Chapter 2 Daily maintenance items Contents Before beginning work 2-1 1. Checking the nozzle 2-2 1.1 Checking with software 2-2 1.1.1 V acuum level when nozzle is open 2-4 1.2 Checking the nozzles visually 2-5 2. Cleaning…
1-15
1
Maintenance
2.4 Required tools
Prepare the following tools and items necessary for maintenance.
n
Tool list
: Supplied with machine, : Options
Name Description Remarks
Phillips screwdriver Large, small D-2
Slotted (flat-blade) screwdriver Large, small
Phillips precision screwdriver
#0, #1 (Used to replace nozzle leaf springs and
air valves.)
Hex wrench set 1 set HEX, WRENCH SET
Grease gun Used to supply grease
Air blow tool Used for cleaning
Ultrasonic cleaner Used to clean nozzles.
Nozzle buffing lube supply syringe Used to supply turbine oil (VG32).
Nozzle cleaning wire Used to clean nozzle holes and spline holes.
Vacuum assembly Used to clean feeder plate surface, etc.
n
Other tool list
: Supplied with machine, : Options
Name Description
Grease (lithium-based grease: NSL) Used to lubricate X, Y and W axes.
Turbine oil (VG32) Used as the nozzle buffing lubricant.
Cleaning paper Use lint-free cleaning paper or cloth that does not leave dust or residue.
Square bandage Used to prevent parts from being lost or contaminated. (2 sheets)
Cleaning alcohol Use absolute ethanol.
Paper cup or tray Used for cleaning spline shaft.
Cotton swab stick (15cm) Used to clean camera lens, half mirror and lighting unit.
Lens cleaner Used to clean camera lens and lighting unit.
Blower brush Used to clean camera lens and lighting unit.
Cleaning kit Used for cleaning spline shaft.
Leaf spring installation tool for HM head Used to install the leaf springs of the HM head.
ANC nozzle attaching and detaching tool
Up to 10 nozzles at the nozzle station can be attached / detached at once.
n
Safety goggles and mask
Name Description
Dust-proof goggles
Always wear these goggles and mask when using alcohol, such as
absolute ethanol or an air blow.
Dust-proof mask
2-1
2
Daily maintenance items
Before beginning work
In most cases, maintenance should be performed with the main power turned off.
However, some maintenance tasks are performed under emergency stop conditions with the power turned on.
In such cases, ensure adequate safety and press the emergency stop before beginning the maintenance.
The power is turned on during maintenance where any servo-axis must be operated or machine operation
checked. In this case, also ensure adequate safety before beginning the maintenance.
When operating the machine, make sure the following conditions are met.
n
Operating conditions
1. Supply air pressure is kept at correct pressure.
2. All safety covers are closed.
3. Nozzles and other units are attached in place.
n
NOTE
The description "Cancel the emergency stop." is in the procedures of this manual. It means "releasing the emergency
stop and pressing the [Ready] button to turn the servo on".
