10-A 一 括 交 換 台車対応ユニット Fe ed er Cart Su pp or t Unit パーツレイアウト Ki t N o . キット 品番 Kit N a me キット名称 N6 10 100 61 8AA ｾｸｼｮﾝNo. PARTS LAYOUT Section No. - - S43 ( KN610100618AA-04-1 )

100%1 / 368
Ref
No.
Remarks
R
1
Q'ty
9-E
一
括交換台車(
コンパ
ク
ト
タ
イプ
)
Feeder Cart(Compact Type)
ｲﾗｽﾄ
No.
Part No.
品　　名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610088987AA
Part Name
備　　　考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
HANDLE
2
1 N610101461AA
ARM
2
2 N210181435AA
GUIDE
2
3 N210124269AA
SPACER
2
4 N210111672AA
COLLAR
21
5 N210083870AA
COLLAR
1
6 N210118199AA
SHAFT
2
7 N210118200AA
SHAFT
3
8 N210108835AA
COLLAR
1
9 N210108836AA
COLLAR
20
10 N210083925AA
COLLAR
1
11 N210108837AA
WASHER
19
12 N210091541AA
SPACER
40
13 N210006937AA
PLATE
2
14 N210124270AA
BRACKET
1
15 N210108838AA
BRACKET
1
16 N210108841AA
GUIDE
20
17 N210083865AA
PLATE
40
18 N210071696AB
GUIDE
1
19 N210118203AA
SEPARATOR
5
20 N210087042AA
HOOK
1
21 N210079717AA
RUBBER-LEG
2
22 KXF0CU2AA00 C-31-3
SCREW
80
23 N510004763AA
Cross recessed Countersunk tapping screw M4X8L+TB2430 Type 2 with gr
SCREW
2
25 N510018251AA
Cross recessed Truss head machine screw M3X5-4.8 A2J (Trivalent)
BOX
1
28 KXF0DX4LA00 190564KB-2EB
SPRING
1
29 N510049260AA 87WM22-40
BOLT
4
30 N510017555AA
SSS 003 Hexagon socket button head screw M6X12-10.9 A2J (Trivalent)
URETHANE
2
31 N510044839AA AA20-40
BOLT
2
32 N510032565AA MMSB8-40
TAPE
2
33 N610089007AA
CLAMP
1
34 N510039096AA CY1-16
RING
1
35 N510021575AA RIN-227B
BOLT
2
36 N510017337AA
Hexagon socket head cap screw M3X6-10.9 A2J (Trivalent)
BOLT
4
37 N510017437AA
Hexagon socket head cap screw M6X25-10.9 A2J (Trivalent)
SCREW
1
38 N510018373AA
Hexagon socket set screw Cup point M4X6-45H A2J (Trivalent)
BOLT
58
39 N510017428AA
Hexagon socket head cap screw M6X12-10.9 A2J (Trivalent)
WASHER
26
40 N510018501AA
Round finish plain washer 6 10H A2J (Trivalent)
CAP
4
41 KXF0ATFAA00 SFA-906
PIN
2
42 N210181436AA
BOLT
2
43 N510017534AA
SSS 003 Hexagon socket button head screw M4X6-10.9 A2J (Trivalent)
S42
--
( KN610088987AA-17-5 )
10-A
一
括
交
換
台車対応ユニット
Feeder Cart Support Unit
パーツレイアウト
Ki
t
N
o
.
キット
品番
Kit Name
キット名称
N610100618AA
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
S43
( KN610100618AA-04-1 )
Ref
No.
Remarks
R
1
Q'ty
10-A
一
括
交
換
台車対応ユニット
Feeder Cart Support Unit
ｲﾗｽﾄ
No.
Part No.
品　　名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610100618AA
Part Name
備　　　考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
PIN
1
1 KXFB04AGA01
PIN
1
2 KXFB04AHA01
PLATE
1
6 N210024446AB
PLATE
2
7 N210124737AA
PLATE
1
8 N210024447AB
CHUTE
1
9 N210047431AA
CHUTE
1
10 N210035437AA
BRACKET
1
14 N210124738AA
BRACKET
1
15 N210124739AA
PH-SENSOR
2
16 N610017708AA
PIN
1
21 KXF0CXMAA00 1017003-80020
PIN
2
24 N210168669AA
WASHER
2
25 KXF0CUPAA00 WASBH30-8-3
WASHER
2
26 KXF0DRHAA00 WSSB10-3-1
SPRING
2
27 KXF0DRJAA00 5581
TAPE
1
28 KXF0DXNAA00 AGF-100 t=0.18 W=100mm L=10m
SPACER
2
38 KXF0DRGAA00 ARU-330
BOLT
4
39 N510017337AA
Hexagon socket head cap screw M3X6-10.9 A2J (Trivalent)
BOLT
4
41 N510017308AA
Hexagon socket head cap screw M3X12-10.9 A2J (Trivalent)
BOLT
5
42 N510017381AA
Hexagon socket head cap screw M4X8-10.9 A2J (Trivalent)
BOLT
3
43 N510017344AA
Hexagon socket head cap screw M4X10-10.9 A2J (Trivalent)
BOLT
12
50 N510017475AA
Hexagon socket head cap screw M8X30-10.9 A2J (Trivalent)
WASHER
2
51 N510018497AA
Round finish plain washer 4 10H A2J (Trivalent)
WASHER
6
52 N510018478AA
Small round-plain washer 3 10H A2J (Trivalent)
WASHER
8
55 N510020099AA Thick washer for M4
WASHER
4
58 N510018327AA Spring lock washer No.2 3 S A2J (Trivalent)
POST
1
66 N510017148AA LSBGT13-105-M8-N4
S44
--
( KN610100618AA-04-1 )
