MDOC-SOFT50032
13
2.YS24SeriesLayout
2.1Layout&Name
2.2Headnumber
2.3Cameracomposition&Cameranumber
2.4Feedersetnumber
2.5Axisname&Axisdimension
MDOC-SOFT50032
14
2.1Layout&Name
<CommontoYS24Series>
*TwoX-beamandTwoHead
HEADUNITA
HEADUNITB
MOUNTTABLEB
MOUNTTABLEA
MDOC-SOFT50032
15
MOUNTSTAGE(R->L)
MOUNTSTAGE2
MOUNTSTAGE1
MOUNTSTAGE1
<YS24(DS)YS24X(DS)>
SingleStageMountingandDualStage
Mountingchangebytheboardsize.
(Details:3.1)
SingleStageMounting DualStageMounting
