CM232-M - 第24页
1-F 本体部 Mai n B od y パーツレイアウト Kit No. キット品 番 Kit N a me キット名称 N610090756AA ｾｸｼｮﾝN o. PARTS LAYOUT Section No. - - M11 ( KN610090756AA-11-6 )
Ref
No.
Remarks
R
1
Q'ty
1-E
本体部
Main Body
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610090756AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
HOLDER
4
1 N210058099AA
BLOCK
4
2 KXFB09VAA00
HOLDER
4
3 KXFB09VBA01
HOLDER
4
4 KXFB02GGA01
COLLAR
4
5 KXFB00T1A00
BUSHING
8
6 KXFB01GBA00
COUPLING
4
7 KXF0E10UA00 SFC-050DA-12B-24B
COVER
4
8 N210028680AA
BRACKET
4
9 N210111451AB
BALL-SCREW
4
10 N510054190AA SBK2030ZS-3.4RRG0+1130LCp5R(B)(30013756M010)
LINEAR-WAY
4
11 N510054191AA
SHS20LV2QZUC1E/2UC1E+1700LHS-II(C)(02378788G000)
BEARING
4
12 KXF0A1UAA00 7002CDB/GNP5
BEARING
4
13 KXF0A1SAA00 7202T2DF/GNP5
BEARING-NUT
8
14 KXF00W4AA00 AN02
BEARING
8
15 KXF010WAA00 AW02
MOTOR
4
16 KXF0CWLAA00
S
HC-RFS103-S1(DDA)
JOINT
8
17 KXF029NAA00 KJS04-M5
JOINT
4
18 KXF02T9AA00 M-5HL-4
PIN
4
19 N510020617AA MMS6-10
PIN
4
20 KXF0CXMAA00 1017003-80020
WASHER
4
21 KXF0DX46A00 WSSB30-15-5
SHIM
4
22 KXF0DX47A00 CIMR15-21-0.5
BOLT
8
23 N510017381AA
Hexagon socket head cap screw M4X8-10.9 A2J (Trivalent)
BOLT
16
24 N510017390AA
Hexagon socket head cap screw M5X12-10.9 A2J (Trivalent)
BOLT
112
25 N510017395AA
Hexagon socket head cap screw M5X16-10.9 A2J (Trivalent)
BOLT
24
26 N510017398AA
Hexagon socket head cap screw M5X20-10.9 A2J (Trivalent)
BOLT
16
27 N510017401AA
Hexagon socket head cap screw M5X30-10.9 A2J (Trivalent)
BOLT
16
28 N510017437AA
Hexagon socket head cap screw M6X25-10.9 A2J (Trivalent)
BOLT
24
29 N510017475AA
Hexagon socket head cap screw M8X30-10.9 A2J (Trivalent)
WASHER
8
30 N510018497AA
Round finish plain washer 4 10H A2J (Trivalent)
COVER
4
31 N210088736AA
BOLT
8
32 N510017592AA
Hexagon socket button head screw M4X8-10.9 A2J (Trivalent) Full thread
SPACER
4
33 KXFB09WFA00
M10
--
( KN610090756AA-11-5 )
1-F
本体部
Main Body
パーツレイアウト
Kit No.
キット品
番
Kit Name
キット名称
N610090756AA
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
M11
( KN610090756AA-11-6 )
Ref
No.
Remarks
R
1
Q'ty
1-F
本体部
Main Body
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610090756AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
BLOCK
8
1 KXFB02GJA00
BLOCK
8
2 KXFB02GKA00
BRACKET
4
3 N210022792AA
PLATE
1
4 N210022793AA
NUT-PLATE
6
5 KXFB02RMA00
DOG
2
6 KXFB02P2A00
PH-SENSOR
4
7 KXF0DYSAA00 PM-L53B-C1(DA KXF0DYSAA00)
SENSOR(800mm)
4
8 N610013309AA
URETHANE
16
9 KXF0CX7AA00 AN25-30
PIN
8
10 KXF0CXKAA00 1017003-60012
NUT
16
11 N510017897AA
Hexagon nut Type-3 Best class M12-6H-4T A2J (Trivalent)
WASHER
16
12 KXF0CPDAA00 WSSB25-12-2
SCREW
16
13 XXF12C50FT
Hexagon socket set screw M12X50 Flat point Steel Black oxide finish
BOLT
16
14 N510017308AA
Hexagon socket head cap screw M3X12-10.9 A2J (Trivalent)
BOLT
8
15 N510017381AA
Hexagon socket head cap screw M4X8-10.9 A2J (Trivalent)
BOLT
8
16 N510017344AA
Hexagon socket head cap screw M4X10-10.9 A2J (Trivalent)
BOLT
2
17 N510017346AA
Hexagon socket head cap screw M4X12-10.9 A2J (Trivalent)
BOLT
8
18 N510017475AA
Hexagon socket head cap screw M8X30-10.9 A2J (Trivalent)
BOLT
8
19 N510017480AA
Hexagon socket head cap screw M8X45-10.9 A2J (Trivalent)
WASHER
16
20 N510018478AA
Small round-plain washer 3 10H A2J (Trivalent)
WASHER
20
21 N510020099AA Thick washer for M4
PLATE
1
22 N210038831AA
BOLT
2
23 N510017351AA
Hexagon socket head cap screw M4X16-10.9 A2J (Trivalent)
DOG
2
24 KXFB02NVA00
M12
--
( KN610090756AA-11-6 )
