-K381
(AD/DA)
PNF0A7
24V
A-in
GND
FGND
1
2
3
4
CN5
4
MOLEX
CN5K381
43025-0400
3
2
1
Power suplly(10 to 30VDC)
GND(0V)
HIGH judgement output
PASS judgement output
LOW judgement output
OMRON
ZX2-LDA11
-B1815
高さ検出センサー
Height Detect Sensor
LASER
SENSOR
-B1815T
ZX2-LD50V
OMRON
Error output
Linear output
Linear GND
LD-OFF input
ZERO reset input
Timing input/Bank0 input)
Reset input/Bank1 input)
BU
BN
GN
WH
YE
GY
SHILD
BK
OR
PK
RD
VT
SR24
Out5
1
2
CN15
AMP
CN15K381
177898-1
2
1
OMRON
ZX2-XC1R
Panasonic Factory Solutions Co.,Ltd. パナソニック ファクトリーソリューションズ株式会社
Name
Drawing No.
Loc. No.
F4K1020-05A
1
2 3 4 5 6 7 8
A
B
C
D
E
F
1 2 3 4 5 6 7 8
A
B
C
D
E
F
Page. No.
Height Detection Laser Unit(H):SPG
N610146319+002AA
P002
