5OM-1841-001w_F8S - 第72页
5OM-1841 气路图及实际贴装图 1-1-16 1605-001 3 2 4 5 6 No. Name Q’ty No. Name Q’ty No. Name Q’ty No. Name Q’ty 2 Solenoid V alve 2 3 Speed Controller 4 4 Cylinder 2 5 Modular Unit 2 6 Air Connector Pin 2
5OM-1841
气路图及实际贴装图
1-1-15
1605-001
1
7
B
A
B
A
3
2
4
6
5
From Main Body
No. Name Q’ty No. Name Q’ty No. Name Q’ty No. Name Q’ty
1 Tube φ 6 1
2 Solenoid Valve 2
3 Speed Controller 4
4 Cylinder 2
5 Modular Unit 2
6 Air Connector Pin 2
7 Union Y 1
5OM-1841
气路图及实际贴装图
1-1-16
1605-001
3
2
4
5
6
No. Name Q’ty No. Name Q’ty No. Name Q’ty No. Name Q’ty
2 Solenoid Valve 2
3 Speed Controller 4
4 Cylinder 2
5 Modular Unit 2
6 Air Connector Pin 2
5OM-1841
2-A
1605-001
