34 Component feeding SIPLACE JTF-M The SIPLACE JTF-M is an automatic and fast change r for standard JEDEC waffle pack trays. O n SIPLACE SX1/SX2 machines, a JTF-M tray feeder can be ins talled on a fixed table instead of…
33
Component feeding
Waffle Pack Changer (WPC5/WPC6)
Technical data
Electrical ratings
WPC5/WPC6 dimensions
Length x width
Height
For 900 mm PCB conveyor height
For 930 mm PCB conveyor height
For 950 mm PCB conveyor height
1520 mm x 360 mm
1430 mm
1460 mm
1480 mm
WPC5 weight
Basic configuration (with cassettes and waffle pack tray carriers)
Fully configured (with WPTC and cassette with components)
Approx. 270 kg
Approx. 320 kg
WPC6 weight
Basic configuration (with cassettes and waffle pack tray carriers)
Fully configured (with WPTC and cassette with components)
Approx. 280 kg
Approx. 330 kg
WPC5/WPC6 surface load ≤ 25 N/cm²
Weight of the waffle pack tray carrier 0.8 kg
Dimensions of waffle pack tray carrier (LxWxH) 360 mm x 260 mm x 6 mm
Dimensions of waffle pack tray (LxWxH) 347 mm x 235 mm x 15 mm
Height of waffle-pack tray, including component
Standard (all levels occupied)
WPC5
WPC6
High components
a
WPC5
b
WPC6
b
a) From serial number B3xxx (WPC5) / C3xxx (WPC6)
b) 45 mm refers to the feed axis (component height + height of waffle pack tray).
15 mm
15 mm
45 mm
45 mm
Distance from level to level 17 mm (± 2 mm)
Storage capacity 28 waffle pack tray carriers
Changeover time for waffle pack tray carrier
over 1 level
over 10 levels
over 27 levels
1.9 s
2.3 s
2.8 s
Supply voltage 3 x 200 V~ ± 10 %; 50/60 Hz (Japan)
3 x 208 V~ ± 10 %; 50/60 Hz (U.S.A)
3 x 230 V~ ± 10 %; 50/60 Hz
3 x 380 V~ ± 10 %; 50/60 Hz
3 x 400 V~ ± 10 %; 50/60 Hz (Europe)
3 x 415 V~ ± 10 %; 50/60 Hz
Nominal apparent power 1.5 kVA
Nominal active power 1.0 kW
Fuse 3 x 10 or 3 x 16 A
34
Component feeding
SIPLACE JTF-M
The SIPLACE JTF-M is an
automatic and fast changer
for standard JEDEC waffle
pack trays. On SIPLACE
SX1/SX2 machines, a JTF-M
tray feeder can be installed
on a fixed table instead of a
component trolley. The
SIPLACE JTF-M occupies a
fixed area of tracks on the
fixed table.
Depending on the magazine
type, the SIPLACE JTF-M
stores up to 18 thin or 14
thick JEDEC waffle pack
trays in an exchangeable
cassette and supplies them
as required. The placement
machine can therefore be
supplied with different com-
ponent types at variable
changeover times.
JTF-M
Fixed component table
35
Component feeding
SIPLACE JTF-M
Technical data
SIPLACE JTF-M
Width
177 mm
Height
587 mm
JEDEC waffle pack tray specifica-
tion
Storage capacity
Waffle pack tray, thin 18 JEDEC waffle pack trays
Thick waffle pack tray 14 JEDEC waffle pack trays
Waffle pack tray changeover time
Slot n to n+1 3.5 seconds
Slot 1 to 18 10 seconds
Slot 18 to 1 8.9 seconds
Cassette
Dimensions approx. 330 mm x 150 mm x 230 mm
Max. load capacity 2.7 kg (150 g each for 18 slots)
Pneumatics
5.2 bar to 9 bar
Compressed air consumption
< 28.3 NL/min.
