Maintenance Inst ructions F Maintenance 03/2003 US Edition 3 Important points to note when carrying out maintenance work 11 3 Imp ort ant poi nt s to note wh en carrying out main- tenance work The main tenance in tervals…
Maintenance Maintenance Instructions F
2 Everything you will need for maintenance 03/2003 US Edition
10
2
2
2
2
2
2
2
2
2
2
2
2
2
Vacuum generator for Pick&Place head 00305378-01
O-ring 6x1 00323535-02
O-ring for valve plunger 00345127-01
Viledon filter mat, 225 x 362 00304048-01
Set of cleaned ceramic nozzles or new nozzles
Set of clean sleeves
Set of clean valve plungers
Valve plunger 00330711-02 (12 x)
Z axis toothed belt 00334936-01
Distributor 00319827-02
O-ring, turning station 00320043-01
Toothed belt, turning station 00320041-01
Spare parts Article number
Maintenance Instructions F Maintenance
03/2003 US Edition 3 Important points to note when carrying out maintenance work
11
3 Important points to note when carrying out main-
tenance work
The maintenance intervals given for inspecting and replacing the filter elements are only valid for
the specified compressed air quality (compressed air specification). If other qualities are used,
the maintenance intervals should be shortened accordingly. 3
CAUTION
NEVER use compressed air to clean inside the placement machine’s modules. 3
Enter the completed maintenance work in the maintenance schedule. We recommend that you
carry out the tasks in the order given in the maintenance schedule. 3
3
3
Maintenance Maintenance Instructions F
4 Maintenance schedule 03/2003 US Edition
12
4 Maintenance schedule
4
Interval Location Equipment / spare parts Done
(date)
Day Empty reject bin, vacuum around machine Collecting container,
vacuum cleaner
Vacuum the nozzle changer Vacuum cleaner
Vacuum the feeders Vacuum cleaner
Empty reject bins Waste bin
Week Vacuum the PCB conveyor / sonar sensor Vacuum cleaner
Clean the X/Y scales Lint-free cloths, ethyl
alcohol
Change the nozzle changer magazines Set of cleaned ceramic
nozzles or new nozzles
Empty the component drawer of the 2x8 mm
conveyor and the flap of the 3x8 mm conveyor
(if present)
Collecting container
Vacuum filter mats for control / servo unit, control unit
for PCB conveyor
Pliers, vacuum cleaner and
new filter mat, if necessary
Vacuum the WPC filter mats Vacuum cleaner
Month Replace the sleeves and valve plungers Laboratory gloves,
cottonwool buds, ethyl
alcohol, lens cloth, set of
cleaned sleeves, set of
cleaned and very lightly
greased valve plungers
Clean and preserve the linear guides for the X and Y
axes
SIPLACE cleaning cloth,
lint-free cloths
Clean the IC camera Phillips screwdriver,
lens cleaning cloth
