0 Introduction to the User Interface of the Test Program User’s M anual Test Program SITEST Software Version 403.xx Edition 12/97 0 - 2
User’s Manual Test Program SITEST 0 Introduction to the User Interface of the Test Program
Software Version 403.xx Edition 12/97
0 - 1
0 Introduction to the User Interface of
the Test Program
WARNING
∆
!
∆
!
The SITEST test program may only be used by staff members of SIEMENS AG AUT 5, or specially trained
customer staff. Improper use of this test program will result in severe damage to the machine and will pose a
hazard to the operating personnel.
NOTE
This User’s Manual is only valid for SITEST software versions
>
403.02.
0 Introduction to the User Interface of the Test Program User’s Manual Test Program SITEST
Software Version 403.xx Edition 12/97
0 - 2
User’s Manual Test Program SITEST 0 Introduction to the User Interface of the Test Program
Software Version 403.xx Edition 12/97 0.1 Starting/Terminating the Test Program
0 - 3
0.1 Starting/Terminating the Test Program
0.1.1 Starting
●
On the user interface for the station, click on the icon (see User’s Manual SIPLACE 80S-20/F
4
).
The test program is started.
The main view of the user interface of the test program will appear on the screen shortly afterwards
(see section 0.2, Figs. 0.2.1 and 0.2.2).
●
Select the desired language (for the procedure, see chapt. 1, section 1.1).
0.1.2 Terminating
There are three ways of properly terminating the test program, i.e. either
–
from the main view via the Mode menu, by selecting the menu command Exit (see section 0.2.1.1),
–
using the key combination
A
LT
+
F4
–
or by proceeding as described in the following.
NOTE
Only the key combination
A
LT
+
F4
permits the test program to be terminated from any display.
●
In the main view, click on the icon.
NOTE
If newly determined or edited machine data have not been saved yet, an appropriate message will be
displayed before exiting the program prompting you to save the data (see examples below).
