番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
1CSQC1042 1 PLATE ﾌﾟﾚｰﾄ
2CSQC0041 1 PLATE ﾌﾟﾚｰﾄ
3CSQC0051 1 PLATE ﾌﾟﾚｰﾄ
4CSQC1171 1 BRIDGE ﾌﾞﾘｯｼﾞ
7CSQC0132 1 STOPPER ｽﾄｯﾊﾟ
8CSQC0142 1 STOPPER ｽﾄｯﾊﾟ
16CSQC1200 3 BOLT, STUD ﾎﾞﾙﾄ ｽﾀｯﾄﾞ
17CSQC7460 2 HOLDER 受け
18CSQC7690 1 COVER ｶﾊﾞｰ
19CSQC7700 1 COVER ｶﾊﾞｰ
32CSQC0511 1 COVER, BELT ｶﾊﾞｰ ﾍﾞﾙﾄ
42CSQC3050 1 PLATE ﾌﾟﾚｰﾄ
43CSQC3060 1 PLATE ﾌﾟﾚｰﾄ
44CSQC3030 2 GUIDE, BELT ｶﾞｲﾄﾞ ﾍﾞﾙﾄ
45CSQC3040 2 GUIDE, BELT ｶﾞｲﾄﾞ ﾍﾞﾙﾄ
46CSQC3080 2 BELT ﾍﾞﾙﾄ
50CSQC3170 1 NAMEPLATE 銘板
51CSQC3190 1 PLATE, SIDE ﾌﾟﾚｰﾄ ｻｲﾄﾞ
52CSQC3330 1 PLATE, SIDE ﾌﾟﾚｰﾄ ｻｲﾄﾞ
62MQC1061 4 PULLEY ﾌﾟｰﾘ
63MQC1073 1 SEAL ｼｰﾙ
64MQC1292 4 PULLEY ﾌﾟｰﾘ
65MQC1300 1 SEAL ｼｰﾙ
66MQC1430 2 BKT BKT
67MQC3113 2 BALL SCREW ﾎﾞｰﾙﾈｼﾞ
68MQC3293 2 COVER ｶﾊﾞｰ
69MQC3313 1 GUIDE ｶﾞｲﾄﾞ
70MQC3323 1 GUIDE ｶﾞｲﾄﾞ
71CSQC1050 2 SHAFT ｼｬﾌﾄ
72MQC3421 2 BKT BKT
74MQC3451 1 HOLDER ﾎﾙﾀﾞ
75MQC3461 1 SHAFT ｼｬﾌﾄ
76MQC3501 2 PULLEY ﾌﾟｰﾘ
77MQC3901 8 SPACER ｽﾍﾟｰｻ
78MQC4130 2 SHAFT ｼｬﾌﾄ
79CLC9051 2 HOLDER ﾎﾙﾀﾞ
41.1.アウトコンベア(逆流れ)Out conveyor(Right-to-left board flow)(Option)(CSQC)
41-2
41.1.アウトコンベア(逆流れ)(Option)(CSQC)
41.1.Out conveyor(Right-to-left board flow)(Option)(CSQC)
CP-643ME PARTS LIST ver04
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
80GVC0141 2 COLLAR ｶﾗｰ
81GVC0320 2 COLLAR ｶﾗｰ
82GVC0350 4 COLLAR ｶﾗｰ
83GVC2262 2 SPROCKET ｽﾌﾟﾛｹｯﾄ
84GVC2311 1 SHAFT ｼｬﾌﾄ
85GVC2320 1 SHAFT ｼｬﾌﾄ
87CSQC1071 2 HOLDER ﾎﾙﾀﾞ
88IQC6041 4 RETAINER, BEARING 押え ﾍﾞｱﾘﾝｸﾞ
89IQC6062 23 NUT ﾅｯﾄ
90IQC6072 56 NUT ﾅｯﾄ
91IQC6291 2 NUT ﾅｯﾄ
92JQC3672 6 NUT, SQUARE ﾅｯﾄ 四角
94M5063H 2
MOTOR, REVERSIBLE
ﾓｰﾀ ﾘﾊﾞｰｼﾌﾞﾙ RM-H6A6ZMR244
95H4001T 2 HEAD, GEAR ﾍｯﾄﾞ ｷﾞﾔ 6GHA7.5A-Y-1
96H4429M 2
BEARING, BALL
ﾍﾞｱﾘﾝｸﾞ ﾎﾞｰﾙ LMK20UU
97H4123A 1
BEARING
ﾍﾞｱﾘﾝｸﾞ UFL000
98H4445A 8 BEARING, MINIATURE ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ LF-1050ZZ
99H4451A 2 BEARING, MINIATURE ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ LF-1680ZZ
100H4440A 5 BEARING, MINIATURE ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ L-1910ZZ
101T2030T 1 CHAIN ﾁｪｰﾝ RS25NP 266ﾘﾝｸ
102T2022B 1 CHAIN ﾁｪｰﾝ RS25NP 68ﾘﾝｸ
103S3033A 2 SPROCKET ｽﾌﾟﾛｹｯﾄ RS25-13T 1ｶﾞﾀ
104S3034A 5 SPROCKET ｽﾌﾟﾛｹｯﾄ RS25-13T 2ｶﾞﾀ
105S1022A 4
CIR-CLIP
ｻｰｸﾘｯﾌﾟ ST-EW-4
106W10022 2 WASHER ﾜｯｼｬ TL182(No.2)
108WQC4081 1 BKT BKT
109CSQC1160 1 BRIDGE ﾌﾞﾘｯｼﾞ
110S3141B 1 SW, PHOTOELECTRIC SW 光電 DL-S3R
122IQC6301 8 NUT ﾅｯﾄ
123WQC0111 1 BKT BKT
125W1022A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M
126W1023A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M
127W1024A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M
128W1043A
WASHER, FLAT
ﾜｯｼｬ 平         
4W-4
129W1044A
WASHER, FLAT
ﾜｯｼｬ 平         
4W-5
130W1045A
WASHER, FLAT
ﾜｯｼｬ 平         
4W-6
41.1.アウトコンベア(逆流れ)Out conveyor(Right-to-left board flow)(Option)(CSQC)
41-3
41.1.アウトコンベア(逆流れ)(Option)(CSQC)
41.1.Out conveyor(Right-to-left board flow)(Option)(CSQC)
CP-643ME PARTS LIST ver04
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
131W1011A
WASHER, CONICAL
ﾜｯｼｬ 皿         
M-4-L
132W1013A
WASHER, CONICAL
ﾜｯｼｬ 皿         
M-6-H
136N4015A
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め       
M4X4L
137N4027A
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め       
M4X5L
138N1080A
NUT, HEX
ﾅｯﾄ 六角         
M4 P=0.7
139N1082A
NUT, HEX
ﾅｯﾄ 六角         
M5 P=0.8
140N1085A
NUT, HEX
ﾅｯﾄ 六角         
M6 P=1.0
141CSQC1230
NUT, HEX
ﾅｯﾄ 六角    
142K5208A
SCREW, TRUSS
小ﾈｼﾞ ﾄﾗｽ M4X6L
144K5261A
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ   M5X10L
145K5178T
SCREW, C/R PAN
小ﾈｼﾞ 十穴鍋        
M3X12L
146K5214A
SCREW, TRUSS
小ﾈｼﾞ ﾄﾗｽ M5X8L
149K5359H
SCREW, HEX SOCKET COUNTERSUNK
小ﾈｼﾞ 六角穴皿       
M4X10L
150H5181A
BOLT, HEX
ﾎﾞﾙﾄ 六角         
M6X12L
152H5287A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M4X8L
153H5288A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M4X10L
156H5291A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M4X18L
158H5296X
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M4X90L
159H5298A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M5X10L
163H5320A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M6X10L
164H5321A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M6X12L
165H5322A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M6X15L
166H5323A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M6X18L
167H5324A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M6X20L
168H5330A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M6X40L
169H5342A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M8X25L
170W1025A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 8M/M
171CSQC1190 1 BOLT, STUD ﾎﾞﾙﾄ ｽﾀｯﾄﾞ
172CSQC1181 1 SPACER ｽﾍﾟｰｻ
173CSQC1060 2 BLOCK ﾌﾞﾛｯｸ
175H5309A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M5X50L
176.
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M8X18L
177W1014A
WASHER, CONICAL
ﾜｯｼｬ 皿         
M-8-H
179CSQC1210 8 WASHER, SPHERICAL ﾜｯｼｬ 球面      
180CSQC1220 8 WASHER, SPHERICAL ﾜｯｼｬ 球面   
181CSQC1361 1 PLATE, GUIDE ﾌﾟﾚｰﾄ ｶﾞｲﾄﾞ
41.1.アウトコンベア(逆流れ)Out conveyor(Right-to-left board flow)(Option)(CSQC)
41-4
41.1.アウトコンベア(逆流れ)(Option)(CSQC)
41.1.Out conveyor(Right-to-left board flow)(Option)(CSQC)
CP-643ME PARTS LIST ver04
