4 SIPLACE SX1/SX2 Content OSC package 41 ASM Software Products 42 Overview 42 Technical data 43 Electrical ratings 43 Compressed air supply 44 Electrical connection and compr essed air 45 Dimensions and set up conditions…
3
SIPLACE SX1/SX2
Content
Overview of technical data 5
Maximum values 5
SIPLACE SX1/SX2 6
Machine description 6
Capacity-on-Demand 7
Modular machine concept 9
Example of SIPLACE SX2 10
Example of SIPLACE SX1 with WPC5/WPC6 11
Machine performance 12
Placement heads 13
General 13
SIPLACE SpeedStar (C&P20 P2) 14
SIPLACE MultiStar (CPP) 15
SIPLACE TwinStar (TH) 16
Nozzle changer 17
Technical data 18
Board conveyor 19
Single and dual conveyor 19
Technical data 20
Placement modes 21
Alternating placement mode 22
PCB warpage 23
Virtual Inkspot Handler (VIH) 25
Smart Pin Support 26
Component feeding 27
Component trolley 27
SIPLACE SmartFeeder X / Xi 28
Alternative SIPLACE modules 29
SIPLACE MeasuringFeeder X 30
Tray holders 31
Waffle Pack Changer (WPC5/WPC6) 32
Technical data 33
SIPLACE JTF-M 34
Technical data 35
OnBoard Inspection and Pattern Matching 36
PCB position recognition 37
Barcode types 39
4
SIPLACE SX1/SX2
Content
OSC package 41
ASM Software Products 42
Overview 42
Technical data 43
Electrical ratings 43
Compressed air supply 44
Electrical connection and compressed air 45
Dimensions and setup conditions 46
Machine dimensions 47
Machine center of gravity 47
Maneuvering distances for the component trolleys 48
Maneuvering distances for WPC5/WPC6 49
Spacing distances for single conveyor 50
Spacing distances for the flexible dual conveyor 51
Spacing distances with input conveyor extension 52
Distances for machine with WPC5/WPC6 53
Clearance dimensions with JTF-M 54
Transportation and delivery configuration 55
List of options 56
Overview of languages 58
ESD certificate 59
Notes 60
5
Overview of technical data
Maximum values
Placement performance
Benchmark value 86,500 comp./h
Component range 0201 (metric) - 200 mm x 110 mm
Placement accuracy ± 22 µm (3σ)
Feeding capacity (component trolley) 120 tape feeder modules 8 mm Xi
Board format (length x width) 1525 mm x 560 mm
Camera 6 illumination levels
Protective covers: Telegray 4
(RAL 7047)
Machine base: Graphite black
(RAL 9011)
Covers: Pearl dark gray
(RAL 9023)
Machine colors SIPLACE SX1/SX2
Handles: Ruby red
(RAL 3003)
