番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
37H3181M 2 PLATE, END ﾌﾟﾚｰﾄ ｴﾝﾄﾞ PBRL8FN
38S1002A 2 CIR-CLIP ｻｰｸﾘｯﾌﾟ RTW15
39S4040X 1 SENSOR, PHOTO ｾﾝｻ ﾌｫﾄ EE-SPX306-W2A
40S4054Y 6 SENSOR, FIBER ｾﾝｻ ﾌｧｲﾊﾞ HPF-S053-A
41A1042T 6 AMPLIFIER ｱﾝﾌﾟ HPX-T1
43GPH2535 3 BOLT ﾎﾞﾙﾄ
44H5298A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M10X40L
45H5345A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X40L
46H5341A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X20L
47H5323A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X18L
48H5300A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15L
49H5297A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X8L
50H5289A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X12L
51H5287A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X8L
52H5286A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X6L
53K5178M SCREW, C/R PAN 小ﾈｼﾞ 十穴鍋 M3X6L
54H5274A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X6L
55N4046A SCREW, HEX SOCKET SET ﾈｼﾞ 六角穴止め M6X8L
56N4037A SCREW, HEX SOCKET SET ﾈｼﾞ 六角穴止め M5X8L
57N4018A SCREW, HEX SOCKET SET ﾈｼﾞ 六角穴止め M3X3L
58W1026A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 10M/M
59W1025A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 8M/M
60W1024A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M
61W1023A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M
62W1022A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M
63W1021A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M
64W1045A WASHER, FLAT ﾜｯｼｬ 平 4W-6
65W1043A WASHER, FLAT ﾜｯｼｬ 平 4W-4
66W1042A WASHER, FLAT ﾜｯｼｬ 平 4W-3
67W1012A WASHER, CONICAL ﾜｯｼｬ 皿 M-5-L
68N1089A NUT, HEX ﾅｯﾄ 六角 M8 P=1.25
69N1091A NUT, HEX ﾅｯﾄ 六角 M8-L
70N1082A NUT, HEX ﾅｯﾄ 六角 M5 P=0.8
71WPM0401 1 SEAL ｼｰﾙ
72W1047A WASHER, FLAT ﾜｯｼｬ 平 4W-10 ･
19-3
19.
第17ｽﾃｰｼｮﾝ(ﾉｽﾞﾙ切換前確認),第18ｽﾃｰｼｮﾝ(ﾉｽﾞﾙ切換),第19ｽﾃｰｼｮﾝ(ﾉｽﾞﾙ切換前確認)(CSPM)
19.Station 17(Nozzle pre change check),Station 18(Nozzle check),Station 19(Nozzle post change check)(CSPM)
19.第17ｽﾃｰｼｮﾝ(ﾉｽﾞﾙ切換前確認),第18ｽﾃｰｼｮﾝ(ﾉｽﾞﾙ切換),第19ｽﾃｰｼｮﾝ(ﾉｽﾞﾙ切換前確認)
CP-643ME PARTS LIST ver04
Station 17(Nozzle pre change check),Station 18(Nozzle check),Station 19(Nozzle post change check)(CSPM)
20.ﾃﾞﾊﾞｲｽﾃｰﾌﾞﾙD1(1∼70) Device table D1(1∼70)(CSSD)
CP-643ME PARTS LIST ver04
20-1
20.ﾃﾞﾊﾞｲｽﾃｰﾌﾞﾙD1(1∼70)(CSSD)
20.Device table D1(1∼70)(CSSD)
Ref.33-7
Ref.31-1
Ref.31-1
Ref.31-1
Ref.31-1
208
176
165
175
161
175
175
161
183
162
176
167
175
161
13
13
B
A
139
26
x14
136
118
104
97
96
133
92
78
100
101
134
105
135
136
78
101
100
101
128
97
96
120
97
129
100
137
8
99
77
13
12
3
76
99
6
7
5
8
9
11
98
60
79
112
60
98
116
58
59
59
112
112
61
117
57
12
13
73
9
108
91
42
78
101
100
40
96
97
73
73
41
39
80
103
2
80
103
38
113
113
37
35
36
34
32
74
74
33
17
4
107
130
13
14
16
81
103
72
94
31
76
101
30
1
27
28
29
106
87
26
25
24
23
22
106
88
21
20
19
18
B
B
132
104
105
110
83
105
104
104
105
85
104
80
125
97
127
127
125
97
124
124
105
104
80
105
122
121
105
104
126
48
109
110
131
76
101
72
94
62
119
76
119
76
72
77
94
114
63
51
50
54
53
52
56
55
64
93
110
65
45
103
80
75
102
84
103
46
86
103
48
84
103
47
111
66
67
70
106
89
69
71
108
90
123
A
A
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
1WSD0553 1 HOLDER, BEARING ﾎﾙﾀﾞ ﾍﾞｱﾘﾝｸﾞ
2WSD5025 1 SLIDE ｽﾗｲﾄﾞ
3WSD1051 1 HOLDER, BEARING ﾎﾙﾀﾞ ﾍﾞｱﾘﾝｸﾞ
4WSD5010 1 BALL SCREW ﾎﾞｰﾙﾈｼﾞ
5H4159A 1 BEARING ﾍﾞｱﾘﾝｸﾞ 20TAC47BDB
6WSD0440 1 COLLAR ｶﾗｰ
7WSD0450 1 COLLAR ｶﾗｰ
8WSD0473 2 COVER, DUSTPROOF ｶﾊﾞｰ 防塵
9WSD1040 2 COLLAR ｶﾗｰ
11N1040A 1 NUT, LOCK ﾅｯﾄ ﾛｯｸ WBK20L-31 注1. Note.1
12WSD1020 2 STOPPER ｽﾄｯﾊﾟ
13WSD0421 8 COLLAR ｶﾗｰ
14WSD0862 1 STOPPER ｽﾄｯﾊﾟ
16WSD0393 1 RETAINER, BEARING 押え ﾍﾞｱﾘﾝｸﾞ
17R2059E 1 RING, LOCKING ﾘﾝｸﾞ 締結 SCE210 22X32
18CSSD3040 1 BELT, TIMING ﾍﾞﾙﾄ ﾀｲﾐﾝｸﾞ
19WSD0081 1 PULLEY ﾌﾟｰﾘ
20. 1 NUT, LOCK ﾅｯﾄ ﾛｯｸ WBK25L-31 注1. Note.1
21WSD0351 1 RETAINER, BEARING 押え ﾍﾞｱﾘﾝｸﾞ
22WSD0361 1 COLLAR ｶﾗｰ
23H4161A 1 BEARING ﾍﾞｱﾘﾝｸﾞ 25TAC62DB
24WSD0372 1 COLLAR ｶﾗｰ
25WSD0381 1 COLLAR ｶﾗｰ
26WSD0411 1 COLLAR ｶﾗｰ
27S1010A 1 CIR-CLIP ｻｰｸﾘｯﾌﾟ RTW42
28H4248A 1 BEARING ﾍﾞｱﾘﾝｸﾞ 6004ZZ
29WSD0341 1 CAP ｷｬｯﾌﾟ
30WSD0611 1 PLATE, SW ﾌﾟﾚｰﾄ SW
31S3138T 1 SW, PHOTOELECTRIC SW 光電 PZ2-51
32WSD5210 1 NAMEPLATE, PRESSURE 銘板 ｱﾙﾐ
33WSD5081 1 PLATE, REFERENCE ﾌﾟﾚｰﾄ 基準 注2. Note.2
34WSD5091 1 PLATE, REFERENCE ﾌﾟﾚｰﾄ 基準 注2. Note.2
35WSD5061 1 PLATE, REFERENCE ﾌﾟﾚｰﾄ 基準 注2. Note.2
36WSD5071 1 PLATE, REFERENCE ﾌﾟﾚｰﾄ 基準 注2. Note.2
37WSD5101 1 CLAMPER ｸﾗﾝﾊﾟ
38WSD5111 1 CLAMPER ｸﾗﾝﾊﾟ
20.ﾃﾞﾊﾞｲｽﾃｰﾌﾞﾙD1(1∼70) Device table D1(1∼70)(CSSD)
CP-643ME PARTS LIST ver04
20-2
20.ﾃﾞﾊﾞｲｽﾃｰﾌﾞﾙD1(1∼70)(CSSD)
20.Device table D1(1∼70)(CSSD)
