NPM-W2S 20161226 - 第84页
17-E 全体カバー:NPM-W2S W hole Cover:NPM -W 2S パーツレイアウト Kit No. キット 品番 Kit Name キット名称 MTKA013993AA セクションNo. PARTS LAYOUT Section No. - - S61 ( KMTKA013993AA-00-5 )
Ref
No.
Remarks R
1
Q'ty
17-D
全体カバー:NPM-W2S
Whole Cover:NPM-W2S
ｲﾗｽﾄ
No.
Part No.
品 名品 番 数量
R
2
パーツリスト
Kit No.
キット品番
Kit Name
キット名称
MTKA013993AA
Part Name
備 考
セクションNo.
PARTS LIST
Section No.
R
3
COVER
2
1 MTPB001221AC
BRACKET
2
2 MTPB008230AA
BRACKET
2
3 MTPB012564AA Parts for IPO
BRACKET
2
4 MTPB005730AA
LEVER
2
5 N210189368AB Parts for IPO
BRACKET
4
6 N210147090AA
BRACKET
2
7 MTPB005483AA
COVER
1
8 N610120787AB
NUT
18
9 KXF0ATHAA00 SFB-001
NUT
14
10 KXF0ATJAA00 SFB-006
BRACKET
16
11 KXF0ATEAA00 SFJ-018
BRACKET
8
12 KXF0DTWAA00 SFJ-N03
SWITCH
2
13 N510055356AA
S
D4NH-1DBC
SPACER
2
14 N510017089AA CB-304E
WASHER
2
15 N510018472AA
Iron round plain washer3X10X1.0(chromeite) A2J (Trivalent)
BOLT
4
16 N510001582AA SRBS-M4X30
BOLT
2
17 N510034860AA SRBS-M3X10
SPACER
2
18 MTNK002908AA ARB-355SE
CABLE-SUPPORT
2
19 N510048516AA FT3
CABLE-SUPPORT
15
20 N510025949AA C1P-004C
FRAME
2
21 N510057898AA SFF-364 L=1133
FRAME
4
22 N510065817AA SFF-364 L=122
FRAME
2
23 N510057900AA SFF-364 L=793
CAP
4
24 KXF0ARXAA00 SFA-005
JOINT
2
25 KXF06F4AA00 53015030-WM
S60
--
( KMTKA013993AA-00-4 )
17-E
全体カバー:NPM-W2S
Whole Cover:NPM-W2S
パーツレイアウト
Kit No.
キット品番
Kit Name
キット名称
MTKA013993AA
セクションNo.
PARTS LAYOUT
Section No.
--
S61
( KMTKA013993AA-00-5 )
Ref
No.
Remarks R
1
Q'ty
17-E
全体カバー:NPM-W2S
Whole Cover:NPM-W2S
ｲﾗｽﾄ
No.
Part No.
品 名品 番 数量
R
2
パーツリスト
Kit No.
キット品番
Kit Name
キット名称
MTKA013993AA
Part Name
備 考
セクションNo.
PARTS LIST
Section No.
R
3
COLLAR
2
1 N210196356AA
PLATE
2
2 N210199606AA
BRACKET
2
3 N210191817AD
PLATE
4
4 N210134486AA
BRACKET
2
5 N210199601AA
PLATE
4
6 N210122133AA
COVER
2
7 N210161947AB
PLATE
2
8 N210200175AA
COVER
2
9 N610091207AA
COVER
2
10 N610091208AA
COVER
1
11 MTKP001632AA
COVER
1
12 N610124141AB
SCREW
8
13 N510018182AA
Cross recessed Countersunk head machine screw M5X10-4.8 A2J (Trivalen
SCREW
4
14 XTT4+10CYW
Cross recessed Truss head tapping screw Type-2 4X10 SUS
SPACER
2
15 N510036039AA 3382330-30050
BOLT
4
16 N510025332AA MMSB6-15
WASHER
4
17 N510021281AA MMSRB6.5-0.5
WASHER
4
18 N510022693AA WWSS6
WASHER
24
19 N510051102AA DB-6-H
BOLT
2
20 N510057929AA Hexagon head bolt M6X68-10.9 A2J (Trivalent)
NUT
2
21 N510004702AA U nut M6 1-type SUS304
WASHER
4
22 N510057313AA PFS-W06A2S306
SCREW
4
23 N510018255AA
Cross recessed Truss head machine screw M3X8-4.8 A2J (Trivalent)
S62
--
( KMTKA013993AA-00-5 )
