MDOC-SOFT50032
35
ConveySpec(Fast)
Size
SizeSize
Size～
～～
～
225mm
225mm225mm
225mm
Thenexttransferactionstartswhen
passingtheexitpositionworkoutsensor.
Thecarry-intransferaction
startswhenthemount
positionsensordetectsboard.
R->L
Thenexttransferactioncannotstart
whentheboardexistsattheexitposition.
Whenthemountingisfinished,itcarries
theboardtotheexitposition.
*TransferactionoverL195uptoL225showsasfollows.
Thenexttransferactionstartswhenthe
workoutsensordetectsboard.
MDOC-SOFT50032
36
ConveySpec(Fast)
Size
SizeSize
Size-
--
-
330mm
330mm330mm
330mm
R->L
Thenexttransferactioncannotstart
whentheboardexistsattheexitposition.
Whenthemountingisfinished,itcarries
theboardtotheexitposition.
*TransferactionoverL225uptoL330showsasfollows.
Thenexttransferactionstartswhen
passingtheexitpositionworkoutsensor.
Thecarry-intransferaction
startswhentheworkoutsensor
detectsboard.
MDOC-SOFT50032
37
ConveySpec(Fast)
Size
SizeSize
Size-
--
-
590mm
590mm590mm
590mm
R->L
*TransferactionoverL330uptoL590showsasfollows.
*SingleStageMounting(Twoboardsbufferinthemachine)
Whenthemountingisfinished,itcarries
theboardtotheexitposition.
Thecarry-intransferactionstarts
whentheworkoutsensordetects
board.
Twoboardsbufferinthemachine
Thenexttransferactionstartswhen
passingtheexitpositionworkout
sensor.
