A-8 Appendix c CAUTION The parts (part Nos.) in this manual were described at the time of manual issue. The part Nos. are subject to change without notice. Make sure to obtain the latest information on part names and par…
A-7
Appendix
n
Maintenance parts list
Position of use Name Part name Part No. Note Qty
HM head unit
Blow valve VALVE KLF-M7152-00X 10
Operation valve VALVE KLF-M7153-00X
For ejector vacuum
generation
10
Shaft blow valve VALVE KLW-M7158-00X 1
Muffler MUFFLER KLW-M715A-00X Muffler inside the bit cap 10
Filer cap FILTER CAP KLW-M7155-00X 10
Bit cap BIT CAP KLW-M7156-00X 10
Vacuum sensor board
VAC SENSOR BRD
ASSY
KHY-M4592-01X 1
Spare ejector EJECTOR KLW-M7157-10X
Valve and ejector unit for
one head
10
Shaft for R-axis idler pulley SHAFT2,TENSION KKE-M7126-00X 2
R-axis drive belt 1 BELT1 KHY-M7131-00X 2
R-axis drive belt 2 BELT2 KHY-M7132-00X 2
Shaft for R-axis tension
pulley
SHAFT1,TENSION KV8-M7115-00X 4
Shaft for R-axis idler pulley 2
SHAFT3,TENSION KKE-M7128-00X 2
R-axis bearing BEARING 90990-25J016 16
Circlip for R-axis idler pulley CIRCLIP 99009-07800 2
Washer for R-axis tension
pulley
WASHER PLAIN 92902-04200 4
Z-axis linear motor Z UNIT ASSY. KLW-M71G5-00X 10
HM5 head unit
Blow valve VALVE KLF-M7152-00X 5
Operation valve VALVE KLF-M7153-00X
For ejector vacuum
generation
5
Shaft blow valve VALVE KLW-M7158-00X 1
Muffler MUFFLER KLW-M715A-00X Muffler inside the bit cap 5
Filer cap FILTER CAP KLW-M7155-00X 5
Bit cap BIT CAP KLW-M7156-00X 5
Vacuum sensor board
VAC5 SENS BRD
ASSY
KHY-M4592-10X 1
Spare ejector EJECTOR KLW-M7157-10X
Valve and ejector unit for
one head
5
Shaft for R-axis idler pulley SHAFT2,TENSION KKE-M7126-00X 1
R-axis drive belt 1 BELT1 KKD-M7131-00X 1
R-axis drive belt 2 BELT2 KKD-M7132-00X 1
Shaft for R-axis tension
pulley
SHAFT1,TENSION KV8-M7115-00X 2
R-axis bearing 1 BEARING 90990-25J016 6
R-axis bearing 2 BEARING 90933-03J105 2
Circlip for R-axis idler pulley CIRCLIP 99009-07800 1
Washer for R-axis tension
pulley
WASHER PLAIN 92902-04200 2
Z-axis linear motor Z UNIT ASSY. KLW-M71G5-00X 5
Blow station Air filter ELEMENT,SPARE KLW-M99B5-F0X 1
Nozzle station
(Common to HM and
HM5 head units)
Cylinder for ANC shutter CYLINDER,ANC ASSY KHY-M652G-10X 1
Nozzle storing sensor board
ANC CTRL BOARD
ASSY
KHY-M45BA-01X 1
ANC cylinder drive valve VALVE KLW-M91V1-00X 1
A-8
Appendix
c
CAUTION
The parts (part Nos.) in this manual were described at the time of manual issue. The part Nos. are subject to change
without notice. Make sure to obtain the latest information on part names and part Nos. when purchasing.
Position of use Name Part name Part No. Note Qty
24-reel fixed feeder
plate
Feeder plate guide rail (Upper
side)
RAIL GUIDE 12P KHY-M371R-00X 8
*3
Guide rail mounting screw
(Upper side)
SCREW, FLAT HEAD 98702-03006 80
*3
Feeder plate guide rail (Lower
side)
GUIDE,FEEDER
UNDER
KHY-M372R-00X 8
*3
Guide rail mounting screw
(Lower side)
SCREW, BINDING
HEAD
98902-03004 32
*3
Tape cutter upper edge CUTTER UPPER,24 KMG-M3T05-00X 4
*3
Tape cutter lower edge set CUTTER LOWER,24 KMG-M3T07-A0X 4
*3
Damper for tape cutter SHOCK ABSORBERS KLW-M3T0D-00X 4
*3
Block for fixing damper BLOCK,ABSORBER KLW-M3T0C-00X 4
*3
Conveyor unit
Pulley for conveyor belt PULLEY,CONV. ASSY. KGY-M9140-A0X
Common to fixed and
movable sides
8
*1
Pulley for adjusting belt tension PULLEY CONV. ASSY KV7-M9140-A0X
Common to fixed and
movable sides
2
*1
Cylinder for board stopper 1 CYL.CV ST R ASSY KMG-M653F-10X
Main (Left to right flow)
Wait (Right to left flow)
1
Cylinder for board stopper 2 CYL.CV ST L ASSY KMG-M653F-20X
Main (Right to left flow)
Wait (Left to right flow)
1
Cylinder for exit stopper CYL.EXIT ST ASSY KMG-M653F-00X 1
Speed controller for cylinder
SPEED
CONTROLLER
KHW-M9274-A0X 2
Cylinder for clamp board CYLINDER KLT-M9263-00X
Common to fixed and
movable sides
2
*1
Speed controller for clamp
board
SPEED
CONTROLLER
KHY-M926S-A0X
Common to fixed and
movable sides
4
*1
Linear guide for clamp board GUIDE KV7-M9266-01X
Common to fixed and
movable sides
6
*1
X-axis
X-axis cable duct CABLE DUCT ASSY. KMG-M2267-A0X 1
Intermediate tape of inner
cable duct
TAPE 1,X DUCT KMG-M220A-00X Cable protection tape 1
Periphery tape of inner cable
duct
TAPE 2,X DUCT KMG-M220B-00X Cable protection tape 1
Inner periphery tape of inner
cable duct
TAPE 3,X DUCT KMG-M220C-00X Cable protection tape 1
Metal plate for cable duct
settlement
COVER DUCT ASSY. KLF-M2243-A0X 1
Power and emergency stop of
inner duct harness
HNS,X-FLEX H.PWR
EMG
KLW-M664F-00X Harness No. J0067 1
Earth wire of inner duct
harness
HNS EARTH 90K30-544110 Harness No. J0665 1
SC-axis motor wiring of inner
duct harness
HNS,X-FLEX SCM KLW-M66E8-00X Harness No. J0158 1
Camera wiring of inner duct
harness
HNS,X-FLEX CAMERA KLW-M66K1-00X Harness No. J0702 1
LAN cable of inner duct harness HNS,X-ELEX LAN KLW-M66B3-00X Harness No. J0183 1
SC-axis encoder wiring of inner
duct harness
HNS,X-FLEX SCP KMG-M66AE-00X Harness No. J0125 1
X-axis ball screw assembly BALL SCREW ASSY. KMG-M2270-00X 1
X-axis guide GUIDE SET,X AXIS KMG-M2276-00X 2
*4
X-axis guide mounting bolt
BOLT HEX.SOCKET
HEAD
91312-04014 30
*4
*1
Required quantity for 2 conveyor rails of fixed and movable sides
*3
Required quantity for front and rear 24-reel fixed bank (Feeder bank x4 positions)
*4
Required quantity for 2 X-axis guides
A-9
Appendix
Position of use Name Part name Part No. Note Qty
Y-axis
Y-axis cable duct DUCT,CABLE KMG-M2678-00X 1
Intermediate tape of inner
cable duct
TAPE 1,Y DUCT KMG-M260B-00X Cable protection tape 1
Periphery tape of inner cable
duct
TAPE 2,Y DUCT KMG-M260C-00X Cable protection tape 1
Inner periphery tape of inner
cable duct
TAPE 3,Y DUCT KMG-M260D-00X Cable protection tape 1
Power and emergency stop of
inner duct harness
HNS,Y-FLEX H.PWR
EMG
KMG-M664E-00X Harness No. J0066 1
Earth wire of inner duct
harness
HNS EARTH 90K30-544160 Harness No. J0664 1
X-axis motor wiring of inner
duct harness
HNS,Y-FLEX XM KLW-M66E6-00X Harness No. J0156 1
SC-axis motor wiring of inner
duct harness
HNS,Y-FLEX SCM KMG-M66EB-00X Harness No. J0157 1
I/O input of inner duct harness HNS,Y-FLEX X DI KMG-M66GE-00X Harness No. J0321 1
Camera wiring of inner duct
harness
HNS,Y-FLEX CAMERA KLW-M66K0-00X Harness No. J0701 1
LAN cable of inner duct harness HNS,Y-FLEX LAN KLF-M66B9-00X Harness No. J0182 1
X-axis encoder wiring of inner
duct harness
HNS,Y-FLEX XP KMG-M66AC-00X Harness No. J0123 1
SC-axis encoder wiring of inner
duct harness
HNS,Y-FLEX SCP KMG-M66AD-00X Harness No. J0124 1
Y-axis ball screw assembly BALL SCREW ASSY. KMG-M2670-00X 1
Y-axis guide GUIDE SET,Y AXIS KMG-M2676-00X 2
*5
Y-axis guide mounting bolt
BOLT HEX.SOCKET
HEAD
90990-01J030 72
*5
PU-axis
Belt for PU-axis motor drive BELT 351-3GT-15 KMG-M920D-00X 1
PU-axis ball screw side belt BELT 1050-3GT-15 KMG-M920E-00X 1
Shaft for tension pulley SHAFT 1 KHW-M921C-00X 1
Circlip for tension pulley CIRCLIP 99009-10400 1
Bearing for tension pulley BEARING 90933-01J300 2
Pulley for motor drive PULLEY:P60-3GT KHW-M9215-00X 1
Pulley for drive unit assembly PULLEY:P60-3GT KHW-M9215-00X 2
Bearing for drive unit assembly BEARING 90933-01J007 4
Circlip for drive unit assembly CIRCLIP 90440-01J090 1
Bearing for pulley assembly BEARING 90933-01J001 2
Pulley for pulley assembly PULLEY:P40-3GT KHW-M9223-00X 1
Circlip for pulley assembly CIRCLIP 99009-12400 1
Electrical part Relay for conveyor I/O board SPARE RELAY KGA-M6522-20X
Relay for I/O CONV
BOARD upstream and
down stream signal lines
13
*5
Required quantity for left and right 2 Y-axis guides
