Key No. PART No. PART NAME Q'ty REMARKS REGISTERED No.
1 616 125 8625 HOLDER 1 648CB-21B-033 1CC2FC0506903
2 616 122 1940 AC SERVO MOTOR 1 648CB-21H-511 1CC4M16000190
3 411 141 4008 WASHER V 4X9X0.8 4 FW4
4 411 141 2905 WASHER SPR 4 4 SW4
5 630 000 7657 BOLT,HEX-SCT 4 M4X16
6 616 125 8755 PULLEY 1 648CB-21H-513 1CC2GD2003950
7 616 112 0069 JOINT 1 648CB-21H-514 1CC2GJ0500440
8 630 000 7626 BOLT,HEX-SCT 6 M4X10
9 411 141 4008 WASHER V 4X9X0.8 4 FW4
10 411 141 2905 WASHER SPR 4 4 SW4
11 630 000 7718 BOLT,HEX-SCT 4 M4X45
12 616 125 8588 SHAFT 1 648CB-21B-017 1CC2GK0503331
13 616 125 8748 PULLEY 1 648CB-21H-507 1CC2GD2003940
14 616 122 1902 BALL BEARING 2 648CB-21H-505 1CC2GF4000010
15 616 125 8595 WASHER 1 648CB-21B-021 1CC2SB0501641
16 616 122 1933 E RING 1 648CB-21H-508 1CC2SC0500640
19 411 141 0505 NUT HEX 5 1 M5
20 616 125 8557 BLOCK 1 648CB-21B-011 1CC2FB1002751
21 616 125 8564 SHAFT 1 648CB-21B-013 1CC2GK0503311
22 616 125 8731 PULLEY 1 648CB-21H-506 1CC2GD2003930
23 616 122 1902 BALL BEARING 2 648CB-21H-505 1CC2GF4000010
24 616 125 8595 WASHER 1 648CB-21B-021 1CC2SB0501641
25 616 122 1933 E RING 1 648CB-21H-508 1CC2SC0500640
27 411 141 6705 WASHER SPR 5 1 SW5
28 411 141 0505 NUT HEX 5 1 M5
29 411 141 4008 WASHER V 4X9X0.8 2 FW4
30 411 141 2905 WASHER SPR 4 2 SW4
31 630 000 7633 BOLT,HEX-SCT 2 M4X12
32 616 902 4703 SHAFT 1 648CB-21B-043 1CC2GK0503343
33 616 122 2046 BALL BEARING 2 648CB-21H-523 1CC2GF4000090
34 411 141 3902 WASHER V 3X7X0.5 1 FW3
35 411 141 2806 WASHER SPR 3 1 SW3
36 630 000 7503 BOLT,HEX-SCT 1 M3X6
37 411 141 4107 WASHER V 5X10X1 1 FW5
39 411 141 0505 NUT HEX 5 1 M5
40 616 125 8571 SHAFT 1 648CB-21B-015 1CC2GK0503321
41 616 125 8731 PULLEY 1 648CB-21H-506 1CC2GD2003930
42 616 122 1902 BALL BEARING 2 648CB-21H-505 1CC2GF4000010
43 616 125 8595 WASHER 1 648CB-21B-021 1CC2SB0501641
44 616 122 1933 E RING 1 648CB-21H-508 1CC2SC0500640
47 411 141 0505 NUT HEX 5 1 M5
48 616 125 8779 BELT 1 648CB-21H-516 1CC2GD1504760
49 616 125 8762 BELT 1 648CB-21H-515 1CC2GD1504750
50 616 122 1728 BRACKET 2 648CB-21B-027 1CC2FC1005270
51 616 112 0113 PHOTO MICRO SENSOR 2 648CB-21H-509 1CC4V24000050
52 616 111 8981 CONNECTOR 2 648CB-21H-510 1CC4J13000010
53 -1 411 119 1909 WASHER V 3X7X0.5 4 FW3 F
53 -2 411 086 4408 WASHER SPR 3 4 SW3 F
53 -3 411 042 0703 SCR PAN 3X8 4 M3X8 PAN
54 411 141 3902 WASHER V 3X7X0.5 4 FW3
NOTE
6-2
9705-001
MODEL TIM-1100L
