10
DEK NeoHorizon 03iX
Machine productivity options
Process
Specification
Print Method
Paste Dispenser
Paste Roll Height Monitor (aPRHM)
ProFlow® ATx
Stinger
Printing Environment Control
Contact PM
Recommended Stencil Frame
VectorGuard
Adjustable Width Stencil Mount (AWSM)
Frame variants – Fully adjustable to accommodate
frame sizes in the range of 381mm to 736mm
(15” to 29”) by 38mm height.
Image position: Centre/Front/Custom
Under Stencil Cleaning
Cyclone high speed cleaner, fully programmable with
wet/dry/vacuum wipe with external solvent tank
Cyclone Duo. Specify length (300mm, 400mm,
460mm, 515mm)
Vacuum Assist for Under Stencil
Cleaning
On board vacuum unit 35 litres/second airflow
On board venturi vacuum unit
Stencil Positioning
Automatic loading incorporating squeegee drip tray
Temperature/Humidity Sensor
Monitoring of the process environment
Handling & Cleaner Options
Specification
Substrate Handling Size (maximum)
620mm (X) x 508.5mm (Y) – Long Board Option
Under Stencil Cleaning
Blue large board cleaner (580mm)
Software & Communications
Specification
Substrate Handling
Flexible boards
Selective print pass through
Singulation
Software & Communications
GEM on TCP/IP
Statistical Process Control
On board, reported via operator interface (QC-CALC)
11
DEK NeoHorizon 03iX
Machine productivity options
Transport
Specification
Substrate Support
Vacuum tooling capability
Vacuum tooling sensor
Vacuum cupes
Grid-Lok® tooling
Substrate Transport
Single piece conveyor with flat belts (heavy boards)
Remote board stop (for use with heavy board option)
Dual Speed Motor* (to be released)
Substrate Fixture
All Purpose Clamping (APC) system*
Snuggers (edge clamping)
Foil-less clamps
* Can only be used with Modular rail system
Vision & Verfication
Specification
HawkEye® 750 Paste on Pad Verification
Enabled
HawkEye® 1700 Paste on Pad
Verification
Enabled (camera included)
HawkEye
HawkEye® Bridging (requires HawkEye® 1700
camera)
2Di Inspection
Basic stencil and board
Advanced stencil and board
Data Capture
Specification
Product Data Capture
Verification & Traceability
ProDEK closed loop
12
DEK NeoHorizon 03iX
Machine footprint
