番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
37CSQC1421 1 POSITIONING 位置決め
38CSQC1430 1 PIN ﾋﾟﾝ
39CSQC1440 2 BAR, GUIDE ﾊﾞｰ ｶﾞｲﾄﾞ
40CSQC1450 1 LEVER ﾚﾊﾞｰ
41CSQC1460 1 NAMEPLATE 銘板
42CSQC2270 2 RETAINER 押え
43CSQC3360 1 BKT, SENSOR BKT ｾﾝｻ
44CSQC4702 1 CABLE ｹｰﾌﾞﾙ
45CSQC5610 1 GUIDE ｶﾞｲﾄﾞ
46CSQC5630 1 STOPPER ｽﾄｯﾊﾟ
47CSQC5640 1 RAIL ﾚｰﾙ
48CSQC5650 1 BKT BKT
49CSQC5670 1 SHAFT ｼｬﾌﾄ
50CSQC5681 1 PLATE, LIFTER ﾌﾟﾚｰﾄ ﾘﾌﾀ
51CSQC5691 1 PLATE, LIFTER ﾌﾟﾚｰﾄ ﾘﾌﾀ
52CSQC5710 1 COLLAR ｶﾗｰ
53CSQC5720 1 PLATE ﾌﾟﾚｰﾄ
54CSQC5860 1 SCALE ｽｹｰﾙ
55CSQC5870 1 PLATE, LOCATING ﾌﾟﾚｰﾄ 位置決め
56CSQC5930 1 BKT BKT
57CSQC5940 1 BKT BKT
58IQC6062 12 NUT ﾅｯﾄ
59JQC3672 8 角ﾅｯﾄ
60S20657 1 CYLINDER ｼﾘﾝﾀﾞ CDAS32X15-ZE155B2
61H4429K 2 BEARING, BALL ﾍﾞｱﾘﾝｸﾞ ﾎﾞｰﾙ LMK16LUU
62S3020W 4 SPRING ｽﾌﾟﾘﾝｸﾞ WF12-35
63H4128Z 4 BEARING ﾍﾞｱﾘﾝｸﾞ SM6UU
64H30715 4 BUSHING ﾌﾞｯｼｭ MB1208DU
65H4476L 1 BELT ﾍﾞﾙﾄ 97.5-1.5GT-3
66S1021A 1
CIR-CLIP
ｻｰｸﾘｯﾌﾟ ST-EW-3
67H4441A 1
BEARING, MINIATURE
ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ LF-840ZZ
68H4443A 1
BEARING, MINIATURE
ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ LF-850ZZ
69S3020Y 1 SPRING ｽﾌﾟﾘﾝｸﾞ WH10-15
70K1090A 1
CAM FOLLOWER
ｶﾑﾌｫﾛｱ CFS04
71N4017A 1
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め       
M2X3L
72A4068H 2
ELBOW
ｴﾙﾎﾞ M-5ALU-4
41.2.アウトコンベア(逆流れ)Out conveyor(Right-to-left board flow)(Option)(CSQC)
CP-643ME PARTS LIST ver04
41-8
41.2.アウトコンベア(逆流れ)(Option)(CSQC)
41.2.Out conveyor(Right-to-left board flow)(Option)(CSQC)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
73K5347K 2 CONTROLLER, SPEED ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ AS2301FM-01-06S
74Y3066X 2 UNION ﾕﾆｵﾝ KQ2E06-01
75K50764 2 CONNECTOR ｺﾈｸﾀ KQ2U06-01S
76H5266A 1
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M2X6L
77K5335A 2
CONTROLLER, SPEED
ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ JSU4
78N10664 NUT U ﾅｯﾄ U M05
79N1080A
NUT, HEX
ﾅｯﾄ 六角         
M4 P=0.7
80N1085A
NUT, HEX
ﾅｯﾄ 六角         
M6
81K41316 1 FLEXIBLE TRACK ｹｰﾌﾞﾙﾍﾞｱ 07.30-018-21-630P
82W1021A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M
83W1022A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M
84W1023A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M
85W1024A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M
86W1043A WASHER, FLAT ﾜｯｼｬ 平 4W-4
87W1011A
WASHER, CONICAL
ﾜｯｼｬ 皿         
M-4-L
88W1012A
WASHER, CONICAL
ﾜｯｼｬ 皿         
M-5-L
89W1013A
WASHER, CONICAL
ﾜｯｼｬ 皿         
M-6-H
90K5178T
SCREW, C/R PAN
小ﾈｼﾞ 十穴鍋        
M3X12L
91.
SCREW, C/R PAN
小ﾈｼﾞ 十穴鍋        
M3X25L
92K5357H
SCREW, HEX SOCKET COUNTERSUNK
小ﾈｼﾞ 六角穴皿      
M3X5L
93K5357M
SCREW, HEX SOCKET COUNTERSUNK
小ﾈｼﾞ 六角穴皿      
M3X6L
94H5273T
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M3X4L
95H5277A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M3X12L
96H5281A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M3X25L
97H5286A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X6L
98H5287A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M4X8L
99H5289A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M4X12L
100H5290A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M4X15L
101H5291A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M4X18L
102H5292T BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X22L
103H5296L BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X65L
104H5299A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M5X12L
105H5263C BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X16L
106H5302A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M5X20L
107H5321A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M6X12L
108H5322A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M6X15L
41.2.アウトコンベア(逆流れ)Out conveyor(Right-to-left board flow)(Option)(CSQC)
CP-643ME PARTS LIST ver04
41-9
41.2.アウトコンベア(逆流れ)(Option)(CSQC)
41.2.Out conveyor(Right-to-left board flow)(Option)(CSQC)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
109H5323A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M6X18L
110H5324A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M6X20L
41.2.アウトコンベア(逆流れ)Out conveyor(Right-to-left board flow)(Option)(CSQC)
CP-643ME PARTS LIST ver04
41-10
41.2.アウトコンベア(逆流れ)(Option)(CSQC)
41.2.Out conveyor(Right-to-left board flow)(Option)(CSQC)
