1 8 - 1 1 8 . 第1 6 ｽ ﾃ ｰ ｼ ｮ ﾝ ( N G 部ﾊ ﾟ ｰ ﾂ 排出) , 残ﾃ ｰ ﾌ ﾟ ｶ ｯ ﾄ 部( W P U , W P K ) 1 8 . S t a t i o n 1 6 ( P a r t s e j e c t ) , W a s t e t a p e c u t t e r ( W P U , W P K ) 1 8 . 第1 6 ｽ ﾃ ｰ ｼ ｮ ﾝ ( N G ﾊ ﾟ ｰ ﾂ…

100%1 / 224
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
80WPQ0830 1 BKT BKT
81WPQ0822 1 SEAL ｼｰﾙ
82WPQ0784 2 HOLDER ﾎﾙﾀﾞ
83H4118T 4 BEARING ﾍﾞｱﾘﾝｸﾞ SST-1810DSG
84WPQ0760 2 COLLAR ｶﾗｰ
85WPQ0771 2 NUT ﾅｯﾄ
86WPQ0791 2 RETAINER, BEARING 押え ﾍﾞｱﾘﾝｸﾞ
87H42726 2 BEARING, SPHERICAL ﾍﾞｱﾘﾝｸﾞ 球面 NB-5
88WPQ0811 2 ROD, JOINT ﾛｯﾄﾞ ｼﾞｮｲﾝﾄ
89WPQ0850 2 PIN ﾋﾟﾝ
90W1008T 2 WASHER ﾜｯｼｬ WW-12
91K5255H SCREW, HEX SOCKET BUTTON 小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M3X5L
92H2025A 2 PIN, SNAP ﾋﾟﾝ ｽﾅｯﾌﾟ SSP-5
93A5043T 5 RETAINER, RAIL 押え ﾚｰﾙ PFP-M
94. SCREW, C/R PAN 小ﾈｼﾞ 十穴鍋 M4X8L
95WPQ0840 1 SEAL (FRENCH) ｼｰﾙ
96AWPQ8014 2 SHAFT, SPLINE ｼｬﾌﾄ ｽﾌﾟﾗｲﾝ
97H5299A 2 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X12L ･
17-4
17.第3ｽﾃｰｼｮﾝ(装着角度ﾌﾟﾘθ),第13ｽﾃｰｼｮﾝ(P角度ﾘﾊﾞｰｽ)(WPQ)
17.Station 3(Pre theta),Station 13(Reverse pre theta)(WPQ)
17.第3ｽﾃｰｼｮﾝ(装着角度ﾌﾟﾘθ),第13ｽﾃｰｼｮﾝ(P角度ﾘﾊﾞｰｽ)Station 3(Pre theta),Station 13(Reverse pre theta)(WPQ)
CP-643ME PARTS LIST ver04
18-1
18.第16ｽﾃｰｼｮﾝ(NG部ﾊﾟｰﾂ排出),残ﾃｰﾌﾟｶｯﾄ部(WPU,WPK)
18.Station 16(Parts eject),Waste tape cutter(WPU,WPK)
18.第16ｽﾃｰｼｮﾝ(NGﾊﾟｰﾂ排出),残ﾃｰﾌﾟｶｯﾄ部 Station 16(Parts eject),Waste tape cutter(WPU,WPK)
CP-643ME PARTS LIST ver04
Ref.33-7
Ref.31-1
Ref.31-1
Ref.31-1
Ref.31-1
87
63
79
59
32
34
33
25
31
25
33
29
37
56
38
28
83
86
30
24
26
27
62
14
13
14
62
15
15
16
25
12
19
19
17
18
17
60
76
2
11
88
94
75
93
75
89
72
82
90
81
69
81
85
78
7
20
8
66
6
68
81
5
20
64
79
4
3
95
96
61
75
74
1
113
75
61
9
61
84
67
81
115
82
91
76
58
10
97
98
22
55
92
61
75
57
73
50
21
57
73
51
53
54
52
61
75
74
36
23
81
71
35
78
116
84
75
44
45
46
48
48
47
43
49
56
56
100
102
100
101
103
42
40
41
103
39
104
56
56
65
78
77
114
112
111
73
108
110
73
105
107
106
109
65
78
92
99
208
176
165
175
161
175
161
175
161
183
162
176
167
175
161
13
13
B
A
139
26
x6
Right-to-left board flow
逆流れ (Option)
A
C
B
A
C
B
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
1WPK0370 1 DUCT ﾀﾞｸﾄ
2WPK0023 1 PLATE ﾌﾟﾚｰﾄ
3WPK0330 1 BKT BKT
4WPK0241 1 CUTTER, STATIONARY ｶｯﾀ 固定
5WPK0260 1 PLATE ﾌﾟﾚｰﾄ
6WPK0271 1 PLATE ﾌﾟﾚｰﾄ
7WPK0071 1 PLATE ﾌﾟﾚｰﾄ
8WPK0312 1 CUTTER, MOVABLE ｶｯﾀ 可動
9WPK0100 1 CLAMPER ｸﾗﾝﾊﾟ
10WPK0111 1 PLATE ﾌﾟﾚｰﾄ
11WPK0122 1 SHAFT, PIVOT ｼｬﾌﾄ 支点
12WPK0130 1 LEVER ﾚﾊﾞｰ
13GPK0880 1 NUT ﾅｯﾄ
14GPK2220 2 BLOCK 駒
15H4296A 2 BEARING, THRUST ﾍﾞｱﾘﾝｸﾞ ｽﾗｽﾄ AS1629
16H4300A 1 BEARING, THRUST ﾍﾞｱﾘﾝｸﾞ ｽﾗｽﾄ NTB1629
17H4297A 2 BEARING, THRUST ﾍﾞｱﾘﾝｸﾞ ｽﾗｽﾄ AS1831
18H4301A 1 BEARING, THRUST ﾍﾞｱﾘﾝｸﾞ ｽﾗｽﾄ NTB1831
19H4412A 2 BEARING, NEEDLE ﾍﾞｱﾘﾝｸﾞ ﾆｰﾄﾞﾙ TLA1612Z
20K1091A 5 CAM FOLLOWER ｶﾑﾌｫﾛｱ CFS-05
21WPU0281 1 BOX BOX
22WPK0159 1 PLATE ﾌﾟﾚｰﾄ
23WPU0370 1 BKT BKT
24GPH1795 1 PIN ﾋﾟﾝ
25H4403A 3 BEARING, NEEDLE ﾍﾞｱﾘﾝｸﾞ ﾆｰﾄﾞﾙ TLA810Z
26WPU0212 1 JOINT ｼﾞｮｲﾝﾄ
28WPU0220 1 JOINT ｼﾞｮｲﾝﾄ
29WPU0340 1 SPRING ｽﾌﾟﾘﾝｸﾞ
30WPU0331 1 JOINT ｼﾞｮｲﾝﾄ
31WPU0203 1 LEVER ﾚﾊﾞｰ
32WPU0030 1 BKT BKT
33WPU0070 2 COLLAR ｶﾗｰ
34WPU0151 1 SHAFT ｼｬﾌﾄ
35WPU0361 1 BKT BKT
36WPU0290 1 BRUSH ﾌﾞﾗｼ
37WPU0241 1 PIN ﾋﾟﾝ
18-2
18.第16ｽﾃｰｼｮﾝ(NG部ﾊﾟｰﾂ排出),残ﾃｰﾌﾟｶｯﾄ部(WPU,WPK)
18.Station 16(Parts eject),Waste tape cutter(WPU,WPK)
18.第16ｽﾃｰｼｮﾝ(NGﾊﾟｰﾂ排出),残ﾃｰﾌﾟｶｯﾄ部 Station 16(Parts eject),Waste tape cutter(WPU,WPK)
CP-643ME PARTS LIST ver04
