Chapter Issue 1 Oct 02 Installation Manual 4.1
CHAPTER 4 UNPACKING INSTRUCTIONS
INTRODUCTION
General To ensure the machine is not damaged during transportation certain machine
components are removed prior to dispatch, wrapped and packed separately.
The machine mounting feet are removed at dispatch and replaced with trans-
portation studs, the machine is secured to the base of the transportation box
with nuts and washers. The studs, nuts and washers are replaced on the
machine assembly by the mounting feet.
Unpacking The lids of the transportation boxes are secured with screws. Remove the box
lids and the sides of the large box only. Remove all loose items from the boxes.
Remove the wrapping from around the machine, remove the loose items from
their bags or wrappings.
CAUTION
RED TRANSIT BRACKETS.
Do not remove the red transit brackets attached
to the machine until the machine has been moved to its designated
position.
Machine
Components
Ensure the following machine components, removed for transportation are
complete and correct:
NOTE
Quantities may vary, depending on customers requirements.
Item Yes No
Machine Mounting Feet
Paste Dispenser Nozzle (if paste dispenser option fitted)
500g Paste Cartridge Sleeve (optional)
Paste Dispenser Drip Tray (if paste dispenser option fitted)
Squeegee Paste Drip Tray
Squeegees (if applicable)
ProFlow Unit (optional)
Monitor
Monitor Stand and Ergo Arm Mount
Keyboard/Mouse Unit
Magnetic Tooling Pins
Manifold (if TCU fitted)
Transport Rail Assembly
semi automatic
UNPACKING INSTRUCTIONS
INTRODUCTION
4.2 Installation Manual Chapter Issue 1 Oct 02
Miscellaneous
Items
Ensure the following additional equipment is complete and correct:
Documentation Ensure the following machine documentation is complete and correct:
Item Yes No
Calibration Screen
Calibration Board
Alignment Test Board
Board Clamp Setting Plate
Paste Deflectors, set of 2 (4 items total)
Rail to Table Height Setting Plates (2 items)
Spares Kit (if ordered)
DEK Semi Automatic Software / DEK Semi Automatic Recovery CD-ROM
Item Yes No
DEK Semi Automatic Technical Manuals CD-ROM incorporating:
• Operator Manuals (in all available languages)
• Technical Reference Manual
• User Manual
• Installation Manual
• Electrical Drawings
• Mechanical Drawings
Installation Manual (paper)
Operator Manual (Paper)
Solvent Data Sheet (optional)
Configuration & Dispatch Procedures
Alignment Data
CE Certificate
DEK Delivery Questionnaire
