MDOC-SOFT50032
5
DS: Dual Stage
SL: Single Lane
DL: Dual Lane
DS:DualStage SL:SingleLane DL:DualLane
Notes :OutlineofMachineLayout
MDOC-SOFT50032
6
1.2YS24SeriesSpecification
• TwoX-beamandTwoHead
– TwoX-beamandtwoheadisdisposedin thesamesize(1250mm)as
YS12.Thedepthofthemachineis1690mm.
• DualStage(onlyYS24-DS,YS24X-DS)
– ItispossibletomountbyusingadualstageuptoL330mm.
1,254mm
1,687mm
TwoX-beam
Y-axisLinearmotor
Dualstageconveyor
Twohead
MDOC-SOFT50032
7
1.2YS24SeriesSpecification
• DualLaneConveyor(YS24(DL)andYS24X(DL)only)
– TheboarduptoW216mmcanbeconveyedinbothconveyorlanes.
(Whenonlyonesideconveyorlaneisused,boardsizeW380mmcan work.)
– Withcustomlayout,theboarduptoW280mmcanbetransferredin both
conveyorlanes.
1,254mm
1,687mm
