Chapter 1 Part names and functions
Contents
1
4
2.1 Keyboard and mouse 1-4
5
3. Head assembly 1-6
3.1 Component pick-and-place head 1-6
3.2 Nozzle types 1-7
8
4. Component supply section 1-9
4.1 Supplying components from feeder plates 1-9
0
4.2.1 ATS15 main unit 1-10
4.2.2 Pallet 1-11
5.
Conveyor unit and component recognition system
1-13
6. Axis configuration 1-14
1-1
1
Part names and functions
1. Machine main unit
A standard machine has the following configurations after installation is complete. Names and functions of
major parts of the main unit are illustrated below.
Signal light
Operation panel and
data input unit
Power switch
Alarm buzzer
Safety cover
Pressure gauge
Air pressure supply/
shutoff switch
Power connection terminals
Machine main unit
Front view
USB port
Tape reel holder
(option)
Feeder setup section
Behind lower left door Behind lower right cover
23100-N8-00
1-2
1
Part names and functions
Machine main unit
Rear view
Machine-to-machine interface connector
(Behind lower left cover and lower right cover)
Operation panel buttons (option)
ATS15 (option)
23101-N8-00
