CM232-M - 第39页
Ref No. Remark s R 1 Q'ty 3-A X 軸接続 ユニ ッ ト X-Axi s C onn ecti on U nit ｲﾗｽﾄ No. Part No. 品 名 品番 数量 R 2 パーツリスト Kit N o . キット 品 番 Kit Name キット名称 N610012219AA Part Nam e 備 考 ｾｸｼｮﾝN o. PARTS LIST Section No. R 3 STOPPER…
3-A
X
軸接続
ユニ
ッ
ト
X-Axis Connection Unit
パーツレイアウト
Kit No.
キット品
番
Kit Name
キット名称
N610012219AA
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
M25
( KN610012219AA-08-1 )
Ref
No.
Remarks
R
1
Q'ty
3-A
X
軸接続
ユニ
ッ
ト
X-Axis Connection Unit
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610012219AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
STOPPER
1
1 KXFB02PLA01
SHEET
1
2 N210068082AA
BRACKET
1
3 KXFB02RQA00
BRACKET
1
4 N210079208AA
PLATE
1
6 KXFB02Q1A00
DOG
1
7 N210021472AA
DOG
1
8 N210022083AA
PH-SENSOR
2
9 KXF0DL6AA01 PM-L53B-C1(DA KXF0DL6AA01)
CABLE-BEAR
1
10 N510011410AA 25.4-055BB-17-24B
PIN
1
11 N510003893AA 1017003-80016
URETHANE
1
12 KXF0CSMAA00 AN25-40
BOLT
1
13 N510017195AA
Hexagon socket head cap screw M12X50-10.9 A2J (Trivalent)
BOLT
4
14 N510017557AA
SSS 003 Hexagon socket button head screw M6X16-10.9 A2J (Trivalent)
BOLT
4
15 N510017341AA
Hexagon socket head cap screw M3X8-10.9 A2J (Trivalent)
BOLT
4
16 N510017308AA
Hexagon socket head cap screw M3X12-10.9 A2J (Trivalent)
BOLT
2
17 N510017381AA
Hexagon socket head cap screw M4X8-10.9 A2J (Trivalent)
BOLT
2
18 N510017344AA
Hexagon socket head cap screw M4X10-10.9 A2J (Trivalent)
BOLT
3
19 N510017433AA
Hexagon socket head cap screw M6X16-10.9 A2J (Trivalent)
BOLT
2
20 N510017473AA
Hexagon socket head cap screw M8X25-10.9 A2J (Trivalent)
WASHER
2
21 N510018494AA
Round finish plain washer 3 10H A2J (Trivalent)
WASHER
2
22 N510018497AA
Round finish plain washer 4 10H A2J (Trivalent)
WASHER
5
23 N510018501AA
Round finish plain washer 6 10H A2J (Trivalent)
WASHER
4
24 N510018478AA
Small round-plain washer 3 10H A2J (Trivalent)
WASHER
2
25 N510018482AA
Small round-plain washer 8 10H A2J (Trivalent)
WASHER
2
26 N510020098AA Thick washer for M3
WASHER
2
27 N510020099AA Thick washer for M4
WASHER
4
28 N510020101AA Thick washer for M6
WASHER
1
29 N510020103AA Thick washer for M10
WASHER
4
30 N510018327AA Spring lock washer No.2 3 S A2J (Trivalent)
SHEET
1
32 N210130085AA
WASHER
2
33 N510021283AA MMSRB8-2.0
M26
--
( KN610012219AA-08-1 )
3-B
X
軸接続
ユニ
ッ
ト
X-Axis Connection Unit
パーツレイアウト
Kit No.
キット品
番
Kit Name
キット名称
N610012219AA
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
M27
( KN610012219AA-08-2 )
