9 2 7 4 12 5 10 6 1 3 1 1 8 KHU-100-1002 3 1 SZ Assy Moving-axis
No. Part No. Part Name Q'ty Remarks Rank Level No. Part No. Part Name Q'ty Remarks Rank Level
1
KHU-M1117-00 PULL 1 /
39
KM0-M1331-01 BRACKET GAS DAMPER 1 /
2
KHU-M1320-00 COVER FR,ASSY 1 /
40
KM0-M1346-00 SHOULDER,BOLT 2 A
3
KHU-M1322-00 HOLE,HNS 1 /
41
K16-90101-10 BOLT:TP-M4X10 10 /
4
KHU-M1330-00 COVER FL, ASSY 1 /
42
90990-12J001 SCREW BIN.HEAD W/W 71
5
KHU-M1340-00 COVER FT ASSY 1 /
43
90990-12J004 SCREW BIN.HEAD W/W 12
6
KHU-M1351-00 DOOR F 1 /
44
90K41-000360 LABEL,ALERT 3
7
KHU-M1351-50
DOOR R 1 /
45
90K41-000350 LABEL,ALERT 1
8
KHU-M1352-00
BRKT HINGE
2 /
46
90K41-000380 LABEL,ALERT
2
9
KHU-M1353-00 PLATE,NUT
4
/
47
91312-03008
BOLT HEX.SOCKET HEAD 16
10
KHU-M1362-00 COVER ST 2 /
48
91312-03010 BOLT HEX.SOCKET HEAD 4
11
KHU-M1372-00 COVER,RC 1 /
49
91312-04006 BOLT HEX.SOCKET HEAD 2
12
KHU-M1377-00 COVER 2, RCB 1 /
50
91312-04008 BOLT HEX.SOCKET HEAD 8
13
KHU-M1378-00 NUT PLATE, R WINDOW 2 /
51
91312-04010 BOLT HEX.SOCKET HEAD 4
14
KHU-M1399-00 BRKT,MAGNET 2 /
52
91312-05010 BOLT HEX.SOCKET HEAD 2
15
KHU-M13D6-50 EMBLEM,YCP 1 /
53
91312-06010 BOLT HEX.SOCKET HEAD 8
16
K16-90103-00 BOLT: TP-M4X8 29 /
54
98902-03006 SCREW BINDING HEAD 4
17
K44-M1354-00
MG.CATCH (TL-152-2) 1 /
55
98902-04006 SCREW BINDING HEAD 2
18
K46-M1373-00 SHAFT HINGE 4 /
56
98702-04008 SCREW,FLAT HEAD (+) 6
19
KG2-M1372-00 PIECE B HINGE 4 /
57
98902-04008 SCREW BINDING HEAD 2
20
KV7-M1372-00 HANDLE 1 1 /
58
92902-04200 WASHER PLAIN 4
21
KW7-M13D7-01 SEAL 2(YAMAHA) 1 /
59
92902-06200 WASHER PLAIN 2
22
KGJ-M3133-00 COLLAR,DAMPER 4 /
60
95612-06100 NUT,U 2
23
KGY-M7177-00 DAMPER 3 4 A
61
KHW-M8596-00 PRESSURE GUIDE 1
24
K46-M101B-00 BROMMET 1 /
62
KHU-M1327-00 RUBBER 1 /
25
KHU-M1333-00 DOOR AIR U 1 /
63 KHU-M1324-00 BEARING 2
/
26
KHU-M1334-00 BRKT.,MAGNET 1 /
64
27
KGJ-M1350-00 SPACER,MINI LATCH 1 /
65
28
KGJ-M1351-01 PLATE,MINI LATCH 1 /
66
29
KV5-M1130-00 CATCH MG. 1 /
67
30
KW3-M1349-00 MINI LATCH 1 A
68
31
KHU-M1343-00 COVER FC2 1 /
69
32
KHU-M1345-00 HINGE 2 /
70
33
KHU-M1346-01 STAY CAMF 2 /
71
34
KHU-M1347-01 COLLAR 2 /
72
35
KHU-M1348-00 CAM FOLLOWER 2 A
73
36
90990-28J144 WASHER PLAIN 2 /
74
37
KH2-M1324-00 GRIP 1 /
75
38
KL3-M1348-10 GAS SPRING 1 A
76
KHU-100-1002
2
1
Cover
Cover
9
2
7
4
12
5
10
6
1
3
11
8
KHU-100-1002
3
1
SZ Assy
Moving-axis
No. Part No. Part Name Q'ty Remarks Rank Level No. Part No. Part Name Q'ty Remarks Rank Level
1 KHU-M2233-00 BELT, SZ 1 A
39
2 KHU-M2251-00 COVER PLATE 1 /
40
3 KW3-M2212-00 PULLY, SZ MOTOR 1 /
41
4 KHU-M653A-80 SENSOR,SZ ORG 1 B
42
5 KHU-M653C-00 SENSOR,SQUEEGEE 1U 1 B
43
6 90K55-523734 AC SERVO MOTOR 1 B
44
7 $SC4-M5A SPEED CONTROLLER 4 /
45
8
KHU-M653C-10X SENSOR,SQUEEGEE 2U
1
B
46
9 91312-04006
BOLT HEX.SOCKET HEAD 6
47
10 91312-04010 BOLT HEX.SOCKET HEAD 4 48
11 92A08-04306 SET SCREW M4X6 3 49
12 98902-03010 SCREW BINDING HEAD 2 50
13 51
14 52
15 53
16 54
17 55
18 56
19 57
20 58
21 59
22 60
23 61
24 62
25 63
26 64
27 65
28 66
29 67
30 68
31 69
32 70
33 71
34 72
35 73
36 74
37 75
38 76
KHU-100-1002
3
1
SZ Assy
Moving-axis
