9-D 一 括交換台車( コンパ ク ト タ イプ ) Feeder Cart(Co mpact Type) パーツレイアウト Kit No. キット品 番 Kit N a me キット名称 N610088987AA ｾｸｼｮﾝN o. PARTS LAYOUT Section No. - - S39 ( KN610088987AA-17-4 )
Ref
No.
Remarks
R
1
Q'ty
9-C
一
括交換台車(
コンパ
ク
ト
タ
イプ
)
Feeder Cart(Compact Type)
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610088987AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
PLATE
1
1 N210021938AB
BUSH
2
2 N210011274AA
PLATE
1
3 N210021943AA
BASE
1
4 N210024448AB
BAR
2
5 KXFB02EGA03
BRACKET
2
6 N210100142AA
COVER
1
7 N210021974AA
COVER
1
8 N210021954AA
BRACKET
2
9 N210019839AA
COVER
1
10 N210076818AB
BRACKET
1
11 N210083874AA
COVER
1
12 N210060009AD
CYLINDER
1
13 N510005138AA ACQ80X75
BOLT
4
14 N510017161AA
Hexagon socket head cap screw M10X130-10.9 A2J (Trivalent)
SPEED-CONTROLLER
2
15 KXF0952AA00 AS3201F-03-06S
WASHER
2
16 N510031421AA 87FWSSB-D50-V16.0-T5.0
COLLAR
2
17 N510044840AA 87FNCLB-V16.0-D25-L23.0
BOLT
1
18 N510017227AA
Hexagon socket head cap screw M16X50-10.9 A2J (Trivalent)
POST
2
19 N510004786AA ETKRFT-25-250-1
BOLT
2
20 N510017190AA
Hexagon socket head cap screw M12X35-10.9 A2J (Trivalent)
BOLT
2
21 N510017187AA
Hexagon socket head cap screw M12X20-10.9 A2J (Trivalent)
COLLAR
4
22 N510044841AA 87FNCLB-V10.0-D16.0-L18.0
WASHER
4
23 N510031420AA 87FWSSB-D25-V10.0-T5.0
MAGNET
2
24 KXF03HBAA00 SM-77S
SCREW
4
25 N510018283AA
Cross recessed Truss head machine screw M4X8-4.8 A2S (Trivalent)
POST
2
26 N510008398AA LSBWRKT-19-133
SCREW
4
27 N510018258AA
Cross recessed Truss head machine screw M4X10-4.8 A2S (Trivalent)
SCREW
2
28 N510018104AA
Cross recessed Pan head machine screw for precision devicesM2X4Type1
BOLT
4
29 N510017398AA
Hexagon socket head cap screw M5X20-10.9 A2J (Trivalent)
BOLT
8
30 N510017401AA
Hexagon socket head cap screw M5X30-10.9 A2J (Trivalent)
BOLT
10
31 N510017442AA
Hexagon socket head cap screw M6X40-10.9 A2J (Trivalent)
BOLT
4
32 N510017170AA
Hexagon socket head cap screw M10X40-10.9 A2J (Trivalent)
WASHER
4
33 N510018478AA
Small round-plain washer 3 10H A2J (Trivalent)
NUT
4
34 N510017867AA
Hexagon nut Type-1 Best class M6-6H-4T A2J (Trivalent)
S38
--
( KN610088987AA-17-3 )
9-D
一
括交換台車(
コンパ
ク
ト
タ
イプ
)
Feeder Cart(Compact Type)
パーツレイアウト
Kit No.
キット品
番
Kit Name
キット名称
N610088987AA
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
S39
( KN610088987AA-17-4 )
Ref
No.
Remarks
R
1
Q'ty
9-D
一
括交換台車(
コンパ
ク
ト
タ
イプ
)
Feeder Cart(Compact Type)
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610088987AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
BAR
2
1 N210011344AA
HOLDER
1
2 KXFB02ERA00
HOLDER
2
3 N210028658AA
SHAFT
2
4 KXFB02F1A00
GUIDE
2
5 KXFB02F0A01
GUIDE
1
6 N210108850AA
PLATE
2
7 N210052464AA
BRACKET
1
8 N210108852AA
BRACKET
1
9 N210108853AA
COVER
1
10 N210111301AA
COVER
1
11 N210111302AA
COVER
1
12 N210118202AA
FRAME
2
14 N510021884AA SFF-364 L=669
FRAME
2
15 KXF0DLSAA00 SFF-364 L=370 TL
FRAME
1
16 N510010029AA SFF-364 L=496
BRACKET
6
17 KXF0ATEAA00 SFJ-018
CAP
4
18 KXF0ARXAA00 SFA-005
CASTER
2
19 N510004570AA 420SA-N75-B
CASTER
2
20 N510004571AA 413SA-N75-B
NUT
2
21 N510017905AA
Hexagon nut Type-1 Best class M16-6H-4T A2J (Trivalent)
BOX
1
22 N210108882AA
NUT
56
23 KXF0ATGAA00 SFB-002
WASHER
2
24 N510031419AA 87FWSSB-D30-V8.0-T2.0
SPRING
2
25 KXF0DLTAA00 (Drawing available 0DLTA)
WASHER
4
26 N510031418AA 87FWSSB-D40-V16.0-T5.0
BOLT
2
27 N986YYYY-915 EH0812
SCREW
4
29 N510018249AA
Cross recessed Truss head machine screw M3X4-4.8 A2J (Trivalent)
MEIBAN
1
30 KXF0DXQCA00
S
NP(Drawing available KXF0DXQCA00)
BOLT
7
31 N510017351AA
Hexagon socket head cap screw M4X16-10.9 A2J (Trivalent)
BOLT
4
33 N510017478AA
Hexagon socket head cap screw M8X40-10.9 A2J (Trivalent)
WASHER
8
35 N510020101AA Thick washer M6
S40
--
( KN610088987AA-17-4 )
