6-17 Module Function 6.10.1.1. SMN Tape Feeder 规格 SMN T ape Feeder 种类 及移动间距 表 6.1 SMN Tape Feed er 种类及移动间距 3 Manual Feeding Lever 8 Index Module 4 Control Module 9 Shutter No. Name No. Name No. Name 品 名 部品编号 移动间距 (mm) …
6-16
Samsung Component Placer SM471 Introduction
备注 以8mm Tape Feeder为基准，供料器底座(Feeder Base)的每个插
槽可以安装一个。
6.10.1. SMN Tape feeder
8mm, 12mm, 16mm, 24mm, 32mm, 44mm, 56mm, 72mm, 88mm 共有9种。
图
6.11 SMN Tape feeder (8mm)
No. Name No. Name No. Name
1 Clamping Lever 6 Tape Guide 11 Clamping
2 Drain 7 Reel Hanger 12 Dump Box
:
;
43
<
86
4
5
7
9
6-17
Module Function
6.10.1.1. SMN Tape Feeder 规格
SMN Tape Feeder种类及移动间距
表
6.1 SMN Tape Feeder
种类及移动间距
3 Manual Feeding
Lever
8 Index Module
4 Control Module 9 Shutter
No. Name No. Name No. Name
品 名
部品编号
移动间距 (mm)
IT Tape
Feeder
IT 8mm 0402 Tape Feeder
8
0402 专用
IT 8mm 2P Tape Feeder 8 2
IT 8mm 4P Tape Feeder 8 4
IT 12mm Tape Feeder 12 4, 8, 12
IT 16mm Tape Feeder 16 4, 8, 12, 16
IT 24mm Tape Feeder 24 4, 8, 12, 16, 20, 24
IT 32mm Tape Feeder 32 4, 8, 12, 16, 20, 24, 32
IT 44mm Tape Feeder 44 4, 8, 12, 16, 20, 24, 32, 40
IT 56mm Tape Feeder 56 4, 8, 12, 16, 20, 24, 32, 40
IT 72mm Tape Feeder 72 4, 8, 12, 16, 20, 24, 32, 40
IT 88mm Tape Feeder 88 4, 8, 12, 16, 20, 24, 32, 40
6-18
Samsung Component Placer SM471 Introduction
可适用Reel
SMN Tape Feeder对应可能的卷（reel）直径请参照下表。此时，SM 8mm Tape
Feeder的 卷（reel）宽 度 (W2) 应在13.0mm 以内。
Non IT
Tape
Feeder
Non-IT 8mm 0402 Tape Feeder
8
0402 专用
Non-IT 8mm 2P Tape Feeder 8 2
Non-IT 8mm 4P Tape Feeder 8 4
Non-IT 12mm Tape Feeder 12 4, 8, 12
Non-IT 16mm Tape Feeder 16 4, 8, 12, 16
Non-IT 24mm Tape Feeder 24 4, 8, 12, 16, 20, 24
Non-IT 32mm Tape Feeder 32 4, 8, 12, 16, 20, 24, 32
Non-IT 44mm Tape Feeder 44 4, 8, 12, 16, 20, 24, 32, 40
Non-IT 56mm Tape Feeder 56 4, 8, 12, 16, 20, 24, 32, 40
Non-IT 72mm Tape Feeder 72 4, 8, 12, 16, 20, 24, 32, 40
Non-IT 88mm Tape Feeder 88 4, 8, 12, 16, 20, 24, 32, 40
品 名
部品编号
移动间距 (mm)
