24-A ARカバー (フ ィーダ) AR COVER(FEED ER) パーツレイアウト Ki t N o . キット 品番 Kit N a me キット名称 N610101505AA ｾｸｼｮﾝNo. PARTS LAYOUT Section No. - - S87 ( KN610101505AA-05-1 )
Ref
No.
Remarks
R
1
Q'ty
23
セラミック基
板
対応
Ceramic PCB Capable
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610030594AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
CLAMPER
2
1 N210071370AA
CLAMPER
2
2 N210071371AA
S86
--
( KN610030594AA-02 )
24-A
ARカバー (フィーダ)
AR COVER(FEEDER)
パーツレイアウト
Ki
t
N
o
.
キット
品番
Kit Name
キット名称
N610101505AA
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
S87
( KN610101505AA-05-1 )
Ref
No.
Remarks
R
1
Q'ty
24-A
ARカバー (フィーダ)
AR COVER(FEEDER)
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610101505AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
COVER
1
2 N210045327AA
S
COVER
1
3 N210045328AA
S
COLLAR
2
4 KXFB058VA01
BRACKET
1
6 N210045329AB
BRACKET
1
7 N210045330AA
COVER
1
8 N610117238AA
S
COVER
1
9 N610117239AA
S
COVER
1
10 N210045333AA
COVER
1
11 N210045334AA
S
MAGNET
3
20 KXF0CS8AA00 C-54-2-black
SCREW
6
22 N510018233AA
Cross recessed Truss head machine screw M3X10-4.8 A2S (Trivalent)
SCREW
4
23 N510018280AA
Cross recessed Truss head machine screw M4X6-4.8 A2S (Trivalent)
SCREW
7
24 N510018283AA
Cross recessed Truss head machine screw M4X8-4.8 A2S (Trivalent)
SCREW
4
25 N510018258AA
Cross recessed Truss head machine screw M4X10-4.8 A2S (Trivalent)
SCREW
2
26 N510018266AA
Cross recessed Truss head machine screw M4X16-4.8 A2S (Trivalent)
WASHER
2
28 KXF0CXEAA00 URWH12-8-5
WASHER
4
29 N510018469AA
Iron round plain washer4X10X1.0 A2J (Trivalent)
SPACER
2
30 N510017097AA CB-405E
BOLT
2
31 KXF0DYG5A00 GUTB4-5-10
BOLT
2
41 N510017424AA
Hexagon socket head cap screw M6X10-10.9 A2J (Trivalent)
WASHER
6
42 N510018497AA
Round finish plain washer 4 10H A2J (Trivalent)
WASHER
4
43 N510020098AA Thick washer for M3
WASHER
4
44 N510020100AA Thick washer for M5
NUT
6
45 N510017849AA
Hexagon nut Type-1 Best class M3-6H-4T A2J (Trivalent)
NUT
8
46 N510017855AA
Hexagon nut Type-1 Best class M4-6H-4T A2J (Trivalent)
NUT
2
47 N510017867AA
Hexagon nut Type-1 Best class M6-6H-4T A2J (Trivalent)
BOLT
4
49 N510017390AA
Hexagon socket head cap screw M5X12-10.9 A2J (Trivalent)
COLLAR
2
78 N210071617AA
BRACKET
1
79 N210075829AA
DOG
1
80 N210075609AA
BRACKET
1
81 N210118913AA
SCREW
2
82 N510018266AA
Cross recessed Truss head machine screw M4X16-4.8 A2S (Trivalent)
BOLT
2
83 N510017337AA
Hexagon socket head cap screw M3X6-10.9 A2J (Trivalent)
WASHER
4
84 N510018494AA
Round finish plain washer 3 10H A2J (Trivalent)
S88
--
( KN610101505AA-05-1 )
