Introduction
1.2.1 Contents and Filing of this Manual Important Notes about the User Manual
User Manual JTF-MW on SIPLACE E 7
1.2
1.2 Important Notes about the User Manual
Important Notes about the User Manual
1.2.1
1.2.1 Contents and Filing of this Manual
Contents and Filing of this Manual
This user manual contains basic information that must be observed for a safe and efficient handling of
the feeder.
The service engineers, qualified staff, operators and users must therefore read it before commencing
installation and commissioning. The instructions must be kept permanently accessible wherever the ma-
chine is used.
In addition, the user must ensure that the employees have fully understood the contents of the user man-
ual.
Images are made for proper understanding and can differ slightly to the real environment.
Further Applicable Documents
This feeder shall be installed on a platform (Pick&Placer, Handler, Tester, customer etc.) or any other
host machine. For the use of that also the manual of the host machine must be read and understood.
1.2.2
1.2.2 Danger Notes
Danger Notes
1.2.3
1.2.3 Liability of the Manufacturer/Supplier
Liability of the Manufacturer/Supplier
We draw your attention to the fact that these instructions only contain descriptive and explanatory ma-
terial and do not include any contractual conditions or undertakings. All obligations of ASM Assembly
Systems GmbH & Co. KG are conclusively specified in the respective contract, on the basis of which you
have received the machine described therein. This applies in particular to all statements regarding per-
formance or service life and the agreed liability for faults or defects. The provisions of the contract re-
garding the liability for faults or defect are neither extended nor restricted by any statements in this
manual.
1.2.3.1
1.2.3.1 Limited Liability
Limited Liability
ASM Assembly Systems GmbH & Co. KG is not liable for damages and secondary damages, if the feed-
er is not used according to the intended use. All data and details of this manual are made according to
actual norms and instructions, best available technology and based on long term insight and experienc-
es.
ASM Assembly Systems GmbH & Co. KG is not liable for damages based on:
• Nonobservance of this manual
• Non Intended Use
• Labour of non trained gents
• Unautorized upgrades
• Technical changes
• Use of not autorized spare parts
The true scope of delivery can vary for custom solutions or for special options needed. Also for changes
in technology.
WARNING
Danger notes
► Work may only be performed on the SIPLACE JTF-MW if the personnel concerned have a
thorough knowledge of the relevant section of the user manual.
► All work must be carried out by appropriately trained and qualified personnel.
► All warnings, cautions and hazard notes must be observed.
► Read chapter 2 Operational Safety of the user manual through carefully.
Introduction
Important Notes about the User Manual 1.2.4 Release History
8 User Manual JTF-MW on SIPLACE E
1.2.4
1.2.4 Release History
Release History
1.2.5
1.2.5 Further Information and Contents of Documentation Pack
Further Information and Contents of Documentation Pack
1.2.5.1
1.2.5.1 How To Get Information
How To Get Information
If you have any questions about this manual or if you would like more information about certain subjects,
please contact your local SIPLACE branch or us directly:
ASM Assembly Systems Singapore Pte ltd
2 Corporation Road
#01-03 Corporation Place
1.2.5.2
1.2.5.2 SIPLACE on the World Wide Web (WWW)
SIPLACE on the World Wide Web (WWW)
Log into our SIPLACE
®
homepage at http://www.siplace.com.
► You can choose between the German and English versions.
The different sections contain information about our products, services and contact persons.
In addition, registered customers can also access the
SIPLACE User Group
. Here you can call up spe-
cial information about our placement systems e.g.
▪ Technical documentation,
▪ Technical information,
▪ Spare parts lists etc.
Registration for the user group is very simple:
► Click on the Register link.
► Fill in the registration form and send it off to us.
Soon afterwards, you will receive your access authorization with USER ID and password.
1.2.6
1.2.6 Abbreviations
Abbreviations
Manual Software version Release
First edition SIPLACE E
JEDEC Tray Feeder
User manual
SW 708.x 02/2015
Abbreviations Description
COT Changeover table
COT-i Changeover table insert
C&P Collect&Place
CPP Collect&Pick&Place head
CPx Collective term for CPP, CP20, CP14, CP12 and/or CP6
CP6 SIPLACE CP6, Collect&Place head with 6 segments
CP12 SIPLACE CP12, Collect&Place head with 12 segments
CP14 SIPLACE CP14, Collect&Place head with 14 segments
EMC Electromagnetic compatibility
ESD Electrostatic sensitive device
HMI Human machine interface (Operator panel)
JTF-MW JEDEC Tray Feeder (Automatic tray changer)
PCB Printed circuit board
P&P Pick&Place
Introduction
1.2.6 Abbreviations Important Notes about the User Manual
User Manual JTF-MW on SIPLACE E 9
PP SIPLACE PP, Pick&Place head
SC Station computer
TH SIPLACE TH, Twin Pick&Place head
Abbreviations Description
