Key No. PART No. PART NAME Q'ty REMARKS REGISTERED No.
54 630 000 8883 SET SCREW 1 M3X4 SET
55 411 141 4008 WASHER V 4X9X0.8 1 FW4
56 411 141 2905 WASHER SPR 4 1 SW4
57 630 000 7626 BOLT,HEX-SCT 1 M4X10
58 630 058 1263 BRACKET 1 648JD-21B-014
59 630 001 0206 WASHER 2 BW3
60 411 141 2806 WASHER SPR 3 2 SW3
61 630 000 7541 BOLT,HEX-SCT 2 M3X14
62 411 141 4008 WASHER V 4X9X0.8 2 FW4
63 411 141 2905 WASHER SPR 4 2 SW4
64 630 000 7657 BOLT,HEX-SCT 2 M4X16
65 616 122 1506 FIBER 2 648JD-21H-503 1CC4V23500380
65 -1 616 122 1513 FIBER ATTACHMENT 4 648JD-21H-505 1CC4V23400100
NOTE
5-2
9705-001
MODEL TIM-1100L
