4.3Utility/TeachingOperation
*Palletsaresetasfollows,inthecaseofPalletSetin[Unit]-[AutoTC].
*Palletsaresetasfollows,inTracetothepickpositionforthepartssuppliedfromATS.
AndtheteachingunitofheadunitBmovesoverthepartswhichtraycountis(1,1).
*Therelationshipbetweenthearrowbuttonsforteachingandthedirectionofaxis
areasfollows.(SimilarinCursorTeach,PitchTeach,andso on.)
A
B
C
D
CD
A
B
MDOC-SOFT50032
51
4.4SlideMechanisminMaintenance
*ItispossibletodetachsATSIIunitwithslideformaintenance inmachine.
Pleaseworkaccordingtothefollowingprocedures.
WhendetachthesATSIIunit
1.PushEmergencybutton.
2.TurnATSLOCKSWtooff.
3.ReleasethefixationofsATSIIunit.
*IncaseofthedangersituationfordetachingsATSIIunit,
ATSLOCKcannotbereleased.(In2.work)
WhenattachthesATSIIunit
1.FixsATSIIunit.
2.TurnATSLOCKSWtoon.
3.PushReadybuttonandturnontheservo.
*WhensATSIIunitisnotfixedcorrectly,
ATSLOCKcannotbeworked.(In2.work)
Whenthemachineturnsoffcorrectly,
ATSLOCKisreleasedautomatically.
Whenthemachineturnson
withthesituationthatsATSIIunitisfixedcorrectly,
ATSLOCKworksautomatically.
(ATSLOCKSWoperationisn’tneededinaboveconditions.)
ATSLOCKSW
CLAMPHANDLE
WhenATSLOCKisnotreleased,
sATSIIunitcannotbedetached,
evenifyouturntheCLAMPHANDLE.
TodetachsATSIIunit,
Itisnecessarytoremovetheotherfixedbolt
undersATSIIunit.
ATSLOCK
MDOC-SOFT50032
52
4.5Others
*TheTrayPriorityfunctionwasabolishedinYS24X+sATSII.
Itisthefunctiontogiveprioritytomountingtrayparts,when thepalletwaspulled.
Itisbecausetheefficiencyofthemounting decreases inthecaseoftwinarmheadmachine.
*TheRecoveryPalletfunctionwasadded.
Withbuyingtheoptionalrecoverypallet,
itbecomespossibletodumppartsassignedtoheadunitBonthe recoverypallet,
inindependenceonthekindofsupplyformoftheparts.
ThefeedersetpositionisnotlostunliketheQFPdump station.
(Refertothemanualfordetails.)
Thereisarestrictionmatterbelowthecurrentstate.
- Onlythedumpactioninauto-runningissupported.
(thedumpactioninresetandthedumpactionafterpartsadjust arenownotsupported.)
- InthecasethattheQFPdumpstationisalsousable,
theQFPdumpstationisgivenpriorityautomatically.
- Refertothedeliveryspecificationsforthepartskind
whichcanbedumpedontherecoverypallet.
- Thefollowingfunctionsconcerningtherecoverypallet arenownotsupported.
- ITOptionSetupVerification
- Y.FactS-ToolSetupNavi
- Y.FactP-ToolFeederViewer
