Maintenance Inst ructions F Maintenance 03/2003 US Edition 4 Maintenance schedule 17 4 4 4 Sleeves Check the switchi ng ring Clean t he longitu dinal va cuum hole Metal dril l bit, 1.4 mm Clean t he transver se vac uum h…
Maintenance Maintenance Instructions F
4 Maintenance schedule 03/2003 US Edition
16
4
4
4
4
4
4
4
4
4 months Vacuum generator:
Clean the Venturi nozzles Ethyl alcohol, lint-free cloth
Blow air through Venturi nozzles Compressed air
Grease the O-rings Unisilkon L250L
Clean and blow air through the vacuum generator
block
Ethyl alcohol, cottonwool
buds
Silencer:
Clean holes to the Venturi nozzles Ethyl alcohol, cottonwool
buds
Check for dirt
Check the plastic mount for breaks
Year Vacuum beneath the lifting table Vacuum cleaner
Clean and preserve the PCB conveyor SIPLACE cleaning cloth
Check the used tape cutter
Fill both grease nipples with grease Set of hexagon socket
spanners, grease gun,
Urethyn E/M2
Interval Location Equipment / spare parts Done
(date)
Maintenance Instructions F Maintenance
03/2003 US Edition 4 Maintenance schedule
17
4
4
4
Sleeves
Check the switching ring
Clean the longitudinal vacuum hole Metal drill bit, 1.4 mm
Clean the transverse vacuum hole Metal drill bit, 1.1 mm
Clean the suction plate Lint-free cloth
Clean the friction wheel Ethyl alcohol, lint-free cloth
Clean the incremental disk Ethyl alcohol, lint-free cloth
Clean the sleeve shaft Ethyl alcohol, lint-free cloth
Ball catch sleeves
Clean the circumference of the ball catch Ethyl alcohol, lint-free
cottonwool buds
Check the film
Clean the groove Ethyl alcohol, lint-free
cottonwool buds
Standard sleeves
Check the O-ring
Clean the snap-fit O-ring Lint-free cloth
Grease the snap-fit O-ring Unisilkon L250L
Valve plunger
Wipe the valve plunger with a dry cloth Lint-free cloth
Check the sealing lips, the spring O-ring and the
sleeve
Grease the valve plunger ISOFLEX TOPAS, NCA 52
Maintenance Maintenance Instructions F
5 Daily maintenance jobs 03/2003 US Edition
18
5 Daily maintenance jobs
5
