TX1 / TX2
SIPLACE TX2i
80
60
Standard configuration
SIPLACE TX1 / TX2 per location
SIPLACE TX2i
4 magazines with 80 nozzle garages
3 magazines with 60 nozzle garages
Nozzle types 40xx/60xx
Nozzle changer for the SIPLACE MultiStar
Number of magazines per location
a
SIPLACE TX1 / TX2
SIPLACE TX2i
4
3
Max. number of nozzle garages per location
SIPLACE TX1 / TX2
SIPLACE TX2i
80
60
Standard configuration per location
SIPLACE TX1 / TX2
SIPLACE TX2i
3 magazines with 60 x 20xx nozzle garages
1 magazine with 9 x 28xx nozzle garages
2 magazines with 40 x 20xx nozzle garages
1 magazine with 9 x 28xx nozzle garages
Nozzle types 20xx, 28xx
Nozzle changer for the SIPLACE TwinStar
Number of magazines
Location 1 Max. 8 magazines for max. 16 nozzle garages
Number of nozzle holders may be freely configured
Standard configuration 3 magazines with two nozzle garages each
1 magazine with one nozzle garage
Nozzle types 5xx (standard)
20xx / 28xx (with nozzle adapter 20xx/28xx on 5xx)
Special nozzle, gripper
