34
Technical data
Electrical ratings, energy consumption and
compressed air supply
Electrical ratings
Supply voltage Fuse
Main power supply 3 x 360 V~ to 3 x 415 V~ ± 10 %; 50/60 Hz
3 x 200 V~ to 3 x 220 V~ ± 10 %; 50/60 Hz
a
a) With options package
3 x 16A characteristic C
3 x 15A characteristic C
b
b) e.g. Siemens circuit breakers in accordance with IEC and UL 489 (order no.: 5SJ4 316-7HG42)
or
EATON Industries circuit breaker FAZ-C16/3-NA 16A 3p (UL 489, CSA C22.2 no. 5, IEC 60947-2)
Mains power connec-
tion
Cable 5 x 2.5 mm² with CEKON connector (3 x 360 V~ to 3 x 415 V~)
Cable 5 x 2.5 mm² without CEKON connector (3 x 200 V~ to 3 x 220 V)
Short circuit classification of machine (SCCR)
c
c) With the original mains connection cable. The marked short circuit rating (SCCR) relates to the beginning of the
original mains cable. In the case of customer modifications, the factory-set length of the mains cable to the machine
may not be shortened nor the factory-set conductor cross-section increased, as this would have a negative impact
on the short circuit rating (SCCR).
10 kA
Energy consumption
With a vacuum pump
d
d) Vacuum pump for C&P20 P2 head only.
Without a vacuum pump
Nominal apparent
power
2.6 kVA 2.3 kVA
Nominal active power 2.00 kW 1.2 kW
Compressed air supply
Compressed air pres-
sure values
p
min
p
max
0.5 MPa = 5.0 bar
1.0 MPa = 10 bar
Operating pressure 0.48 MPa ± 0.025 MPa (4.8 bar ± 0.25 bar)
Compressed air con-
nection
1/2" hose connection
Compressed air consumption
e
e) Average consumption values.
Placement head configu-
ration
Compressed air
consumption
f
with vac-
uum pump
f) Under normal atmospheric conditions at 20°C and 1013 hPa.
Compressed air consump-
tion without vacuum pump
g
g) Optional
SIPLACE TX2i/TX2 C&P20 P2/C&P20 P2
CPP / CPP
CPP / TH
120 Nl/min
No option
No option
No option
260 Nl/min
220 Nl/min
SIPLACE TX1 C&P20 P2
CPP
TH
70 Nl/min
No option
No option
No option
130 Nl/min
130 Nl/min
Compressed air specification according to ISO 8573
Particle size (ISO class 3) 5 µm
Particle density (ISO class 3) 5 mg/m³
Maximum oil content
(ISO class 1)
Particle density 0.01 mg/m³
Pressure dewpoint (ISO class 4) Dewpoint + 3°
35
Technical data
Electrical ratings, energy consumption and
compressed air supply
1 = Electrical connection
2 = Compressed air connection
The connections are run into the machine from below and then connected to the power supply
or pneumatic unit terminals.
36
Technical data
Dimensions and setup conditions
Length
a
Without conveyor extension and with hand guard
With input conveyor extension
b
With output conveyor extension
With input and output conveyor extension)
a) Measured at the outer contour of the machine protection.
b) Only at the first machine in the line.
1000 mm
1260 mm
1604 mm
1864 mm
Width
Outer contour of machine protection (both tables "inside")
With monitor
Outer contour of machine protection (table location 1 "outside")
With monitor
2232 mm
2420 mm
2347 mm
2441mm
Height of machine (for PCB conveyor height 950 mm)
Machine protection closed
With 2-color indicator lamp
With 3-color indicator lamp
Without indicator lamp (height of packaging)
With folded-up short protective cover 45 degrees position
With folded-up short protective cover 60 degrees position
With folded-up short protective cover 45 degrees position
With folded-up short protective cover 60 degrees position
1500 mm
1690 mm
1735 mm
1500 mm
1960 mm
2070 mm
2050 mm
2175 mm
Floor clearance of placement machine TX1/TX2
(for PCB conveyor height 900 mm)
(for PCB conveyor height 930 mm)
(for PCB conveyor height 950 mm)
120 mm ± 15 mm
150 mm ± 15 mm
170 mm ± 15 mm
Machine floor clearance TX2i
(for PCB conveyor height 900 mm)
(for PCB conveyor height 930 mm)
(for PCB conveyor height 950 mm)
120 mm ± 13 mm
150 mm ± 13 mm
170 mm ± 13 mm
Weight
SIPLACE TX (without feeder modules)
SIPLACE TX (fully equipped with feeder modules)
2036 kg
2150 kg
Location
c
With table on outside
c) Measured at the outer contour of the machine protection and without conveyor extension.
2.23 m²
2.33 m²
Even floor surface load (without feeder module)
Even floor surface load(with feeder module)
Characteristic surface load
6.46 kN/m²
6.79 kN/m²
7.70 kN/m²
Number of machine feet 4
Max. noise emissions 75 dB (A)
Please note:
Also observe the document "Network and compressed air configuration for SMD systems"
(German+English, Item No. 00197548-xx), which is supplied with your SIPLACE machine.
