Maintenance Inst ructions F Maintenance 03/2003 US Edition 8 2-monthly maintenance work 53 Maintain the component feeder table 8 a Clear the feeder area. : Remove any loose co mponen ts from the comp onent fe eder table …
Maintenance Maintenance Instructions F
8 2-monthly maintenance work 03/2003 US Edition
52
8
Maintenance Instructions F Maintenance
03/2003 US Edition 8 2-monthly maintenance work
53
Maintain the component feeder table 8
a Clear the feeder area.
: Remove any loose components from the component feeder table using the vacuum cleaner.
s Use a whetstone to remove any irregularities from the magnetic bar.
8
8
d Preserve the feeder area using a lint-free cloth sprayed with WD40.
f Vacuum up any loose components from the tape container and remove any unwanted stickers
and adhesive tape.
8
g Cut off the excess used tape flush with the feeder and empty the component drawer on 8 mm
S feeders.
: Return the feeders to the feeder area.
Make sure that each feeder is in the correct location and is connected correctly. 8
8
8
8
8
8
8
Maintenance Maintenance Instructions F
8 2-monthly maintenance work 03/2003 US Edition
54
8
