1.2YS24SeriesSpecification

• DualLaneConveyor(YS24(DL)andYS24X(DL)only)

– TheboarduptoW216mmcanbeconveyedinbothconveyorlanes.

(Whenonlyonesideconveyorlaneisused,boardsizeW380mmcan work.)

– Withcustomlayout,theboarduptoW280mmcanbetransferredin both

conveyorlanes.

1,254mm

1,687mm

MDOC-SOFT50032

1.3TrayChanger

• sATSII (Option)

– ItcanbeequippedwithonlyYS24X(SL)and

YS24X(DL).

– MagazineType:15Paletteｘ2

– Themagazineandthepalettearecompatible

withsATS.

– MaxTraySize:L325ｘ W205mm

– IthastheSlideMechanismforMaintenance

Fordetails,seeChapter4.

MDOC-SOFT50032

1.4 YSSeriesCommonSpecification

• SSFeeder

– Intelligent&Electricdrive

– Built-intapecutter(Option)

– CompactSSFeedercarriage

• Itiseasytodisposeofemptywastetapes,without

removingthecart.

– Changeablefeederpitchbyboarddata

• Recognitionsystem

– Scancamera

• Applicablecomponents0402- 8x8mm

• Sideviewrecognition

– Multicamera

• Applicablecomponents0402– 32x32mm

(2048pixel)

• SafetyandEnvironmentalConsiderations

– DeviceiscompatiblewithCEmarkingtoensuresafedevice

design,enablingittobemarkedaroundtheworld.

– Compatiblewithairsupplysourceof0.45MPa.

Scan camera

Multi camera
