番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
38WPA5062 1 PULLEY ﾌﾟｰﾘ
39H45190 1 BELT, TIMING ﾍﾞﾙﾄ ﾀｲﾐﾝｸﾞ 728-8YU-20
40WPA5101 1 BELT, TIMING ﾍﾞﾙﾄ ﾀｲﾐﾝｸﾞ
41H4519W 1 BELT, TIMING ﾍﾞﾙﾄ ﾀｲﾐﾝｸﾞ 464-8YU-25
42WPA5091 1 BELT, TIMING ﾍﾞﾙﾄ ﾀｲﾐﾝｸﾞ
43WPA0980 1 COLLAR ｶﾗｰ
44WPA5081 3 PULLEY ﾌﾟｰﾘ
45WPA5530 1 COLLAR ｶﾗｰ
46WPA0221 1 COLLAR ｶﾗｰ
47WPA0210 1 HOLDER, BEARING ﾎﾙﾀﾞ ﾍﾞｱﾘﾝｸﾞ
48WPA1833 1 SHAFT, CAM ｼｬﾌﾄ ｶﾑ
49WPA0362 1 KEY ｷｰ
50WPA0251 2 COLLAR ｶﾗｰ
51WPA1071 1 GEAR, BEVEL ｷﾞﾔ ﾍﾞﾍﾞﾙ
52WPA1300 3 KEY ｷｰ
53H4315T 2 BEARING, DRY ﾍﾞｱﾘﾝｸﾞ ﾄﾞﾗｲ 70B-2520
54WPA1060 2 GEAR, PINION ｷﾞﾔ ﾋﾟﾆｵﾝ
55WPA1041 1 COLLAR ｶﾗｰ
56WPA0321 1 COLLAR ｶﾗｰ
57WPA0400 1 SPRING ｽﾌﾟﾘﾝｸﾞ
58WPA0311 1 COLLAR ｶﾗｰ
59WPA1052 1 SHAFT ｼｬﾌﾄ
61WPA1010 2 KEY ｷｰ
62WPA1281 1 HOUSING ﾊｳｼﾞﾝｸﾞ
63H4315H 2 BEARING, DRY ﾍﾞｱﾘﾝｸﾞ ﾄﾞﾗｲ 70B-2020
66WPA1090 1 COLLAR ｶﾗｰ
68WPA0082 1 BKT BKT
69WPA0202 1 BKT, ADJUSTING BKT 調整
76WPA1252 1 HANDLE ﾊﾝﾄﾞﾙ
77WPA1262 1 BKT BKT
78WPA1642 1 SPRING, PLATE ｽﾌﾟﾘﾝｸﾞ 板
79N4036H SCREW, HEX SOCKET SET ﾈｼﾞ 六角穴止め M5X5L
80N1100A NUT, HEX ﾅｯﾄ 六角 M16
81W1029A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 16M/M
82W1027A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 12M/M
83W1026A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 10M/M
25.カムボックス 1 Cam box 1(CSPA)
CP-643ME PARTS LIST ver04
25-3
25.カムボックス 1(CSPA)
25.Cam box 1(CSPA)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
84W1025A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 8M/M
85W1024A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M
86W1022A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M
87W1048A WASHER, FLAT ﾜｯｼｬ 平 4W-12
88W1047A WASHER, FLAT ﾜｯｼｬ 平 4W-10
89W1016A WASHER, CONICAL ﾜｯｼｬ 皿 M-12-H
90W1015A WASHER, CONICAL ﾜｯｼｬ 皿 M-10-H
91W1014A WASHER, CONICAL ﾜｯｼｬ 皿 M-8-H
92W1013A WASHER, CONICAL ﾜｯｼｬ 皿 M-6-H
93W1012A WASHER, CONICAL ﾜｯｼｬ 皿 M-5-L
94W1011A WASHER, CONICAL ﾜｯｼｬ 皿 M-4-L
95H5394A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M12X50L
96H5391A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M12X40L
97H5365A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M10X50L
98H5361A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M10X30L
99H5359A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M10X20L
100H5349A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X60L
101H5348A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X55L
102H5347A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X50L
103H5340A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X15L
104H5332A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X50L
105H5324A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X20L
106H5322A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X15L
107H5321A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X12L
108H5302A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X20L
109H5288A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X10L
111H5299A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X12L
112WPA1650 1 SCREW ﾈｼﾞ
114W1023A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M
120H5360A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M10X25L
121WPA0073 1 BKT BKT
122WPA0351 1 WASHER ﾜｯｼｬ
123WPA1021 2 WASHER ﾜｯｼｬ
124H5301A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X18L
134WPA0272 1 SCALE 目盛り
135WPA1732 1 GUIDE ｶﾞｲﾄﾞ
25.カムボックス 1 Cam box 1(CSPA)
CP-643ME PARTS LIST ver04
25-4
25.カムボックス 1(CSPA)
25.Cam box 1(CSPA)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
136WPA1740 1 PLATE ﾌﾟﾚｰﾄ
137WPA1750 1 PLATE ﾌﾟﾚｰﾄ
138WPA1760 1 BKT BKT
139WPA1681 1 BKT BKT
140WPA1671 1 BASE ﾍﾞｰｽ
141WPA1771 2 SPRING , PLATE ｽﾌﾟﾘﾝｸﾞ 板
142S31970 1 SW, LIMIT SW ﾘﾐｯﾄ XCS-A501
143S31971 1 SW, LIMIT SW ﾘﾐｯﾄ XCS-Z01
144H5286A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X6L
145H5289A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X12L
146H5307A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X40L
147H5326A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X25L
148. BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M10X12L
152N1096A NUT, HEX ﾅｯﾄ六角 M12
153WPA4050 1 STOPPER ｽﾄｯﾊﾟ
154WPA4040 1 SPRING ｽﾌﾟﾘﾝｸﾞ
155WPA4010 1 HOUSING ﾊｳｼﾞﾝｸﾞ
156WPA4071 1 SHAFT ｼｬﾌﾄ
161WPA4060 1 COLLAR ｶﾗｰ
162WPA1820 1 WASHER ﾜｯｼｬ ･
25.カムボックス 1 Cam box 1(CSPA)
CP-643ME PARTS LIST ver04
25-5
25.カムボックス 1(CSPA)
25.Cam box 1(CSPA)
