YS100-88_KJJ_KJH_mpl_je - 第60页
KJJ/KJH-101 1 1 1 1 Blow Station Blow Station (YS88) 4 6 17 10 12 21 1 1 1 1 23 16 14 19 26 9 23 8 7 22 25 2 2 5 2 3 1 21 12 30 29 28 27 27 13 18 ST AND DUMP BOX Selection Standard s-A TS 15 24 20 20 31 32 33 33
KJJ/KJH-1011
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1 KHW-M9903-01 BLOCK, BLOW ST. 1 FNC /
Í
39
2 KHW-M9903-50 BLOCK, BLOW ST. 1 SF /
Í
40
3 KHW-M9904-00 BRACKET, SENSOR 2 /
Í
41
4 KHW-M9905-00 PLATE, REFLECT 2 /
Í
42
5 KHW-M99D3-00 STAND, DUMP BOX 1 /
43
6 KJJ-M99D5-00 STAND, DUMP BOX 1 S-ATS /
44
7
KJJ-M652R-00
SENSOR, BLOW ST ASSY 1
B
Í
45
8
90990-41J066 COLOR, SENSOR
4
/
Í
46
9
KGR-M9934-01 INLINE FILTER
1
E
47
10 KGS-M99D0-00 DUMP BOX ASSY. 1 /
48
11 $PF JOINT 1 49
12 $TL6-01M JOINT 1 50
13 $NK-2N NYLON CLIP 5 /
Í
51
14 KGR-M9934-F0 FILTER SPARE 1 E
52
15 KHW-M9931-00 EXHUST BOX 1 /
Í
53
16 KHW-M9932-00 PLATE, TUBE CLAMP 1 /
Í
54
17 97602-04308 SCREW, PAN HEAD W/W 7 /
Í
55
18
97602-05310 SCREW, PAN HEAD W/W
4
/
Í
56
19 90115-02J006
BOLT HEX. SOCKET HEAD
4
57
20 90122-03J008
BOLT BUTTON HEAD
4
58
21 91312-04008 BOLT HEX. SOCKET HEAD 6 M4X8 59
22 91312-06016 BOLT HEX. SOCKET HEAD 2 M6X16 60
23 91317-04010 BOLT HEX. SOCKET HEAD 4 M4X10 61
24 92902-06200 WASHER PLAIN 2 62
25 KHW-M9906-A0 VALVE ASSY. 1 B
Í
63
26 K40-M8598-10 PLUG 1 1 /
64
27 $TL6-02 JOINT 1 /
65
28 91312-03020 BOLT HEX. SOCKET HEAD 2 M3X20 66
29 67
30 68
31 69
32 70
33 71
34 72
35 73
36 74
37 75
38 76
10
1
Blow Station
Blow Station (YS100)
KJJ/KJH-1011
11
1
Blow Station
Blow Station (YS88)
4
6
17
10
12
21
11
11
23
16
14
19
26
9
23
8
7
22
25
2
2
5
2
3
1
21
12
30
29
28
27
27
13
18
STAND DUMP BOX Selection
Standard
s-ATS
15
24
20
20
31
32
33
33
KJJ/KJH-1011
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1 KGR-M99D0-00 DUMP BOX ASSY. 1 /
38
2
KGR-M99D3-00 STAND, DUMP BOX 1 STD /
39
KGR-M99D4-01 STAND, DUMP BOX 1 S-ATS /
40
3 91312-04008 BOLT HEX. SOCKET HEAD 2 41
4 91312-06020 BOLT HEX. SOCKET HEAD 2 42
5
92902-04200 WASHER, PLAIN 2 43
6 92902-06200
WASHER, PLAIN
2
/
Í
44
7 KGR-M9903-02
BLOCK, BLOW ST.
1
/
Í
45
8 KGR-M9904-00
COVER, HEAD
1
/
Í
46
9 KGR-M9905-00 BRACKET R, SENSOR 1 /
Í
47
10 KGR-M9906-00 BRACKET L, SENSOR 1 /
Í
48
11 KJH-M652R-00 SENSOR, BLOW ST ASSY 1 B
Í
49
12 90990-41J066 COLLAR 4 B
Í
50
13 KHW-M9906-A0 VALVE ASSY. 1 B
51
14 KGR-M9934-01 INLINE FILTER 1 E
52
15 K40-M8598-10 PLUG 1 1 /
Í
53
16 $TS6-01 JOINT 2 /
54
17
$TS10-02
JOINT 3
/
55
18
$TL6-02
JOINT 1
/
56
19
$UT6
JOINT 1
/
57
20 $NK-2N NYLON CLIP 6 58
21 90115-02J006 BOLT HEX. SOCKET HEAD 4 59
22 91312-03005 BOLT HEX. SOCKET HEAD 2 60
23 91317-03010 BOLT HEX. SOCKET HEAD 4 61
24 91312-03020 BOLT HEX. SOCKET HEAD 2 62
25 91312-04012 BOLT HEX. SOCKET HEAD 4 63
26 91317-03018 BOLT HEX. SOCKET HEAD 2 64
27 97602-04308
SCREW, PAN HEAD W/WASHER
6 /
Í
65
28 KHW-M9931-00 EXHAUST BOX 1 /
Í
66
29 KHW-M9932-00 PLATE, TUBE CLAMP 1 /
Í
67
30 97602-04308
SCREW, PAN HEAD W/WASHER
7 /
Í
68
31 97602-05310
SCREW, PAN HEAD W/WASHER
4 69
32 KGR-M9934-F0 FILTER SPARE 1 E
70
33 $PF PLUG 7 /
71
34 72
35 73
36 74
37 75
11
1
Blow Station
Blow Station (YS88)
