NPM-W2S 20161226 - 第80页
17-C 全体カバー:NPM-W2S W hole Cover:NPM -W 2S パーツレイアウト Kit No. キット 品番 Kit Name キット名称 MTKA013993AA セクションNo. PARTS LAYOUT Section No. - - S57 ( KMTKA013993AA-00-3 )
Ref
No.
Remarks R
1
Q'ty
17-B
全体カバー:NPM-W2S
Whole Cover:NPM-W2S
ｲﾗｽﾄ
No.
Part No.
品 名品 番 数量
R
2
パーツリスト
Kit No.
キット品番
Kit Name
キット名称
MTKA013993AA
Part Name
備 考
セクションNo.
PARTS LIST
Section No.
R
3
BRACKET
1
1 MTPB001223AB
COVER
1
2 MTKP000662AC
DUCT
2
3 N610161042AA
COVER
1
4 MTKP006884AA
COVER
1
5 N610154519AD
COVER
1
6 N610154520AC
COVER
1
7 N610166194AC
COVER
1
8 MTKP000665AB
COVER
1
9 N610166196AB
COVER
1
10 MTKP006704AA
SPACER
8
11 N510029535AA CF-425E
FAN-GUARD
4
12 KXF077MAA00
S
109-019E
SCREW
8
13 N510018271AA
Cross recessed Truss head machine screw M4X40-4.8 A2J (Trivalent)
SCREW
42
14 N510018304AA
Cross recessed Truss head machine screw M6X10-4.8 A2J (Trivalent)
SCREW
8
15 N510018313AA
Cross recessed Truss head machine screw M6X6-4.8 A2J (Trivalent)
FAN
1
16 N610127903AA
S
S56
--
( KMTKA013993AA-00-2 )
17-C
全体カバー:NPM-W2S
Whole Cover:NPM-W2S
パーツレイアウト
Kit No.
キット品番
Kit Name
キット名称
MTKA013993AA
セクションNo.
PARTS LAYOUT
Section No.
--
S57
( KMTKA013993AA-00-3 )
Ref
No.
Remarks R
1
Q'ty
17-C
全体カバー:NPM-W2S
Whole Cover:NPM-W2S
ｲﾗｽﾄ
No.
Part No.
品 名品 番 数量
R
2
パーツリスト
Kit No.
キット品番
Kit Name
キット名称
MTKA013993AA
Part Name
備 考
セクションNo.
PARTS LIST
Section No.
R
3
COVER
2
1 N210149683AB
WASHER
4
2 MTPA004915AA
FRAME
2
3 MTPA016975AB
COVER
2
4 N210143036AA
BRACKET
2
5 N210143037AC
NUT-PLATE
2
6 N210186760AA
COVER
2
7 N210147088AB
PLATE
4
8 N210164816AA
NUT-PLATE
4
9 N210186756AA
COVER
2
10 MTKP000693AA
COVER
2
11 N610168763AC
COVER
2
12 MTKP000694AA
COVER
2
13 MTKP000695AA
SCREW
68
14 MTNK002299AA
Cross recessed Truss head machine screw M4X10-4.8 A2J(Trivalent)(PA-S
NUT
72
15 KXF0ATGAA00 SFB-002
CAP
104
16 KXF0ATFAA00 SFA-906
GAS-SPRING
4
17 KXF0E381A00
S
KMF70-40M
SPACER
4
18 N510017106AA CF-418E
PULL
2
19 KXF0DX62A00 AP-829-2
BOLT
8
20 N510020762AA MMSB10-10
WASHER
16
21 N510018506AA
Round finish plain washer (JIS B 1256:1978) 10 10H A2J (Trivalent)
SPACER
8
22 N510068123AA CF-502.5ZE
SCREW
8
23 N510068146AA
Cross recessed Truss head machine screw M4X10-4.8 A2S(Trivalent)(UG-
WASHER
8
24 N510018763AA
Toothed lock washer 4 External toothed Steel Unichrome black (Trivalent)
HINGE
4
25 N610124459AA
S58
--
( KMTKA013993AA-00-3 )
