Service Manual WPC5 / WPC6
Page 3-49
➢ Carefully insert the new controller board.
➢ Make sure that the controller board engages properly.
➢ Tighten the 4 screws fastening the front plate of the controller board.
➢ Lock the top and bottom locks.
➢ Plug the CAN bus cable back into the front of the controller board..
Settings
➢ Restore the previously saved *.xml file. See section.
➢ For more information, refer to the Online Help for the station software. See "4.5 Storing and
Restoring Machine Data" [➙
4-140].
Service Manual WPC5 / WPC6
Page 3-50
3.6.3.4 Replace the Axis card
Spare Part
• Axis KSP A364 analog [03041865-xx]
Removal / Installation
➢ Wear the ESD wristband.
➢ Loosen the 2 screws fastening the front plate of the axis card.
➢ Carefully pull the axis card (see "3.6.3 Control Unit" [➙ 3-47]) out of the control unit.
➢ Carefully insert the new axis card.
➢ Make sure that the axis card engages properly.
➢
Tighten the 2 screws fastening the front plate of the axis card.
Settings
➢ Perform a firmware download for the axis card..
⇨ Configure, update and calibrate the machine) ⇨ Embedded Software ⇨ Update subsystem ⇨
⇨ Automatic tray feeder axis.
➢ For more information, refer to the Online Help for the station software.
Service Manual WPC5 / WPC6
Page 3-51
3.6.3.5 Replace the Servo Amplifier for the Lifting Axis and Feed Axis
Spare Parts
• Servo amplifier TBS 200/3Z1 [03048005-xx] for feed axis
• Servo amplifier TBS 200/10X1 [00344204-xx] für lifting axis
Removal / Installation
➢ Wear the ESD wristband.
➢ Loosen the 4 screws fastening the plexiglass cover and remove this.
➢ Press down the lock under the board of the relevant servo amplifier (see "3.6.3 Control Unit"
[➙
3-47]).
➢ Carefully pull the servo amplifier out of the control unit.
➢ Make sure that the servo amplifier matches the relevant axis. Compare the part numbers of
the "old" servo amplifier with those of the new one.
➢ Carefully insert the new servo amplifier.
➢ Make sure that the servo amplifier engages properly.
➢ Refit the plexiglass cover and screw into place.
Settings
• No settings are required.
