Version 1.10 September 2020 Maintenance Manual
A-9
Appendix
Position of use Name Part name Part No. Note Qty
Y-axis
Y-axis cable duct DUCT,CABLE KMG-M2678-00X 1
Intermediate tape of inner
cable duct
TAPE 1,Y DUCT KMG-M260B-00X Cable protection tape 1
Periphery tape of inner cable
duct
TAPE 2,Y DUCT KMG-M260C-00X Cable protection tape 1
Inner periphery tape of inner
cable duct
TAPE 3,Y DUCT KMG-M260D-00X Cable protection tape 1
Power and emergency stop of
inner duct harness
HNS,Y-FLEX H.PWR
EMG
KMG-M664E-00X Harness No. J0066 1
Earth wire of inner duct
harness
HNS EARTH 90K30-544160 Harness No. J0664 1
X-axis motor wiring of inner
duct harness
HNS,Y-FLEX XM KLW-M66E6-00X Harness No. J0156 1
SC-axis motor wiring of inner
duct harness
HNS,Y-FLEX SCM KMG-M66EB-00X Harness No. J0157 1
I/O input of inner duct harness HNS,Y-FLEX X DI KMG-M66GE-00X Harness No. J0321 1
Camera wiring of inner duct
harness
HNS,Y-FLEX CAMERA KLW-M66K0-00X Harness No. J0701 1
LAN cable of inner duct harness HNS,Y-FLEX LAN KLF-M66B9-00X Harness No. J0182 1
X-axis encoder wiring of inner
duct harness
HNS,Y-FLEX XP KMG-M66AC-00X Harness No. J0123 1
SC-axis encoder wiring of inner
duct harness
HNS,Y-FLEX SCP KMG-M66AD-00X Harness No. J0124 1
Y-axis ball screw assembly BALL SCREW ASSY. KMG-M2670-00X 1
Y-axis guide GUIDE SET,Y AXIS KMG-M2676-00X 2
*5
Y-axis guide mounting bolt
BOLT HEX.SOCKET
HEAD
90990-01J030 72
*5
PU-axis
Belt for PU-axis motor drive BELT 351-3GT-15 KMG-M920D-00X 1
PU-axis ball screw side belt BELT 1050-3GT-15 KMG-M920E-00X 1
Shaft for tension pulley SHAFT 1 KHW-M921C-00X 1
Circlip for tension pulley CIRCLIP 99009-10400 1
Bearing for tension pulley BEARING 90933-01J300 2
Pulley for motor drive PULLEY:P60-3GT KHW-M9215-00X 1
Pulley for drive unit assembly PULLEY:P60-3GT KHW-M9215-00X 2
Bearing for drive unit assembly BEARING 90933-01J007 4
Circlip for drive unit assembly CIRCLIP 90440-01J090 1
Bearing for pulley assembly BEARING 90933-01J001 2
Pulley for pulley assembly PULLEY:P40-3GT KHW-M9223-00X 1
Circlip for pulley assembly CIRCLIP 99009-12400 1
Electrical part Relay for conveyor I/O board SPARE RELAY KGA-M6522-20X
Relay for I/O CONV
BOARD upstream and
down stream signal lines
13
*5
Required quantity for left and right 2 Y-axis guides
A-10
Appendix
2.2 sATS15 maintenance parts list
Position of use Name Part name Part No. Note Qty
Guide rail
Pallet drawing guide rail L1 GUIDE, PALETTE L1 KMF-M1809-00X 2
Pallet drawing guide rail L2 GUIDE, PALETTE L2 KMF-M1810-00X 1
Pallet drawing guide rail R GUIDE, PALETTE R KMF-M1811-00X 1
Pallet drawing guide rail L3 GUIDE, PALETTE L3 KMF-M1812-00X 1
Latch Cylinder for latch operation
CYLINDER,LATCH
ASSY
KMF-M653E-00X 1
Latch and AH-axis
Valve for latch and hook
drive
ATS VALVE ASSY KMF-M653L-00X 1
AH-axis
AH-axis drive pulley PULLEY 1 KC0-M1751-00X 1
AH-axis idler pulley PULLEY,5 KB0-M2255-01X 1
AH-axis tension pulley PULLEY 4 KB2-M2254-00X 1
Pallet positioning stopper STOPPER ASSY KGX-M18A4-00X 2
Pallet positioning plunger PLUNGER ASSY. KGX-M18A3-02X 3
c
CAUTION
The parts (part Nos.) in this manual were described at the time of manual issue. The part Nos. are subject to change
without notice. Make sure to obtain the latest information on part names and part Nos. when purchasing.
