1.4 Warning label positions
Warning labels with information needed to use the machine safely and correctly are
affixed to the machine and peripheral equipment. Be sure to comply with the instructions
on these warning labels.
Warning labels
Attachment positions (1)
WARNING
CLOSE COVER WHILE OPERATING
WARNING
CLOSE COVER WHILE OPERATING
■ Inside of safety cover
(open/close cover)
WARNING
DO NOT TOUCH THIS SWITCH
MOVING MACHINE MAY CAUSE INJURY
■ Safety cover
(open/close cover)
WARNING
DO NOT TOUCH THIS SWITCH
MOVING MACHINE MAY CAUSE INJURY
■ TSF1 open/close cover
WARNING
DO NOT TOUCH THIS SWITCH
MOVING MACHINE MAY CAUSE INJURY
■ Conveyor cover
■ Conveyor cover
WARNING
CLOSE COVER WHILE OPERATING
■ Inside of TSF1 open/close cover
DON'T
TOUCH
■ Fiducial camera ■ Multi-vision camera
DO NOT TOUCH
23003-5E-20
1. Safety
ix
Warning labels
Attachment positions (2)
■ Main power connection
section
■ Rear panel
■ Switching power supply
(inside of panel)
■ Motor section (inside of cover)
■ Signal cable connector
■ Front panel
■ Conveyor entrance/exit opening
WARNING
Do not put In
hand through
openIng.
MovIng parts can
pInch hand.
23004-5E-20
