vii 1. Safety Do not use any solvent other than specified. 23001-5E-2L c CAUTION Using other than the specified solvents might damage the machine or create a fire hazard.
vi
1. Safety
Possible loss of eyesight
LASER BEAM
Do not stare into laser beam!
Max. output:1 mW, Pulse width: 1ms max.
Semiconductor laser (wavelength: 685nm)
Class 2 laser product
LASER BEAM EXIT
23001-5E-2E
c
CAUTION
Looking directly into the laser beam may cause loss of eyesight.
DON'T
TOUCH
Do not touch camera unit.
DO NOT TOUCH
23001-5E-2F
c
CAUTION
Do not touch the camera unit or apply impacts since this will adversely affect component
mounting operation.
Make correct connections.
23001-5E-2K
c
CAUTION
Wrong connections or wiring methods other than specified might damage the machine. Always
make correct connections by complying with the specified wiring methods.
vii
1. Safety
Do not use any solvent other than specified.
23001-5E-2L
c
CAUTION
Using other than the specified solvents might damage the machine or create a fire hazard.
viii
1.4 Warning label positions
Warning labels with information needed to use the machine safely and correctly are
affixed to the machine and peripheral equipment. Be sure to comply with the instructions
on these warning labels.
Warning labels
Attachment positions (1)
WARNING
CLOSE COVER WHILE OPERATING
WARNING
CLOSE COVER WHILE OPERATING
■ Inside of safety cover
(open/close cover)
WARNING
DO NOT TOUCH THIS SWITCH
MOVING MACHINE MAY CAUSE INJURY
■ Safety cover
(open/close cover)
WARNING
DO NOT TOUCH THIS SWITCH
MOVING MACHINE MAY CAUSE INJURY
■ TSF1 open/close cover
WARNING
DO NOT TOUCH THIS SWITCH
MOVING MACHINE MAY CAUSE INJURY
■ Conveyor cover
■ Conveyor cover
WARNING
CLOSE COVER WHILE OPERATING
■ Inside of TSF1 open/close cover
DON'T
TOUCH
■ Fiducial camera ■ Multi-vision camera
DO NOT TOUCH
23003-5E-20
