番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
121H4445A 10 BEARING, MINIATURE ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ LF-1050ZZ
122H4451A 2 BEARING, MINIATURE ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ LF-1680ZZ
123H4440A 5 BEARING, MINIATURE ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ L-1910ZZ
124S3033A 2 SPROCKET ｽﾌﾟﾛｹｯﾄ RS25-13T 1ｶﾞﾀ
125S3034A 6 SPROCKET ｽﾌﾟﾛｹｯﾄ RS25-13T 2ｶﾞﾀ
126S1022A 5
CIR-CLIP
ｻｰｸﾘｯﾌﾟ ST-EW-4
127W10022 2 WASHER ﾜｯｼｬ TL182(No.2)
129N1014A 1
NUT, FINE U
ﾅｯﾄ ﾌｧｲﾝU AN00
131CSQC2710 1 BKT BKT
132CSQC2670 1 BRIDGE ﾌﾞﾘｯｼﾞ
133CSQC2680 1 BRIDGE ﾌﾞﾘｯｼﾞ
137T2034K 1 CHAIN ﾁｪｰﾝ RS25NP 284ﾘﾝｸ
138T2040K 1 CHAIN ﾁｪｰﾝ RS25NP 416ﾘﾝｸ
139T2023A 1 CHAIN ﾁｪｰﾝ RS25NP 88ﾘﾝｸ
144S3141B 1 SW, PHOTOELECTRIC SW 光電 DL-S3R
152CSQC2690 1 BRIDGE ﾌﾞﾘｯｼﾞ
154W1021A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M
155W1022A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M
156W1023A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M
157W1024A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M
158W1025A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 8M/M
159W1043A
WASHER, FLAT
ﾜｯｼｬ 平
4W-4
160W1044A
WASHER, FLAT
ﾜｯｼｬ 平
4W-5
162W1011A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-4-L
163W1012A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-5-L
164W1013A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-6-H
167N4019T
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め
M3X5L
168N4026A
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め
M4X4L
169N4027A
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め
M4X5L
170N1080A
NUT, HEX
ﾅｯﾄ 六角
M4 P=0.7
171N1085A
NUT, HEX
ﾅｯﾄ 六角
M6 P=1.0
172CSQC1230 8
NUT, HEX
ﾅｯﾄ 六角
173K5209A
SCREW, TRUSS
小ﾈｼﾞ ﾄﾗｽ M4X8L
174K5214A
SCREW, TRUSS
小ﾈｼﾞ ﾄﾗｽ M5X8L
176K5261A
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M5X10L
177K5178T
SCREW, C/R PAN
小ﾈｼﾞ 十穴鍋
M3X12L
40.1.インコンベア(逆流れ)In conveyor(Right-to-left board flow)(Option)(CSQC)
CP-643ME PARTS LIST ver04
40-4
40.1.インコンベア(逆流れ)(Option)(CSQC)
40.1.In conveyor(Right-to-left board flow)(Option)(CSQC)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
178
SCREW, C/R PAN
小ﾈｼﾞ 十穴鍋
M3X14L
180H5285A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X5L
181K5359H
SCREW, HEX SOCKET COUNTERSUNK
小ﾈｼﾞ 六角穴皿
M4X10L
182H5181A
BOLT, HEX
ﾎﾞﾙﾄ 六角
M6X12L
183H5276A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X10L
185H5287A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X8L
186H5288A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X10L
189H5291A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X18L
191H5297A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X8L
192H5298A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X10L
193H5299A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X12L
194H5300A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X15L
197H5309A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X50L
198H5320A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X10L
199H5321A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X12L
200H5323A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X18L
201H5324A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X20L
202H5326A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X25L
203H5330A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X40L
204H5342A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M8X25L
205H5296Z
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X100L
206H5323A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X18L
208CSQC2420 1 BKT BKT
209K53325 2 CONTROLLER, SPEED ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ JSC4-M5A
210Y3044A 2 UNION ﾕﾆｵﾝ M-5E
211Y3061D 2 UNION, HALF ﾕﾆｵﾝ ﾊｰﾌ KJS04-M5
212CSQC1060 2 BLOCK ﾌﾞﾛｯｸ
216.
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M8X18L
217W1014A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-8-H
219CSQC1210 8 WASHER, SPHERICAL ﾜｯｼｬ 球面
220CSQC1220 8 WASHER, SPHERICAL ﾜｯｼｬ 球面
221CSQC2821 1 PLATE, GUIDE ﾌﾟﾚｰﾄ ｶﾞｲﾄﾞ
222CSQC2831 1 PLATE, GUIDE ﾌﾟﾚｰﾄ ｶﾞｲﾄﾞ
223K52564
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M4X5L
225CSQC7242 1 JOINT ｼﾞｮｲﾝﾄ
226CSQC3200 1 NAMEPLATE 銘板 French
40.1.インコンベア(逆流れ)In conveyor(Right-to-left board flow)(Option)(CSQC)
CP-643ME PARTS LIST ver04
40-5
40.1.インコンベア(逆流れ)(Option)(CSQC)
40.1.In conveyor(Right-to-left board flow)(Option)(CSQC)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
227CSQC7231 1 HOUSING ﾊｳｼﾞﾝｸﾞ
40.1.インコンベア(逆流れ)In conveyor(Right-to-left board flow)(Option)(CSQC)
CP-643ME PARTS LIST ver04
40-6
40.1.インコンベア(逆流れ)(Option)(CSQC)
40.1.In conveyor(Right-to-left board flow)(Option)(CSQC)
