番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
40WSD0300 1 LEVER ﾚﾊﾞｰ
41WSD0291 1 PIN, PIVOT ﾋﾟﾝ 支点
42WSD1030 1 PIN, ROLLER ﾋﾟﾝ ﾛｰﾗ
43WSD0930 1 SPRING ｽﾌﾟﾘﾝｸﾞ
44H4437A 1 BEARING, MINIATURE ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ L-1360ZZ
45H2048A 1 PIN, SPRING ﾋﾟﾝ ｽﾌﾟﾘﾝｸﾞ 3ﾟX10
46WSD5500 1 PLATE, TIGHTENING ﾌﾟﾚｰﾄ 締付け
47WSD5281 1 PLATE, SW ﾌﾟﾚｰﾄ SW
48WSD5271 1 PLATE, SW ﾌﾟﾚｰﾄ SW
49WSD5071 1 PLATE, REFERENCE ﾌﾟﾚｰﾄ 基準 注2.Note.2
50WSD5061 1 PLATE, REFERENCE ﾌﾟﾚｰﾄ 基準 注2.Note.2
51WSD5111 1 CLAMPER ｸﾗﾝﾊﾟ
52WSD5101 1 CLAMPER ｸﾗﾝﾊﾟ
53WSD5081 1 PLATE, REFERENCE ﾌﾟﾚｰﾄ 基準 注2.Note.2
54WSD5091 1 PLATE, REFERENCE ﾌﾟﾚｰﾄ 基準 注2.Note.2
55WSD5131 1 GUIDE, HOLDER ｶﾞｲﾄﾞ 受け
56WSD5141 1 GUIDE, HOLDER ｶﾞｲﾄﾞ 受け
57WSD0641 50 BOLT ﾎﾞﾙﾄ
58WSD0014 50 CLAMPER ｸﾗﾝﾊﾟ
59WSD0652 50 SPRING ｽﾌﾟﾘﾝｸﾞ
60WSD5051 1 BEARING, SLIDE ﾍﾞｱﾘﾝｸﾞ ｽﾗｲﾄﾞ
61WSD5041 1 BEARING, SLIDE ﾍﾞｱﾘﾝｸﾞ ｽﾗｲﾄﾞ
62WSD0620 2 SPACER ｽﾍﾟｰｻ
63WSD0132 2 PLATE, REFERENCE ﾌﾟﾚｰﾄ 基準
64WSD5471 1 PLATE, SW ﾌﾟﾚｰﾄ SW
65S4040Z 1 SENSOR, PHOTO ｾﾝｻ ﾌｫﾄ EE-SPX406-W2A
67R5025T 50 ROLLER, NEEDLE ﾛｰﾗ ﾆｰﾄﾞﾙ 5ﾟX10
68H4435T 50 BEARING, MINIATURE ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ L-1150ZZ
69WSD5220 1 NAMEPLATE, ALUMINUM 銘板 ｱﾙﾐ
70WSD5210 1 NAMEPLATE 銘板
71WSD0671 1 BELT, TIMING ﾍﾞﾙﾄ ﾀｲﾐﾝｸﾞ
72WSD5351 1 STEADY BRACE 振れ止め
73WSD0841 2 STEADY BRACE 振れ止め
74MPD5140 32 COLLAR ｶﾗｰ
75WSD5342 1 HOLDER, REEL ﾎﾙﾀﾞ ﾘｰﾙ
76WSD5330 1 SEAL ｼｰﾙ
21.ﾃﾞﾊﾞｲｽﾃｰﾌﾞﾙD2(71∼140) Device table D2(71∼140)(CSSD)
CP-643ME PARTS LIST ver04
21-3
21.ﾃﾞﾊﾞｲｽﾃｰﾌﾞﾙD2(71∼140)(CSSD)
21.Device table D2(71∼140)(CSSD)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
77K5178T SCREW, C/R PAN 小ﾈｼﾞ 十穴鍋 M3X12L
78H5287A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X8L
79H5289A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X12L
80H5290A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X15L
81K5258A SCREW, HEX SOCKET BUTTON 小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M4X25L
82N4038A SCREW, HEX SOCKET SET ﾈｼﾞ 六角穴止め M5X10L
83H5299A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X12L
84H5300A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15L
85H5302A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X20L
86K5262N SCREW, HEX SOCKET BUTTON 小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M6X35L
87H5321A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X12L
88H5323A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X18L
89H5328A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X35L
90H5326A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X25L
91H5327A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X30L
92H5332A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X50L
93H5340A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X15L
94H5341A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X20L
95H5342A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X25L
96H5362A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M10X35L
97H5364A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M10X45L
98H5391A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M12X40L
99W1042A WASHER, FLAT ﾜｯｼｬ 平 4W-3
100W1043A WASHER, FLAT ﾜｯｼｬ 平 4W-4
102W1022A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M
103W1044A WASHER, FLAT ﾜｯｼｬ 平 4W-5
104W1012A WASHER, CONICAL ﾜｯｼｬ 皿 M-5-L
105W1023A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M
106W1013A WASHER, CONICAL ﾜｯｼｬ 皿 M-6-H
107W1024A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M
108W1014A WASHER, CONICAL ﾜｯｼｬ 皿 M-8-H
109W1025A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 8M/M
110W1026A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 10M/M
111W1048A WASHER, FLAT ﾜｯｼｬ 平 4W-12
112W1027A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 12M/M
113N1079A NUT, HEX ﾅｯﾄ 六角 M4
21.ﾃﾞﾊﾞｲｽﾃｰﾌﾞﾙD2(71∼140) Device table D2(71∼140)(CSSD)
CP-643ME PARTS LIST ver04
21-4
21.ﾃﾞﾊﾞｲｽﾃｰﾌﾞﾙD2(71∼140)(CSSD)
21.Device table D2(71∼140)(CSSD)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
114N1082A NUT, HEX ﾅｯﾄ 六角 M5
115N1073T NUT, HEX ﾅｯﾄ 六角 M12
117H4323A 1 BEARING, DRY ﾍﾞｱﾘﾝｸﾞ ﾄﾞﾗｲ MB0608DU
118WSD5121 2 CLAMPER ｸﾗﾝﾊﾟ
120S4040X 1 SENSOR, PHOTO ｾﾝｻﾌｫﾄ EE-SPX306-W2A
122WSD5441 1 STEADY BRACE 振れ止め
123WSD0900 2 STEADY BRACE 振れ止め
124AWSD5480 1 CLAMPER ｸﾗﾝﾊﾟ
125WSD4030 106 RETAINER, RAIL 押え ﾚｰﾙ
126WSD4040 1 COVER, SAFETY ｶﾊﾞｰ 安全
127CSPZ3151 1 COVER ｶﾊﾞｰ
128CSPZ3160 1 COVER ｶﾊﾞｰ
129CSPZ3170 1 COVER ｶﾊﾞｰ
130WPZ3472 2 SPRING, PLATE ｽﾌﾟﾘﾝｸﾞ 板
131H5285A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X5L
133W1045A WASHER, FLAT ﾜｯｼｬ 平 4W-6
134WPZ3550 2 PLATE, TIGHTENING ﾌﾟﾚｰﾄ 締付け
135H5392A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M12X45L
136H5343A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X30L
137H2087A 4 PIN, TAPER ﾋﾟﾝ ﾃｰﾊﾟ 1P M8X50L ﾀｯﾌﾟﾄｳｼ
138N1085A NUT, HEX ﾅｯﾄ 六角 M6
139W1051A WASHER, FLAT ﾜｯｼｬ 平 6M/MX1.6X125
140K5262H SCREW, HEX SOCKET BUTTON 小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M6X20L
141W1015A WASHER, CONICAL ﾜｯｼｬ 皿 M-10-H
142AWSD5510 1 PLATE, REFERENCE ﾌﾟﾚｰﾄ 基準
注1.(4)WSD5010の付属品
Note.1:Inserted into (No.4)WSD5010.
注2.ｾｯﾄ納入の場合D1軸､D2軸合計8個ｾｯﾄのこと｡
Note.2:When purchasing sets, eight are required(D1-and D-2axis).
21.ﾃﾞﾊﾞｲｽﾃｰﾌﾞﾙD2(71∼140) Device table D2(71∼140)(CSSD)
CP-643ME PARTS LIST ver04
21-5
21.ﾃﾞﾊﾞｲｽﾃｰﾌﾞﾙD2(71∼140)(CSSD)
21.Device table D2(71∼140)(CSSD)
