5 -28
5
Editing the PCB data
4. PCB file format conversion
2.Enter the file name in the "VIOS Board Name" box.
The folder (No1) in which XML format files are stored are determined, so you do
not have to designate the folder. Unlike XML files, no extension is attached to the
file name.
3.Click the [OK] button.
The XML PCB data has now been saved as VIOS PCB data.
Table of Contents
1. Data backup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
1.1 Creating a PCB data disk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
1.1.1 Data backup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
2. Creating the user database . . . . . . . . . . . . . . . . . . . . . . . 6-4
2.1 Copying the data into the database . . . . . . . . . . . . . . . . . . . . . . . 6-4
3. Creating XML library. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6
3.1 Setting the library path . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6
3.2 Setting the PCB data links . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8
3.2.1 Setting links from the VGOS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8
3.2.2 Setting links from the Editor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-10
3.2.3 Using library matching (Editor only) . . . . . . . . . . . . . . . . . . . . . . 6-11
3.3 Saving the library data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-13
Chapter 6 Managing the data
