1G4C-E-MP4-1.pdf - 第10页

Ref No. Remark s R 1 Q'ty 㪌㪄㪘 䉦䊷䊃 䊥䉾䉳 䊓䉾䊄ኻᔕ Ca rtridg e H ead supp ort 䍐䍵䍛䍢 㪥㫆㪅 Part No. ຠ䇭䇭ฬ ຠ⇟ ᢙ㊂ R 2 䊌䊷䉿䊥䉴䊃 Kit N o . 䉨䉾䊃ຠ ⇟ Kit Name 䉨䉾䊃ฬ⒓ KXFX039VA00 Part Name ஻䇭䇭䇭⠨ 䍜䍖䍚䍌䍻㪥㫆㪅 PARTS LIST Section No. R 3 HINGE 2 …

100%1 / 26
㪌㪄㪘
䉦䊷䊃䊥䉾䉳䊓䉾䊄ኻᔕ
Cartridge Head support
䊌䊷䉿䊧䉟䉝䉡䊃
Kit N
o
.
䉨䉾䊃ຠ
⇟
Kit Name
䉨䉾䊃ฬ⒓
KXFX039VA00
䍜䍖䍚䍌䍻㪥㫆㪅
PARTS LAYOUT
Section No.
S9
--:(:8#
Ref
No.
Remarks
R
1
Q'ty
㪌㪄㪘
䉦䊷䊃䊥䉾䉳䊓䉾䊄ኻᔕ
Cartridge Head support
䍐䍵䍛䍢
㪥㫆㪅
Part No.
ຠ䇭䇭ฬຠ⇟ ᢙ㊂
R
2
䊌䊷䉿䊥䉴䊃
Kit N
o
.
䉨䉾䊃ຠ
⇟
Kit Name
䉨䉾䊃ฬ⒓
KXFX039VA00
Part Name
஻䇭䇭䇭⠨
䍜䍖䍚䍌䍻㪥㫆㪅
PARTS LIST
Section No.
R
3
HINGE
2
1 KXFB029YA00
SHAFT
1
2 KXFB029ZA00
SHAFT
1
3 KXFB02A0A00
KNOB
1
4 KXFB02A1A01
JOINT
2
5 KXFB02A4A00
COLLAR
2
6 KXFB02A5A00
PLATE
1
7 KXFB02A7A00
ARM
1
8 KXFB02A8A00
ARM
1
9 KXFB02A9A00
KNOB
2
10 KXFB02AAA00
COLLAR
2
11 KXFB02ABA00
PLATE
1
12 N210001466AA
BLOCK
1
13 KXFB02ADA01
BLOCK
1
14 KXFB02AEA00
PLATE
1
15 KXFB02AFA00
PLATE
1
16 KXFB02AGA00
BRACKET
1
17 KXFB02ALA00
COVER
1
18 KXFB02ANA00
BRACKET
1
19 KXFB02ASA00
COVER
1
20 KXFB02ATA00
BRACKET
1
21 KXFB02AUA00
CYLINDER
1
22 KXF0A7SAA00 CQSB20-25D
CYLINDER
1
23 KXF0A7TAA00 CDQSB20-25D-A93L
TUBE
1
24 KXF0DWYGA00
Coil Tube D4XD2.5X5-Conductor(DA KXF0DWYGA00)
BOLT
2
25 N510017544AA
Hexagon socket button head screw M5X20-10.9 A2J (Trivalent)
SPACER
2
26 N510020129AA 3382330-40040
PLUNGER
1
27 KXF09WSAA00 BSZ6
SCREW
1
28 N510018974AA
Hexagon socket set screw Cup point M6X5-45H A2J (Trivalent)
BOLT
2
29 KXF0DWULA00 GUTB6-8-20
SHAFT
2
30 KXF0CP6AA00 SSFRD10-30.0-F12-B9-P6-N6-SC11
JOINT
3
31 KXF02BTAA00 KQL04-M5
JOINT
1
32 KXF0A7XAA00 KQK04-M5
PIN
2
33 KXF0BY4AA00 SPP1.5-6
NUT
5
34 KXF0DWUMA00 Domed cap nut M4 3-type(SUS)
SCREW
5
35 N510018282AA
Cross recessed Truss head machine screw M4X8-4.8 A2J (Trivalent)
PLUNGER
4
36 KXF0A7YAA00 PFSSN4
SHAFT
2
37 KXF0CP2AA00 NBJ02-6-65-M3-MA55
LINEAR-BUSH
2
38 KXF0A80AA00 LHIFC6
SCREW
2
39 N510018259AA
Cross recessed Truss head machine screw M4X12-4.8 A2J (Trivalent)
S10
--:(:8#
㪌㪄㪙
䉦䊷䊃䊥䉾䉳䊓䉾䊄ኻᔕ
Cartridge Head support
䊌䊷䉿䊧䉟䉝䉡䊃
Kit N
o
.
䉨䉾䊃ຠ
⇟
Kit Name
䉨䉾䊃ฬ⒓
KXFX039VA00
䍜䍖䍚䍌䍻㪥㫆㪅
PARTS LAYOUT
Section No.
S11
--:(:8#
