Maintenance Maintenance Instr uctions F 2 Everything you will need f or maintenance 03/2003 US E dition 8 2 Everything you will need for maintenance The foll owing lists of m aterial s contain al l the tool s, equipm ent…
Maintenance Instructions F Maintenance
03/2003 US Edition 1 Safety instructions
7
WARNING 1
SIPLACE cleaning tissue 1
1
1
1.1 Explanation of the symbols
1
1
Tools and consumables required 1
1
1
1
Note 1
1
1
1
Tip 1
1
1
1
Caution 1
1
1
1
: Harmful: May cause lung damage if swal-
lowed.
: Do not inhale vapor / aerosol. Avoid contact
with the skin. If swallowed, do not induce
vomiting. See medical attention immediately
and show the packaging or label.
: Wear gloves while using the cleaning tissue.
Maintenance Maintenance Instructions F
2 Everything you will need for maintenance 03/2003 US Edition
8
2 Everything you will need for maintenance
The following lists of materials contain all the tools, equipment and consumables that you will
need to maintain the placement machine. 2
Always use ethyl alcohol for cleaning – do not use solvents. 2
Apply all lubricants sparingly and exactly where they are needed. 2
2.1 Tools and equipment
Have the following tools and equipment to hand before you start the maintenance:
Tools and equipment Article number
Waste bin
Vacuum cleaner
Drip tray
Brush
Short-bristled brush
Pliers (in the service box) 00346929-01
Scissors
Set of hexagon socket spanners
Set of slotted-head screwdrivers
Laboratory gloves
Metal drill bit, 1.1 mm diameter
00092020-01
Metal drill bit, 1.4 mm diameter
00092026-01
Whetstone / oilstone
Pallet jack
2
Maintenance Instructions F Maintenance
03/2003 US Edition 2 Everything you will need for maintenance
9
2.2 Consumables
Have the following consumables to hand before you start the maintenance:
2.3 Spare parts
Have the following spare parts to hand before you start the maintenance:
Consumables Article number
Protective latex gloves 00372972-01
Soft, lint-free cloths
Lint-free cottonwool buds 00352931-02
SIPLACE cleaning cloth 00315253-02
Lens cleaning tissue (e.g. Kodak)
Ethyl alcohol
ISOFLEX TOPAS, NCA 52 00328369-01 1 kg can,
00330850-01 50g tube
WD40, 400 ml 00325833-01
UNISILKON L250L 00310259-01
Z axis oil dispenser with Structovis GHD 00367071-01
Grease cartridge with Urethyn E/M2 02101696-01
Spare parts Article number
Pneumatic maintenance unit
F4 / F5 / F5HM
F3 / F4 Old
00357795-01
00315948-02
Filter G1/2 Modulair, 112 5µ
F4 / F5 / F5HM
F3 / F4 Old
00343010-01
00316488-01
Filter insert, 5 microm. for series 112
F4 / F5 / F5HM
F3 / F4 Old
00355386-01
00330406-01
Silencer for Collect & Place head 00320964-01
